LV-671Z User's Manual
1.2 <Product Specification>
General Specification
Form Factor
CPU
Memory
Chipset
BIOS
Green Function
Watchdog Timer
Real Time Clock
Enhanced IDE
Multi-I/O Port
Chipset
Serial Port
USB Port
Parallel Port
Floppy Port
IrDA Port
K/B & Mouse
GPIO
Card Bus
PCMCIA
10
Mini-ITX motherboard at 170 x 170 mm (L x W)
Embedded Intel Celeron M 600MHz
Package: mBGA 479
FSB: 400MHz
1GBytes DDR200/266 SDRAM on one 184-pin DIMM socket
Unbuffered, non-ECC supported
Intel 82852GM GMCH and 82801DB ICH4
Phoenix-Award v6.00PG 4Mb PnP flash BIOS
Power saving mode includes doze, standby and suspend modes.
ACPI version 1.0 and APM version 1.2 compliant
System reset programmable watchdog timer with 1 ~ 255
sec./min. of timeout value
Intel ICH4 built-in RTC with lithium battery
PCI enhanced IDE interface supports dual channels and up to 4
ATAPI devices at UltraATA/100
One 40-pin and one 44-pin IDE port
DiskOnModule (DOM) embedded flash disk up to 1GBytes
Intel 82801DB ICH4 (USB) and Winbond W83627HF-AW LPC
Super I/O controller
Two external RS-232 serial port with 16C550 compatible UART
and 16 bytes FIFO
Six Hi-Speed USB 2.0 ports with 480 Mbps of transfer rate
Two external and four internal USB ports
One external bi-direction parallel port with SPP/ECP/EPP mode
One slim-type FDD port supports up to two FDD
One IrDA compliant Infrared interface supports SIR
External PS/2 keyboard and mouse ports on rear I/O panel
One 20-pin Digital I/O connector with 15-bit programmable I/O
interface
One PCMCIA Type I/II slot
Introduction

Product Specification
