CEILING
BEST
PLACEMENT
1000mm
ANYWHERE IN THIS
30 cm (12 in)
MINIMUM
DO NOT INSTALL
ACCEPTABLE
PLACEMENT
THIS AREA
DEAD AIR
DO NOT INSTALL
PEAK CEILING
500mm
NOT IN
THIS AREA
AREA
DO NOT INSTALL
SLOPED CEILING
500mm
NOT IN
1000mm
ANYWHERE IN THIS
AREA
DEAD AIR
Smoke alarm should
be located between
500mm and 1500mm
of the highest point.
IMAGE 2A
SIDE WALL
IMAGE 2B
