Smoke Alarms - Quell Q1300 Installer Manual

BEDROOM KITCHEN
LIVING ROOM
Smoke Alarms for Minimum Protection
Smoke Alarms for Additional Protection
Ionization Type Smoke Alarms with
"Hush" Control or Photoelectric Type
SINGLE FLOOR PLAN
IMAGE 1A
•
Install smoke alarms on sloped, peaked or cathedral ceilings
between 500 and 1500mm from the highest point of the ceiling.
Smoke alarms in rooms with ceiling slopes greater than 1 m in 8 m
horizontally should be located on the high side of the room (See
.
Image 2B)
BEDROOM
KITCHEN
GARAGE
BASEMENT
IMAGE 1C
TOTAL HOME PROTECTION
BEDROOM BEDROOM
BEDROOM
HALL
MASTER
BEDROOM
FAMILY ROOM
WORKSHOP
BEDROOM HALL BEDROOM
LIVING
KITCHEN
ROOM
BASEMENT
MULTIPLE FLOOR PLAN
IMAGE 1B
FIRE
EXTINGUISHERS
SMOKE
ALARMS
FIRE BLANKET
3
