Page 1: Instruction Manual
10X PAN-TILT-ZOOM CAMERA Instruction Manual English Version 4.0 INDUSTRY BUSINESS HOME RETAIL BUSINESS OUTDOOR LZC7091 www.lorextechnology.com Copyright © 2013 Lorex Technology Inc. - Page 2 Thank you for purchasing the LOREX Super+ Resolution 10X PTZ Speed-Dome Camera. This manual refers to the following models: • LZC7091 For the latest online manual and to learn about our complete range of accessory products, please visit our website at: www.lorextechnology.com...
-
Page 3: Need Help
NEED HELP? CO NTAC T U S F IRST DO NOT RETURN THIS PRODUCT TO THE STORE Please make sure to register your product at www.lorextechnology.com to receive product updates and technical support. 2 Easy Ways to Contact Us Online: Product Support is available 24/7 including product information, user manuals, quick start up guides and FAQ’s at www.lorextechnology.com/support... -
Page 4: Necesita Ayuda
VIEW YOUR WORLD™ VOIR VOTRE MONDE VEA SU MUNDO™ ¿NECESITA AYUDA? BESOIN D’ASSISTANCE? COMUNÍQUESE PRIMERO COMMUNIQUEZ D’ABORD CON NOSOTROS AVEC NOUS NO DEVUELVA ESTE PRODUCTO A LA TIENDA NE RETOURNEZ PAS CE PRODUIT AU MAGASIN Por favor, registre su producto en www.lorextechnology. Veuillez enregistrer votre produit sur le site com para recibir actualizaciones del producto y www.lorextechnology.com afin de recevoir des mises à... - Page 5 B E F O R E Y O U S TA R T Please make sure to register your product at www.lorextechnology.com to receive product updates and technical support THIS PRODUCT MAY REQUIRE PROFESSIONAL INSTALLATION LOREX IS COMMITTED TO FULFILLING YOUR SECURITY NEEDS •...
- Page 6 AVANT DE ANTES DE COMMENCER EMPEZAR Cerciórese de por favor colocar su producto Veuillez enregistrer votre produit sur le site en www.lorextechnology.com para recibir www.lorextechnology.com afin de recevoir actualizaciones y la información del producto des mises à jour et le soutien technique pour y soporte técnico.
- Page 7 Features • Latest Sony EXview™ II image sensor for best-in-class low light performance • Sony Effio™ video image processor delivers up to 700TV lines of resolution • 10X Optical Zoom and 10X Digital Zoom to focus in on even the finest details •...
-
Page 8: Safety Instructions
Safety Instructions • Read this guide carefully and keep it for future reference. • Follow all instructions for safe use of the product and handle with care. • Use the camera within given temperature, humidity, and voltage levels noted in the Technical Specifications. •... -
Page 9: Table Of Contents
TABLE OF CONTENTS 1. Getting Started ....... . . 1 2. -
Page 11: Getting Started
Getting Started 1. GETTING STARTED Before you start, ensure you have received all the items listed below: 3ft BNC/Power/RS485 Cable Camera 100ft BNC/Power/RS485 Extension Cable Mounting Screw Kit 13V DC Power Adapter Instruction Manual Wall Mount Kit Foam Pad... -
Page 12: Connecting The Camera
Connecting the Camera 2. CONNECTING THE CAMERA It is recommended to connect the camera to your DVR and test the PTZ controls before permanent installation. 3ft BNC / Power / RS485 cable 6-Pin Connector Female Camera Male DC Power 100ft BNC / Power / RS485 extension cable Power adapter Female DC RS485... - Page 13 Connecting the Camera 1. Connect the 6-pin connector on the 3ft cable to the camera. • To do this, you must remove the camera from the case. Rotate the dome cover counterclockwise to remove. Remove the base attachment screws (3x) and remove the camera base. See illustration below.
- Page 14 Connecting the Camera 3. Use a Philips screwdriver (not included) to loosen the 2 screws on the RS485 connection block furthest from the pre-attached wires. Insert the RS485 wires into the RS485 connection block (red to red, black to black). Tighten the screws on the RS485 connection block to Loosen screws Insert wires...
- Page 15 Connecting the Camera • If the wires can be easily removed, they may become disconnected and affect control of the camera. Use wire strippers (not included) to expose more of the wires if needed. 7. Connect the male BNC connector on the 100ft extension cable to an available Video IN port on the DVR.
-
Page 16: Default Protocol Information
Connecting the Camera 2.1 DEFAULT PROTOCOL INFORMATION Unlike standard security cameras, PTZ (pan-tilt-zoom) cameras require special protocol information to enable a Security DVR to control the camera movement. Input the following information into your DVR to enable PTZ controls. • Default ID: 1 •... -
Page 17: Installation
Installation 3. INSTALLATION 3.1 INSTALLATION TIPS AND WARNINGS Make sure to install the camera in a location that can support the camera weight. Make sure there are no live electrical cables in the area where you plan to mount the camera. •... -
Page 18: Extension Cables
Installation 3.2 EXTENSION CABLES • Included extension cable is 100ft / 30m long. • Because this is a high-powered PTZ camera, the power cable cannot be extended beyond 100ft. • Alternatively, you may connect the included power adapter directly to the camera’s power connector and plug the adapter into a power outlet near the camera. -
Page 19: Wall Mount Installation (Indoor/Outdoor)
Installation 3.3 WALL MOUNT INSTALLATION (INDOOR/ OUTDOOR) Make sure to disconnect the power adapter before installing the camera. Camera will begin moving immediately when power adapter is connected. Camera can be installed to a wall using the included wall mount. This method is suitable for indoor or outdoor installations. - Page 20 Installation 3. Rotate the camera dome cover counterclockwise to remove. Dome cover 4. Remove the base attachment Base screws (3x) and remove the attachment camera from the camera base. screws Camera Camera base 5. Remove the rubber plug on the bottom of the camera base and run the single end of the cable through the bottom of the camera...
- Page 21 Installation 6. Connect the cable to the camera (see “Connecting the Camera” on page 2). Attach the camera to the base using the base attachment screws (3x) then reattach the dome cover by rotating it clockwise. NOTE: Make sure power adapter is disconnected before connecting the 6-pin connector.
-
Page 22: Ceiling Install (Indoor Only)
Installation 3.4 CEILING INSTALL (INDOOR ONLY) Make sure to disconnect the power adapter before installing the camera. Camera will begin moving immediately when power adapter is connected. Camera is not weatherproof if installed using this method. Use the included wall mount for outdoor installations. Camera can be installed directly to a ceiling. - Page 23 Installation 3. Remove the base attachment Base screws (3x) and remove the attachment camera from the camera base. screws Camera Camera base Remove the rubber plug on the bottom of the camera base and run the 6-pin connector through the cable hole. 5.
- Page 24 Installation 6. Attach the camera base to the ceiling using the included mounting screws (x4). NOTE: Use the included drywall anchors if installing the camera in drywall. Mounting screws 7. Connect the 6-pin connector to the camera. NOTE: Make sure power adapter is disconnected before connecting 6-Pin the 6-pin connector.
- Page 25 Installation 9. Reattach the dome cover by rotating it clockwise. Remove protective vinyl from dome cover. 10.Connect the cables. For details, see “Connecting the Camera” on page 2. • For details on DVR setup, see “Controlling the PTZ Camera with your DVR” on page 16.
-
Page 26: Controlling The Ptz Camera With Your Dvr
Controlling the PTZ Camera with your DVR 4. CONTROLLING THE PTZ CAMERA WITH YOUR DVR Once your camera is connected to the DVR, you must perform initial setup to control the camera using the DVR. Once this setup is complete, you will be able to move the camera, configure preset positions, and use other advanced controls. -
Page 27: Controlling The Camera
Controlling the PTZ Camera with your DVR 4. Configure the following: • Channel: Select the channel the camera is connected to. • Protocol: Select the protocol (default: Pelco-D). • Baud rate: Select the camera’s baud rate (default: 2400). • Data Bit: Select 8. •... - Page 28 Controlling the PTZ Camera with your DVR 3. Use the on-screen PTZ controls to control the camera. Channel: Speed Slider: Increase or decrease the pan and tilt speed Select the channel with the PTZ camera Direction keys: Camera Pre-set Click + / - to adjust the controls (see page 19) camera Zoom, Focus,...
-
Page 29: Ptz Presets And Ptz Cruise
Controlling the PTZ Camera with your DVR 4.3 PTZ PRESETS AND PTZ CRUISE Using the DVR, you can create presets. Presets allow you to save different positions of the camera, so you can return the camera to these positions without using the manual controls. A PTZ cruise (referred to on some DVR’s as a tour or scan), allows you to configure a sequence of presets that the camera will automatically cycle through. -
Page 30: Selecting Ptz Presets On The Eco2 Dvr
Controlling the PTZ Camera with your DVR 4. Complete the steps above to create additional presets as needed. Press Save when you are finished to save all created presets. 4.5 SELECTING PTZ PRESETS ON THE ECO2 DVR 1. In the No. field, select the number of the preset you would like to select. -
Page 31: Changing Protocol Information
Changing Protocol Information 5. CHANGING PROTOCOL INFORMATION The camera’s PTZ protocol information allows a DVR to communicate with it and control the camera’s movement. You will not need to change the default protocol information on your camera unless you are using multiple PTZ cameras or if your DVR does not support the default settings (see your DVR’s instruction manual for details). -
Page 32: Accessing The Dip Switches
Changing Protocol Information 5.1 ACCESSING THE DIP SWITCHES To access the DIP switches, you must remove the camera from the case. To do this, you must remove the camera from the case. Rotate the dome cover counterclockwise to remove. Remove the base attachment screws (3x) and remove the camera base. - Page 33 Changing Protocol Information You cannot use the same ID for more than 1 PTZ camera. IMPORTANT You cannot set an ID with a value of 0. Switch is ON or OFF OFF OFF OFF OFF OFF OFF OFF ON OFF ON OFF ON OFF ON OFF OFF...
-
Page 34: Setting The Camera Protocol And Baud Rate
Changing Protocol Information 5.3 SETTING THE CAMERA PROTOCOL AND BAUD RATE The protocol is the language that allows the camera and DVR to communicate, and the baud rate is the frequency of signal sent to the camera. The camera supports Pelco-D and Pelco-P protocols. Protocol and baud rate are set using switches 1&2 on the smaller DIP switch panel. -
Page 35: Technical Specifications
Technical Specifications 6. TECHNICAL SPECIFICATIONS Image Sensor 1/3" Sony Ex-View HAD CCD II Video Format NTSC Effective Pixels 976(H) x 494 (V) Resolution up to 700 TVL Range 360° Pan (Endless) 155° Tilt (Auto-Flip) Pan/Tilt Speed Max 360°/Sec. Zoom 10x Optical Zoom & 10x Digital Zoom Protocol Pelco-D, Pelco-P 0.7 Lux in Color ... -
Page 36: Dimensions
Dimensions 7. DIMENSIONS Units: mm Camera Camera and Wall Mount... -
Page 37: Troubleshooting
Troubleshooting 8. TROUBLESHOOTING There is no picture at night • Camera is capable of seeing in extremely low light conditions (0.02 Lux), but it cannot see in total darkness. It is recommended to install the camera where there is some ambient light (e.g. street lighting or starlight, moonlight, etc.) or leave a light on in the area where the camera is installed. - Page 38 Troubleshooting PTZ controls are not working or are not working properly • RS485 wires not connected or connected using wrong polarity. Ensure the red wire is connected to the + RS485 port and the black wire is connected to the - RS485 port. •...
- Page 40 EXPAND AND CUSTOMIZE YOUR SYSTEM WITH A FULL RANGE OF CAMERAS & ACCESSORIES Specialty Cameras Wireless Cameras Dome Cameras Digital Video Recorders Monitors Simulated Cameras Security Hard Disc Drives Extension Cables Accessories www.lorextechnology.com 1 - 8 8 8 - 4 2 - L O R E X ( 1 - 8 8 8 - 4 2 5 - 6 7 3 9 ) SEP 6 2012 - R16...
