啊哈
BBQ Range Hood
Installation and User manual
Content
Safety instructions---------------------------------- 2
Product description--------------------------------- 4
Installation & start using--------------------------- 6
Maintenance and cleaning------------------------9
Warranty-----------------------------------------------10
For warranty service call 1300 373 199(Australia)
or 0508 123108(New Zealand) to connect you to
the nearest authorised service centre
20130917 issue 1
1
BBQR123X
BBQR123X-F
Advertisement
Related Manuals for Bellini BBQR123X
Summary of Contents for Bellini BBQR123X
-
Page 1: Table Of Contents
Installation and User manual Content Safety instructions---------------------------------- 2 Product description--------------------------------- 4 Installation & start using--------------------------- 6 Maintenance and cleaning------------------------9 Warranty-----------------------------------------------10 For warranty service call 1300 373 199(Australia) BBQR123X or 0508 123108(New Zealand) to connect you to BBQR123X-F the nearest authorised service centre... -
Page 2: Safety Instructions
Safety instructions This manual explains the proper installation and use of your range hood, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. Never to do: Always to do: This appliance is not intended for use by persons... - Page 3 Safety instructions Never to do: Always to do: It is prohibited to fit the range hood over a solid fuel Attention should be given to ensure that any stove applicable regulations concerning discharge This appliance must not be connected to a chimney of exhaust air are fulfilled.
-
Page 4: Product Description
Product description Accessories Description Picture User Manual Upper chimney retaining bracket Lower chimney retaining bracket Hood mount bracket Dry wall anchors plugs Screw (ST4x8mm) Screw (ST4x30mm) Component list: Technical data: 1. Chimney cover 2. Upper chimney retaining bracket 3. Upper decorative chimney (Inner) 4. - Page 5 Installation and start using your range hood Dimensions: Installation Procedures: Warning: Check that the installation complies with the standards of local building, gas and electrical authorities. Before connecting to the mains supply ensure the mains voltage corresponds to the voltage on the appliance rating plate inside the range hood.
-
Page 6: Installation & Start Using
1. Using a spirit level, mark a vertical line on the wall (Central to the cook top installed below) to indicate the centre location of the hood and a horizontal line where the hood base will be positioned. Drill holes as per below drawing and insert dry wall anchor plugs into holes. - Page 7 2. Fasten Hood mount bracket by 4pcs ST4x30mm screws. 3. Hang on the main body of range hood. 4. Fit the outlet and flexible exhaust duct onto outlet 5. Slide out Upper Decorative Chimney to desired height.
- Page 8 6. Fasten Upper chimney retaining bracket by 4 pcs ST4x30mm screws, then fasten 2 pcs ST4x8mm screws at side to fix Upper Decorative Chimney. 7. Remove all blue protective film on chimney and cooker hood, the installation is now finished. Start using your range hood –...
-
Page 9: Maintenance And Cleaning
Maintenance and cleaning Caution: The baffle filters can be cleaned either by hand or in • Before maintenance or cleaning is carried out, the the dishwasher. After cleaning ensure that the filters range hood should be disconnected from the main are completely dry before refitting. -
Page 10: Warranty
Consumer until the expiry of two (2) years (Warranty Period). If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform to the Company’s specifications as a result of some defect in materials, components or workmanship (Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini product free of charge. - Page 11 1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.
