Main unit

2.2.1

Outside of the main unit

The illustration shows the main unit with an optional Multi Bypass Tray MB-503.
No. Name
1
Original Cover
2
Original Pad
3
Control Panel
4 1st Side Cover
5 1st Side Cover Release Lever
6 Bypass Tray (Option)
7
Tray 1
8 Front Cover
9 Output Tray
10
Power Switch
11
Power Cord
12
USB Port (Type A) USB2.0/1.1
2-4
1
9
8
7
12
11
2 3
Main unit 2.2
4
5
6
10
