LV-666 User's Manual
LV-666
MOTHER BOARD
User's Manual
Edition 1.1
October 19, 2004
Preface
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LV-666 and is the answer not in the manual?

Questions and answers

Summary of Contents for Commell LV-666

  • Page 1 LV-666 User’s Manual LV-666 MOTHER BOARD User’s Manual Edition 1.1 October 19, 2004 Preface...
  • Page 2: Copyright Notice

    LV-666 User’s Manual Copyright Notice ©Copyright 2004 The information contained in this user’s manual and all accompanying documentation is copyrighted and all rights are reserved. This publication may not, in whole or in part, be reproduced, transcribed, stored in a retrieval system, translated into any language or...
  • Page 3 LV-666 User’s Manual Manual Guide This manual is designed to help you build a reliable Personal Computer based on the LV-666 platform. Chapter 1—Quick Reference This chapter is for advanced users who want to quickly assemble a system. The motherboard layout along with jumper and switch settings, and memory configuration are provided.
  • Page 4: Table Of Contents

    LV-666 User’s Manual Table of Content 1. LV-666 Quick Reference ................... 6 1.1 Motherboard Layout ................. 6 1.2 I/O Ports ....................7 1.3 Front Panel Connector ................7 1.4 Jumpers....................8 1.5 PCI Frequency Setting ................10 1.6 Memory Installation ................10 1.7 Connectors .....................
  • Page 5 LV-666 User’s Manual 3.5.5 Front IEEE1394 connectors (1394_1 & 1394_2) ....... 24 3.5.6 Front USB Header (USB1/2 & USB 3/4) ........25 3.5.7 Floppy Driver Connector (FDD1)..........25 3.5.8 IDE connectors (PRIMARY1 & SECONDARY1)......26 3.5.9 Back Panel Connectors .............. 27 3.5.10 Power Supply Connector (ATXPWR1) ........
  • Page 6: Lv-666 Quick Reference

    LV-666 User’s Manual 1. LV-666 Quick Reference This section is for users to get started using the motherboard straight away. 1.1 Motherboard Layout 19 20 21 22 23 24 25 26 ATX Power connector (ATXPWR1) Audio Aux-in connector (J1) IDE connector (PRIMARY1)
  • Page 7: I/O Ports

    Quick Referenece LV-666 User’s Manual 1.2 I/O Ports 1.3 Front Panel Connector The following illustration shows the front panel connector pin assignments: Motherboard Layout...
  • Page 8: Jumpers

    LV-666 User’s Manual 1.4 Jumpers CLEAR_CMOS1 Mode Clear CMOS Normal Operation Default setting JCFSEL Compact Flash Mode Master Slave Default setting CPU RATIO 3.0x 3.5x 4.0x 4.5x 5.0x 5.5x 6.0x 6.5x 7.0x 7.5x 8.0x 8.5x 9.0x 9.5x 10.0x 10.5x 11.0x 11.5x...
  • Page 9 Quick Referenece LV-666 User’s Manual 12.0x 12.0x 12.5x 13.0x 13.5x 14.0x 14.5x 15.0x 15.5x 16.0x Switch Number RESERVE 1-OFF Default OVERSCAN 2-ON Enable 2-OFF Disable TV-mode NTSC NTSC-EIA PAL-M PAL-BDGHI PAL-Comb-N PAL-N COM2 RS232/485/422 Mode jumper setting Mode RS232 RS422...
  • Page 10: Pci Frequency Setting

    LV-666 User’s Manual 1.5 PCI Frequency Setting The PCI frequency settings are automatically set by the system 1.6 Memory Installation Note: This motherboard supports up to two double-sided or two single-sided DIMMs when the DDR DRAM interface is operating at 133 MHz. Installing DDR DIMM modules...
  • Page 11: Connectors

    Quick Referenece LV-666 User’s Manual 1.7 Connectors Connector Function Remark DIMM1 184-pin DIMM Socket Standard DIMM2 184-pin DIMM Socket Standard PRIMARY1 40-pin Primary IDE Port Standard SECONDARY1 40-pin Secondary IDE Port Standard FDD1 34-pin FDD Port Standard COM2 10-pin COM2 RS-232/485/422 Serial Port...
  • Page 12: Introduction

    LV-666 User’s Manual 2. Introduction 2.1 Overview The high quality LV-666 is a high-performance, enhanced function motherboard that supports VIA C3/Eden Embedded processor with 133 MHz front side bus (FSB). This motherboard is designed around the latest VIA CLE266 Chipset in Mini-ITX form factor.
  • Page 13: Motherboard Specifications And Features

    Appendix LV-666 User’s Manual 2.2 Motherboard Specifications and Features 2.2.1. Hardware General Specification Form Factor Mini-ITX at 170 x 170 mm (L x W) VIA C3/Eden Embedded processor at 133MHz FSB Memory 2GBytes DDR200/266 SDRAM on 2 x 184-pin DIMM socket...
  • Page 14 Introduction LV-666 User’s Manual VGA Display Interface Chipset VIA CLE266 built-in internal AGP 4X 2D/3D graphics Frame Buffer Size BIOS selectable 8/16/32/64MB with system shared memory 2D Engine 128 bit 3D Engine 1 Pipe, 2 Texture, dedicated MPEG-2 Slice Layer, IDTC & Motion Compensation...
  • Page 15: Software

    Appendix LV-666 User’s Manual IEEE1394 Interface Chipset VIA VT6307S PCI IEEE1394 controller Interface IEEE1394 with 100/200/400 Mbps of data transfer bandwidth Connector 2 x internal IEEE1394 connector Power and Environment Power Requirement 20-pin ATX power connector Dimension 170 (L) x 170 (H) mm, Mini-ITX form factor...
  • Page 16: Motherboard Layout

    Introduction LV-666 User’s Manual 2.3 Motherboard Layout 12 13 14 1518 19 20 23 24 Note: Because of optional items and design changes, your motherboard may not be identical to the one shown in the illustration. Motherboard Specifications and Features...
  • Page 17 Appendix LV-666 User’s Manual Key to Motherboard Function Name Function ATXPWR1 Standard ATX Power Connector PRIMARY1 40-pin IDE1 Connector SECONDARY1 40-pin IDE2 Connector Front Panel Connector CHIPFAN System FAN PCI1 32-bit PCI Slot DIMM1 184-pin DDR SDRAM Socket DIMM2 184-pin DDR SDRAM Socket...
  • Page 18: Embedded Processor

    Introduction LV-666 User’s Manual 2.4 Embedded Processor The board supports embedded VIA C3/Eden EBGA368 processor from 300MHz to 1GHz. The C3 E-series provide best C/P rate performance, and the Eden series provide low power consumption solution. 2.5 AC’97 Codec The board is integrated with Realtek ALC650 codec. The ALC650 is an 18-bit, full duplex, AC’97 2.2 compatible stereo audio codec.
  • Page 19: Hardware Installation

    9. One 10/100Mps Ethernet wire to connect with your ADSL modem or HUB. 10. A speaker. 3.1 Packing List Please check the package list below: 1. 1 x LV-666 motherboard. 2. 1 x IDE 66/100 40-pin ribbon cable. 3. 1 x Floppy 34-pin ribbon cable. 4. 1 x Drivers and Utility CD.
  • Page 20: Installation

    LV-666 User’s Manual 3.2 Installation The LV-666 is designed to fit into a standard Mini-ITX ATX form factor chassis. The pattern of the mounting holes and the position of the back panel connectors meet the Mini-ITX ATX system board specification.
  • Page 21: Connector And Jumper Location

    Appendix LV-666 User’s Manual 3.4 Connector and Jumper Location Installation...
  • Page 22: Attaching Connectors

    Hardware Installation LV-666 User’s Manual 3.5 Attaching Connectors 3.5.1 Front Panel Connectors (JP1) There are seven connectors on the motherboard for speaker, switches, and indicator lights on the system’s front panel. This 2-pin connector connects to the case-mounted PW SW Power button.
  • Page 23: Audio Cd-In Connector (J2)

    Appendix LV-666 User’s Manual 3.5.2 Audio CD-in connector (J2) This connector enables you to connect a CD-ROM to the motherboard and receive stereo audio input 3.5.3 Audio Line-out connector (JP3) Attaching Connectors...
  • Page 24: Infrared (Ir) Connector (Ir1)

    Hardware Installation LV-666 User’s Manual 3.5.4 Infrared (IR) Connector (IR1) This 5-pinheader connects to an optional wireless transmitting and receiving infrared module via a cable and a bracket. Configure BIOS to enable the IrDA port if you attach an infrared module to this connector. Refer to Integrated Peripherals in Chapter 4 for details.
  • Page 25: Front Usb Header (Usb1/2 & Usb 3/4)

    Appendix LV-666 User’s Manual 3.5.6 Front USB Header (USB1/2 & USB 3/4) 3.5.7 Floppy Driver Connector (FDD1) Attaching Connectors...
  • Page 26: Ide Connectors (Primary1 & Secondary1)

    Hardware Installation LV-666 User’s Manual 3.5.8 IDE connectors (PRIMARY1 & SECONDARY1) An IDE drive ribbon cable has two connectors to support two IDE drives. If a ribbon cable connects to two IDE drives at the same time, one of them has to be configured as Master and the other has to be configured as Slave by setting the drive select jumpers on the drive.
  • Page 27: Back Panel Connectors

    Appendix LV-666 User’s Manual 3.5.9 Back Panel Connectors The back panel provides external access to PS/2 style keyboard and mouse connectors, two serial ports, one parallel port, dual USB ports, and audio Line-out, Line-in, MIC-in ports which are integrated on the motherboard. The figures below show the location of the back panel I/O connectors.
  • Page 28 Hardware Installation LV-666 User’s Manual S-Video Port You can connect S-Video devices to S-Video port on the back panel. RCA Video (TV-Out) You can connect RCA Video devices to RCA Video port (TV-Out) on the back- panel. LAN Port Connect a device to the LAN port on the back panel.
  • Page 29 Appendix LV-666 User’s Manual Serial Port Connect a serial device such as a mouse or modem to the 9-pin serial port. You can set the serial port IRQs in BIOS. Refer to integrated Peripherals in Chapter 4 for details. Note: Serial printers must be connected to the serial port.
  • Page 30: Power Supply Connector (Atxpwr1)

    Hardware Installation LV-666 User’s Manual 3.5.10 Power Supply Connector (ATXPWR1) The ATX power supply has a single lead connector with a clip on one side of the plastic housing. There is only one way to plug the lead into to ATX power connector.
  • Page 31: Cpu/System Fan Connectors

    Appendix LV-666 User’s Manual 3.5.11 CPU/System Fan connectors There are two fan connectors on the motherboard for the cooling fans. The connectors support fans of 12VDC/500mAMP (six watt) or less. When the system goes into sleep state, fans should be shut down to eliminate audible noise and reduce power consumption.
  • Page 32: Serial Com2 Connector (Com2)

    Hardware Installation LV-666 User’s Manual 3.5.13 Serial COM2 connector (COM2) The motherboard provides one onboard serial COM2 connector. The COM2 connector has the same signal with COM1 on the back panel. The COM2 also support RS485/422 communication mode. Please follow the jumper setting below to select the mode you need.
  • Page 33: Front Mic-In Connector (Jp2)

    Appendix LV-666 User’s Manual 3.5.14 Front MIC-in connector (JP2) Connect a microphone to the pink microphone connector to record audio to your computer. Ground MICIN 3.5.15 Front AUX connector (J1) Connector the cable attached to line-out connector on front panel. This header shared same signal with line-out back panel.
  • Page 34: Lvds Connector

    Hardware Installation LV-666 User’s Manual 3.5.16 LVDS connector The board supports LCD LVDS interface, you can use a panel through this interface. Pin NO Pin Assignment Pin NO Pin Assignment +3.3V +3.3V TVD0 +2.5V TVD1 +2.5V TVD2 TVD3 TVD4 Ground...
  • Page 35: Optional Dvo Interface

    Hardware Installation LV-666 User’s Manual 3.5.17 Optional DVO interface The board supports DVO interface to support multimedia video input and output. JP7 J11 Attaching Connectors...
  • Page 36: Installing System Memory

    Hardware Installation LV-666 User’s Manual 3.6 Installing System Memory Maximum system memory supported by the motherboard is 2GB.The motherboard has two DIMM Sockets. Memory can be installed using 184-pin DDR SDRAM DIMM memory modules. These are no jumper settings required for the memory size or type, which is automatically detected by the BIOS.
  • Page 37: Cpu & Cmos Jumper Setting

    Hardware Installation LV-666 User’s Manual 3.7 CPU & CMOS Jumper Setting Refer to the following illustration and instructions to set the jumpers on your motherboard. Notice: the SW2 can let you configure the CPU ratio, but we have set done this before the board is shipped, please do not attend to overclock, this may due to the system unstable.
  • Page 38: Cpu Ratio

    Hardware Installation LV-666 User’s Manual Please check the following ratio form of CPU clock ratio if your board runs the wrong frequency of your order. CPU RATIO 3.0x 3.5x 4.0x 4.5x 5.0x 5.5x 6.0x 6.5x 7.0x 7.5x 8.0x 8.5x 9.0x 9.5x...
  • Page 39: Appendix A: Lvds Module Setup Information

    Appendix LV-666 User’s Manual Appendix A: LVDS Module Setup Information A.1: Layout Pin-1 A.2 Jumper and Connector Reference Jumper: JP1 Type: Onboard 3-pin Header Mode 24-bit data in 12-bit data in Default setting Jumper: JP2 Type: Onboard 3-pin Header Mode...
  • Page 40 P6F169 User’s Manual Appendix Jumper: JP5 Type: Onboard 3-pin Header Mode 12-bit input with 24-bit RGB data input/output Two 12-bit input with 48-bit RGB data input/output Default setting Connector: CN3 Type: 5-pin header inverter connector Assignment +12V Connector: CN2 Type: onboard 40-pin connector for LVDS connector Signal Signal PVDD...
  • Page 41: Bios Panel Type Table

    P6F169 User’s Manual Appendix A.3 BIOS Panel Type Table Panel ID Resolution Channel Dithering 640x480 Enable 800x600 Enable 1024x768 Enable 1280x768 Enable 1280x1024 Enable 1400x1050 Enable 1600x1200 Enable 1280x800 Enable 800x480 Enable 1024x768 Enable 1024x768 Disable 1024x768 Disable 1280x768 Disable 1280x1024 Disable 1400x1050...
  • Page 42: Contact Information

    Contact Information LV-666 User’s Manual Contact Information Any advice or comment about our products and service, or anything we can help you please don’t hesitate to contact with us. We will do our best to support you for your products, projects and business.
