Menu Operation

The Main Menu is where you control the unit's
configuration. It is accessed by pressing the Menu button.
Once in the menu, turning the rotary encoder cycles through
the options while pressing the encoder advances the
selection. Pressing Menu will go back in levels until you exit
the menu. All settings are preserved when the unit is
powered off.

Inputs

USB 1.1 – Driver-less, plug-n-play computer input that is
limited to 96kHz.
USB 2.0 – Hi-speed computer input that is capable of 192kHz
and DSD playback. Use of this input requires drivers
installed on the computer.
FireWire – Hi-speed computer input that is capable of
192kHz and DSD playback. Use of this input requires drivers
installed on the computer.
S/PDIF – Coaxial S/PDIF input capable of receiving PCM
data up to 192kHz.
AES/EBU – Professional digital input capable of receiving
PCM data up to 192kHz.
Toslink – Optical S/PDIF input capable of receiving PCM
data up to 192kHz.
ADAT – Optical ADAT input capable of receiving PCM data
up to 96kHz. Signal originates from Channel 1-2 only.
Analog – Unbalanced RCA analog input that can bypass the
volume control or be routed through it. Available on the Pre
version only.
SDIF – Professional DSD input capable of receiving DSD64x
and DSD128x formats. Mastering version only.
Up-sampling
The unit has the capability to up-sample all PCM data to
192kHz sampling rate. This provides an analog bandwidth of
100kHz. With up-sampling enabled, it will automatically up-
sample PCM data. It will automatically turn off for DSD data.
