PT100 RTD Evaluation Board User's Guide
TABLE B-1: BILL OF MATERIALS (CONTINUED)
Qty Reference
3 R18, R22, RES 1.00K OHM 1/10W 1% 0805
R23 SMD
2 R19, R21 RES 10.0 OHM 1/8W 1% 0805 SMD Panasonic - ECG
1 R20 RES 619K OHM 1/8W 1% 0805
SMD
20 TP1<->TP20 TEST POINT PC COMPACT SMT
1 U1 Single-Ended, Rail-to-Rail I/O, Low
Gain PGA
1 U2 1 Mhz. Low Power Op-Amp
1 U3 Rail-to-Rail Input/Output, 10 MHz Op
Amps
1 U4 28/40/44-Pin, High-Performance,
Enhanced Flash, USB
microcontrollers with nanoWatt
Technology
1 U5 13-Bit Differential Input, Low-Power
A/D Converter with SPI Serial
Interface
1 U6 50mA, 100mA and 150mA Adjust-
able CMOS LDOs with Shutdown
3 U8,U9,U10 Single/Dual Digital Potentiometer
with SPI Interface
1 Y1 CRYSTAL 20.0000 MHZ 18PF SMD Citizen America Corp.
DS51607A-page 20
Description
Panasonic - ECG
Panasonic - ECG
Keystone Electronics
Microchip Technology Inc.
Microchip Technology Inc.
Microchip Technology Inc.
Microchip Technology Inc.
Microchip Technology Inc.
Microchip Technology Inc.
Microchip Technology Inc.
Manufacturer
ERJ-6ENF1001V
ERJ-6ENF10R0V
ERJ-6ENF6193V
®
5016
MCP6S26T-I/SL
MCP6002-I/SN
MCP6024-I/SL
PIC18F2550-I/SO
MCP3301-BI/SN
TC1071VCT
MCP41010-I/SN
CS20-20.000MABJ-UT
© 2006 Microchip Technology Inc.
Part Number
