- Page 1 EVO TM Uninterruptible Power Supply EVO TM 6.0 (6 KVA) EVO TM 8.0 (8 KVA) EVO TM 10.0 (10 KVA) EVO TM 12.0 (12 KVA) EVO TM 15.0 (15 KVA) USER’S MANUAL...
-
Page 3: Table Of Contents
TECHNICAL CHARACTERISTICS ................16 RECOMMENDATIONS FOR CORRECT USE ..............17 TROUBLESHOOTING ....................19 PICTURES......................21 Copyright 2007 TECNOWARE s.r.l. All rights reserved. All trademark are property of their respective owners. TECNOWARE s.r.l. www.service.tecnoware.com This manual has been printed and edited by TECNOWARE s.r.l. -
Page 4: Safety Warnings
Read this manual carefully and completely before installing and using the TECNOWARE EVO TM Uninterruptible Power Supply, which, from here after, will also be referred to as UPS. The UPS must be used only by properly trained personnel. To ensure correct and safe operations, it is necessary that operators and maintenance personnel observe the general safety Standards as well as the specific instructions included in this manual. -
Page 5: Introduction
EVO TM is constantly being developed and improved: consequently, your unit may differ somewhat from the description contained in this manual. This manual includes the follows models of the EVO TM series: • EVO TM 10.0 • EVO TM 6.0 • EVO TM 12.0 • EVO TM 8.0 • EVO TM 15.0 In this manual, which covers all 5 models, EVO TM will simply be referred to as UPS. -
Page 6: General Characteristics
3. GENERAL CHARACTERISTICS UPS EVO TM has all the modern features which guarantee maximum reliability and safety: Double-Conversion ON-LINE technology Sinusoidal wave generated by an IGBT INVERTER Output voltage regulation ±1% Protection from overload and short circuits Automatic BYPASS to protect from accidental overload or Inverter fault Start-up even under MAINS OFF conditions Automatic protection when battery is low Automatic restart, following an automatic shut-down due to low battery, once AC... -
Page 7: Receipt And Site Selection
4. RECEIPT AND SITE SELECTION Carefully remove the UPS from its packaging, and carry out a meticulous inspection. We recommend keeping the original packaging in case you need to send the UPS for maintenance purposes. In case of transport damage, notify the carrier and dealer immediately. We recommend keeping the original packaging in a secure place, in case you need to ship the UPS for maintenance purposes. -
Page 8: Battery Mode
BATTERY MODE During operation in the LINE MODE, if the UPS finds the MAINS OFF condition (due to a blackout or overvoltage/brownout), it then switches into BATTERY mode. In this case, the batteries supplies the required output power thanks to the DC/AC conversion carried out by the INVERTER. -
Page 9: External Description
Table 1 (the display shows the actual screen number visualized by a fractional number 2/8, 5/8, etc). Table 1: Indications of LCD display LCD Display show Description TECNOWARE Welcome message EVO TM XXX STATUS State of the system (*refer following note) -
Page 10: Rear Side
*AC and BAT refer respective to the mains voltage and to the battery, in particular: AC:IN Normal mains voltage AC:LOSS Anomalous mains voltage BAT:OK Normal Battery autonomy BAT:LOW Low Battery autonomy Table 2: led present on the frontal panel Indication on the panel Description This led indicates the presence of the input mains voltage is within specifications. - Page 11 EPO (EMERGENCY POWER OFF) REMOTE EPO SWITCH The EVO TM models have the EPO, Emergency Power OFF, ( connector on the rear see figure 4), side. This permits to immediately switch the UPS OFF from a distance in case of emergency. To use an external switch to activate EPO function it is sufficient to connect the switch to the EPO terminal as described in the above figure.
- Page 12 DRY CONTACTS BOARD (OPTIONAL) Com. Fault AC fail Bypass Low Bat Com. The Dry Contacts board has a 10 pin connector on the rear side of the UPS. 1. Common Pin 1 and Pin 10 are common pins. 2. Fault Pin 2 is the normal-open output: when UPS works normally, Pin 2 and Pin 1-10 will be open, when UPS is failed, Pin 2 and Pin 1-10 will be closed.
-
Page 13: Electrical Installation
7. ELECTRICAL INSTALLATION WARNING The electric installation, has to be done by qualified personnel. Follow all the Safety Standards (CEI Standards in Italy) for the IN/OUT connections and for the right section of IN/OUT cables. We recommend to use a dedicated AC input/output power Line for the UPS. - Page 14 The instructions below describe the operations to connect in right way the UPS to a BATTERY BOX supplied by Tecnoware. We suggest to use only BATTERY BOX supplied by TECNOWARE. TECNOWARE declines any responsibilities if this rule is not followed.
-
Page 15: First Start Up
There are no internal parts in the UPS which are user serviceable. Any repair or maintenance work must be performed exclusively by qualified technical personnel authorized by TECNOWARE. TECNOWARE declines any responsibility if this warning is disregarded. Disregard for these warnings may lead to a risk of electric shock to operators 8. -
Page 16: Functioning
9. FUNCTIONING TURNING ON AND OFF UPS EVO TM is equipped with a main switch placed on the rear (see figure 4). If this switch is in OFF position than UPS is completely OFF; else UPS is ON in one of the three functioning modes (LINE mode, BATTERY mode, BYPASS mode). -
Page 17: Computer Interface
LOAD TESTING UPS EVO TM indicates the output power percentage (respect to the nominal value) by the LCD display, visualizing it on the second row of the display. UPS EVO TM has the capability to accept an overload less than 110% for an indefinite time. An overload between 110% and 150% (indicate by an intermittent acoustic alarm and OVERLOAD led flashing) respect to the nominal value, is accepted for about 20 seconds and after UPS switches automatically to the BYPASS mode. -
Page 18: Technical Characteristics
11. TECHNICAL CHARACTERISTICS UPS EVO TM MODEL 6.0 TM 15.0 TM 8.0 TM 10.0 TM 12.0 TM 8000 VA 10000 VA 15000 VA 6000 VA 12000 VA POWER 4800 W 6400 W 8000 W 9600 W 12000 W ON-LINE Double Conversion with transformer TECNOLOGY Triphase 380 V NOMINAL INPUT VOLTAGE... -
Page 19: Recommendations For Correct Use
12. RECOMMENDATIONS FOR CORRECT USE UPS CLEANING WARNING Before any cleaning operation, make sure that the main switch (see figure 4) of the UPS is OFF and that mains input power has been removed. Use only a cloth dampened with water to clean the unit. If UPS works in an environmental unusually dusty or dirty, remove the dirty from the ventilation holes. -
Page 20: Operator Safety
PROTECTION OF POWERED DEVICES The UPS assure continuos adjusted and jammed alimentation only if it is NOT functioning in BYPASS mode. In this mode the INVERTER is off and at the output there is only the voltage that is present at the input by the AUTOMATIC BYPASS To light powered devices by the UPS make following operations: If UPS EVO TM is in BYPASS mode press ON button on frontal panel and wait the •... -
Page 21: Troubleshooting
13. TROUBLESHOOTING Following are described some functioning anomalies and relating solutions: UPS doesn’t lights on without giving any information Check if main switch on the rear is in ON position. • UPS continues to function in BATTERY mode also if AC input line is present at the input Make sure that is present AC input line at the input of the UPS and that AC input line •... - Page 22 TECNOWARE. TECNOWARE declines any responsibility if this warning is disregarded. If the described anomalies should continue despite the advised troubleshooting, or should they manifest in any other form, please contact TECNOWARE SUPPORT www.service.tecnoware.com...
-
Page 23: Pictures
14. PICTURES Figure 1 – Functioning mode User’s manual UPS EVO TM... - Page 24 BY-PASS LOAD LINE UNINTERRUPTIBLE POWER SUPPLY Figure 2A – Frontal Panel for EVO TM 6.0, EVO TM 8.0, EVO TM 10.0, EVO TM 12.0 1. ON button 2. OFF button 3. SELECTION button 4. BATTERY LOW led (yellow) 5. OVERLOAD led (red) 6.
- Page 25 Figure 2B – Frontal Panel for EVO TM 15.0 BUTTON LINE OFF Button BYPASS ON Button FAULT BATTERY LOW SELECTION Button OVERLOAD User’s manual UPS EVO TM...
- Page 26 Figure 3 – IN/OUT Terminal Blocks UPS EVO TM User’s manual...
- Page 27 Figure 4 - UPS EVO TM rear view On the left: EVO TM 6.0, in the middle: EVO TM 8.0, EVO TM 10.0, EVO TM 12.0; on the right: EVO TM 15.0 1. Main Switch WARNING Only EVO TM 8.0 -15.0...
- Page 28 UE countries. CONFORMITY TO THE EUROPEAN DIRECTIVES TECNOWARE S.r.l. confirms that EVO TM models comply with the requirements set out in: the Low Voltage Directive (Safety) 73/23/EEC and following amendments, the EMC (Electro-Magnetic Compatibility) Directive 89/336/EEC and following amendments.
- Page 29 TECNOWARE S.r.l. www.service.tecnoware.com User’s manual UPS EVO TM...
