Aristel C710 Manual

Cordless desk-phone connecting to the dect 209 2 line / 9 handset telephone system
Hide thumbs Also See for C710:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
A
r
i
s
t
e
l
N
e
t
w
o
r
k
s
A
r
i
s
t
e
l
N
e
t
w
o
r
k
s
Manual for the C710 Cordless Desk-phone
Connecting to the DECT 209
2 Line / 9 Handset
Telephone System
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C710 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel C710

Summary of Contents for Aristel C710

  • Page 1 Manual for the C710 Cordless Desk-phone Connecting to the DECT 209 2 Line / 9 Handset Telephone System...

  • Page 2: Key Function

    Warning This equipment will be inoperable if the mains power fails. 1. Key function Caller ID List the caller ID and missed call Phone book List the telephone numbers stored in the phone book Speak phone Speak phone on-off Speak volume control Increase or decrease speaker volume M1~ M6 Memory dial...

  • Page 3: Making Call

    INT/OK/power on-off Establish internal connection Confirm programming step. power on or off the feature phone Mute/C/Escape Mute key (Microphone OFF in conversation) Correct input error (Clear) Escape from programming menu Redial/Pause Redialing key, browsing of last dialed telephone Numbers by pressing the key repeatedly. Insert a pause for a phone book Number 2.

  • Page 4: Outgoing Call

    2-2 Adjust speak phone Volume You can adjust the speaker volume by pressing the volume increase key or pressing volume decrease key while on a call. 2-3 Outgoing Call 2-3-1 External call with normal dialing Go off hook or press the speak phone key first, and then enter the digits to be dialed.

  • Page 5: Three Way Conference

    2-4 Internal Calls between handsets (Only for two or more handsets) If you want to talk to another handset, take the following steps: Press the “ INT ” key Enter the number of the desired handset. When the called handset starts to ring, the y can go off hook or press Speak phone key to answer the incoming internal call.

  • Page 6: Call Duration Display

    2-7 Pause While entering a phone number you can add a pause to this number by pressing the pause key for connecting to PABX. It should not be the first digit of a telephone number. 2-8 Call Duration Display When the External/Internal call is finished, the call duration will be displayed for 3 seconds.

  • Page 7: Empty Battery

    2-12 Empty Battery When the battery is almost empty, you will hear a warning tone. The empty battery symbol will be displayed. 3. Menu and Function Setting You can set your phone book and/or program the feature phone by just scrolling through the menu.

  • Page 8: Phone Book Setting

    3-2 Phone Book Setting You can save 20 telephone numbers (25 digits) with name (12 letters) in the phone book. Phone book menu Scroll menu by pressing the Down key then press “OK” key while the cursor points to “Phone Book”. 3-2-1 To <ADD>...
  • Page 9 3-2-4 To <ERASE> the PHONEBOOK. Press “Down” key, as cursor points to “ Delete ” press “OK” key Press ” Down” key to find the telephone number to be deleted. Press “OK ”to confirm. Or give up by pressing Press “OK ” key, “ Are you sure? ” will be displayed for you to confirm Press “...
  • Page 10 3-3 Caller –ID/CLIP Function When the unit receives a phone call, the caller’s phone number is shown on the fea- ture phone’s display. The unit receives calls in FSK (name, telephone number, date and time of call) as well as in DTMF (telephone number only). If the caller number is blocked, you will see “PRIVATE”...
  • Page 11 3-5 feature phone Setting When you have multi handsets, every handset can be set individually programmed. Scroll menu by press “down” then press “OK” key while the display show “HS Setting”. 3-5-1 Set external ring melody and volume. As cursor points to “Set extring”, press “OK” key Press up/ down key to choose your preferred melody then press “OK”...
  • Page 12 3-5-5 Change Handset Pin Display shows your name and handset number Some setting are protected against unauthorized alternation via PIN (Personal Identification Number). You can set different PIN code in handset and base or make it the same. This PIN has 4 digits; the default Number from factory setting is 1590.
  • Page 13 Press “OK” for confirmation. 3-6 Base Setting (the following base operation guide is with base sta- tion of ARISTEL two line DECT PABX. If you are using other manufacturer’s DECT base station, please consult with the user manual for base setting).
  • Page 14 3-6-1 Change Dial mode Press “Down” key, as cursor points to “Dial Mode”, press “OK” key. Press “Down” key, move the cursor to DTMF Dial or PULSE Dial, then press “OK” key. Press “Up Down” key to select DTMF or PULSE then press “OK” key for confirmation.
  • Page 15 3-6-5 Call Barring You can set 5 groups of Nos. to bar out going calls. (1-5 digits for each group. For instance, long distance call 0011, mobiles 04, etc). You can also select each handset (HS1 – HS5) to belong to different barrier groups. Press “Down”...
  • Page 16 3-6-6 LCR Function The LCR function allows the User to choose the most economic carrier to make the call. You can set the provider prefix number in the handset and then dial out with your pre-determined code. Your feature phone will automatically put your provider prefix number in front of any dialed number.

  • Page 17: Select Base

    3-6-8 Set Base Default You can reset your base to the default status. Press “Down” key, as cursor points to “BS Default ”, for confirmation press “OK” key. 3-7 Select Base Handsets can be registered to 4 different base stations. When a handset is registered to several base stations, you can choose which base station you want to work with.
  • Page 18 How to register New Handset If you want to register a new feature phone on the base station or when you have to un-register a feature phone, the base station must be in registration mode. Please refer to the operation manual and set the base station in register mode. Press “Down”...
  • Page 19 Warning! This equipment will be inoperable if mains power fails. Aristel Networks Pty Ltd Unit 1, 25 Howleys Rd. Notting Hill. Victoria. 3168 Telephone: 03 8542 2300 Facsimile: 03 9544 3299 Version 1.1 January 2003...
