PRODUCT FEATURES
1. Selection of 420 and 520TV resolution and low light performance surveillance
camera with a built-in 1/3 type CCD
2. Integrated 3.6mm fixed lens
3. Outstanding 0.15/0.30 lux performance with built-in 24 LEDs.
4. Photocell activates IR light at night.
5. Compact and light weight
6. Designed for indoor or outdoor use
SAFETY PRECAUTIONS
5. The installation should be made
by qualified service engineers
and should conform to all local
codes.
6. To prevent fire or electric shock,
do not expose the camera to rain
or moisture.
7. To prevent fire or electric shock,
UL listed wiring should be used
for the DC 12V input.
8. Use only DC 12V regulated
power supply marked class 2.
9. Never attempt to disassemble or
modify the camera.
OUTDOOR IR COLOR CAMERA
MODEL: BC-IR3.6N / BCH-IR3.6N
1. Be sure to connect each lead to the
appropriate
connection may cause damage to
the camera.
2. Do not attempt to aim the camera
at the sun or other extremely
bright objects.
3. Do not allow the camera to be
subject to unstable location, strong
shocks and vibration, and strong
electromagnetic field.
4. If
any
immediately turn off the power
and consult your dealer.
1
terminal.
Wrong
abnormality
occurs,
