Checking after the installation

After installing the device and the driver, the following are installed on your computer
and can be checked:
Taskbar
- Direct Scan icon in the right-hand corner of the Windows taskbar. This icon is not
displayed in Windows XP. In Windows XP, this function is integrated with the
Scanner and Camera Wizard.
'Start – Settings – Control Panel'. Double-click on the 'System' icon and select the
'Device Manager' tab.
- Imaging Devices – Trust Direct Webscan 19200
'Start – Settings – Control Panel' and then double-click on the 'Add/Remove
Programs' icon.
- Trust Direct Webscan 19200
Start - Programs - Trust - Direct Webscan 19200
- 'Help': help function for the scanner and the Direct Scan software.
- 'Direct Scan' icon: click on the Direct Scan icon in the right-hand corner of the
Windows taskbar to use the scan buttons. This icon is not displayed in Windows XP.
In Windows XP, this function is integrated with the Scanner and Camera Wizard.
- 'Panel' icon: opens the 'Direct Scan' panel.
- 'Scanner Settings' icon: opens the settings window for the Direct Scan panel.
- 'Uninstall Direct Webscan': removes the TWAIN driver and the applications.
Note: The information given above will vary when the installation has been
altered by the user (for example, not everything has been installed or
locations other than the default locations have been selected).
Note: Deviations may also occur as a result of using new drivers available on
the Internet.
Note: The location or name may vary in the 'Control Panel' for different
operating systems.
6

Using the scanner

Scans can be made in two different ways using the Trust Direct Webscan 19200,
namely via the Direct Scan application (the easiest way) or via the TWAIN interface
window (more options). See the chapters below for instructions on how to use the
scanner.
6.1 Direct Scan application
The Direct Scan application is the easiest way to scan. With one touch of the buttons
on the scanner, you can scan a photograph or document and open it in a photo
editing program (Photo Express), send it by fax, print it or send it via e-mail. Follow
the instructions given below.
1. After the software has been installed, a Direct Scan icon will be included in the
Windows taskbar. If this icon is not visible, click on 'Start – Programs – Trust -
Direct Webscan 19200' and select 'Direct Scan' from the menu. The scanner
buttons can now be used to make a scan.
Note: The Direct Scan icon is not included in the taskbar in Windows
XP. The Direct Scan function is integrated in the Windows XP
Scanner & Camera Wizard.
Note: You must have installed Photo Express on your computer to be
able to scan directly to this application. See chapter 4 for more
information.
Note: If there is a cross through the Direct Scan icon, then the scanner
has not been connected correctly. Check the USB connection
and, if necessary, restart your computer.
