- Page 1 Easy Connect 9600 Plus Easy Connect 9600 Plus User Manual Version 1.0...
- Page 2 Easy Connect 9600 Plus Copyright Statement No part of this manual may be reproduced or transmitted, in any form or by any means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, for any purpose other than the purchaser's personal use, without the prior written permission of the manufacturer.
-
Page 3: Table Of Contents
Easy Connect 9600 Plus Contents 1. Introduction..................2 1.1 Conventions ................2 1.2 Contents ..................2 1.3 Minimum system requirements ..........3 2. Safety ..................... 4 3. Connection..................5 4. Installation of the TWAIN driver and the software...... 6 4.1 TextBridge Classic 1.1 ............... 7 4.2 Ulead iPhoto Plus 4 .............. -
Page 4: Introduction
Easy Connect 9600 Plus 1. Introduction This manual is intended for users of the Easy Connect 9600 Plus scanner. No specific prior knowledge is needed to install and use this product. This scanner will only work with Windows 95 / 98 and Windows NT 4.0. -
Page 5: Minimum System Requirements
Easy Connect 9600 Plus 1.3 Minimum system requirements Compatible PC with 80486 CPU and 8 MB RAM Microsoft Windows 95 / 98 or Windows NT 4.0 Printer port (EPP) Hard disk with at least 60 MB free space (for installation) -
Page 6: Safety
Easy Connect 9600 Plus 2. Safety Read the following instructions carefully before use: Remove the power plugs from the power sockets before cleaning the equipment. Do not use this equipment in damp environments such as bathrooms, damp basements, swimming pools, etc. -
Page 7: Connection
Easy Connect 9600 Plus 3. Connection Note: Turn off the computer before connecting peripheral devices. Follow these steps to connect the scanner to your computer: Turn off the computer and all peripheral devices. Remove the printer cable plug, if there is one, from the parallel port at the back of your computer. -
Page 8: Installation Of The Twain Driver And The Software
Easy Connect 9600 Plus 4. Installation of the TWAIN driver and the software All the files needed for the installation of the drivers and the application software are on the CD. Note: The following notation has been used in the examples: hard disk is drive ’C:’, CD-ROM player is drive ‘D:’. -
Page 9: Textbridge Classic 1.1
Easy Connect 9600 Plus Select ‘Typical’ to install all the components. Click on ‘Next’. To continue installation follow the instructions on the screen. 4.1 TextBridge Classic 1.1 The installation of the ‘Textbridge Classic’ OCR program is part of the total installation and will be done automatically. -
Page 10: Ulead Iphoto Plus 4
Easy Connect 9600 Plus Figure 5: Selecting the input device Select the ‘Trust Easy Connect 9600 Plus’ from the list and click on ‘Select’. A window such as Figure 6 will appear. Figure 6: Finishing installation Click on ‘End’ to complete the installation. - Page 11 Easy Connect 9600 Plus Follow the instructions on the screen to continue installation. Select ‘Yes’ when asked if you want to install the Acrobat Reader. Click on ‘Accept’ to accept the license agreement. Click on ‘Install’ to install the program in the directory indicated.
-
Page 12: Scanning
Easy Connect 9600 Plus 5. Scanning You can scan in two ways with this scanner. The first method, via the scan dialog box is fast and easy (see chapter 5.1). The second method, via the TWAIN dialog box, offers you more facilities (see chapter 5.2). - Page 13 Easy Connect 9600 Plus Scan window Set up: the image or document to the selected application. Copy window Set up: print the image or document on the connected printer. (Printer required) Fax window Set up: send the image or document per fax.
-
Page 14: Twain Dialog Box
Easy Connect 9600 Plus 5.2 TWAIN dialog box You can open the TWAIN dialog box by scanning in a TWAIN- compatible application. You can read about how to select the scanner and how to start TWAIN in the manual belonging to the application you are using. -
Page 15: Enhance Tab
Easy Connect 9600 Plus Descreen Elimination of moiré patterns in print work. Help Shows a list of detailed subjects Language Select the language you want to see on the screen. Exit Close the program. With the ‘PreScan’ button you can make a pre-scan of the image or document at a low resolution. -
Page 16: Making A Scan
Easy Connect 9600 Plus 5.3 Making a scan Carry out the following steps to make a scan. Place the image or document on the glass plate facing downwards. Click on the ‘PreScan’ button with the mouse. Set the required scan mode (colour, grey, black and white). -
Page 17: Ulead Iphoto Plus 4
Start the Ulead iPhoto Plus program. Select ‘File’. Select ‘Acquire’ and choose ‘Select Source’ (see Figure 9). Now select ‘Trust Easy Connect 9600 Plus’ (see Figure 10) and click on ‘OK’. Ulead iPhoto Plus 4.0 is now correctly set up for your scanner. -
Page 18: Starting The Twain Program
Easy Connect 9600 Plus 6.2 Starting the TWAIN program You need the TWAIN program in order to scan images. Start the Ulead iPhoto Plus program. Click on ‘Start’ (see Figure 11, option 1). Click on ‘Scan’ (see Figure 11, option 2). - Page 19 Easy Connect 9600 Plus Figure 12: Dialog box Aquire Image in Ulead iPhoto Plus 4.0...
-
Page 20: Working With Textbridge
Easy Connect 9600 Plus 7. Working with TextBridge TextBridge is a program for scanning and converting text. The scan result can be processed in a word processor. You will find an extensive manual for the program on the CD-ROM. 7.1 Setting up the scanner The scanner was configured for the use of the software during the installation of the application. - Page 21 Easy Connect 9600 Plus In order to process the scanned text which you have just saved, you need a word processor. Enter the name of the file as you saved it at step 12. TextBridge also has more advanced options. Look in the on-line help...
-
Page 22: Maintenance
Easy Connect 9600 Plus 8. Maintenance Clean the glass plate regularly with a soft, clean cloth to remove dust and anything else which shouldn’t be there. A clean glass plate is important because specks will be visible on the scanned image. -
Page 23: Troubleshooting
You can easily test the basic functions of the scanner using this test program. Start the test program (Start | Programs | Trust Easy Connect 9600 Plus | Test Program). The test program appears on the screen (see Figure 13). - Page 24 Easy Connect 9600 Plus Symptom Possible cause Solution Scan too dark. Monitor too dark. Change the brightness of the monitor. Number of colours too Set your screen low on VGA card. adapter to a minimum of 65,535 (16 bit) colours.
- Page 25 Easy Connect 9600 Plus Symptom Possible cause Solution Error message Hard disk full. You need three times during scanning. the size of the image to be scanned as available hard disk space. The required space is shown in the TWAIN window. Free space or choose a lower resolution.
- Page 26 Connect the power has come loose. supply adapter (see chapter 3). Check the Internet (www.trust.com) for the FAQ’s and for the latest version of the driver. Please contact your dealer if you still have problems after you have tried these solutions.
-
Page 27: Specifications
Easy Connect 9600 Plus 10. Specifications Type Flatbed, CIS scanner Optical resolution (H x V) 300 x 600 DPI Maximum resolution through 9600 x 9600 DPI interpolation Scan mode 1 bit black and white 10 bit grey value 30 bit colour...
