Easy Scan 19200

Easy Scan 19200
User's Manual
Version 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easy Scan 19200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trust Easy Scan 19200

Summary of Contents for Trust Easy Scan 19200

  • Page 1: Easy Scan

    Easy Scan 19200 Easy Scan 19200 User’s Manual Version 1.2...
  • Page 2 Easy Scan 19200 Copyright Without the written consent of the manufacturer it is prohibited to reproduce or transfer any part of this manual in any format, either electronically or mechanically, as photocopy or recording, in information or search systems, other than for personal use by the purchaser.
  • Page 3 Easy Scan 19200 Preface This manual is for users of the Easy Scan 19200. No specific knowledge is required for installation or operation of this product. This user’s manual uses the following conventions for commands: ‘Configuration screen’ Software term, shown on the screen.
  • Page 4 Easy Scan 19200 Blank Page...
  • Page 5 Easy Scan 19200 Contents 1. Introduction..................1 2. Safety First..................2 3. Installing the scanner ..............3 3.1 Contents of the packaging ............3 3.2 Transport safety catch ............... 3 3.3 Connection................. 3 4. Software installation ..............6 4.1 Installing the TWAIN driver ............6 4.1.1 Windows 3.1x .................
  • Page 6 Easy Scan 19200 6.2.1 Setting up the scanner ............20 6.2.2 Scanning with TextBridge Classic ......... 20 7. Working with PaperCom ............22 8. Maintenance................. 23 9. Troubleshooting ................24 Appendix A: Technical Specifications........... 27...

  • Page 7: Introduction

    Easy Scan 19200 1. Introduction The scanner can be used to scan texts and images. The bundled software enables the scanned images to be edited. Take time to read this manual thoroughly so that you can make optimal use of the scanner’s features.

  • Page 8: Safety First

    Easy Scan 19200 2. Safety First Please read the following instructions carefully: Remove the plugs from the sockets before cleaning the equipment. Do not use liquid cleaning agents or spray cans. Wipe off the equipment with a damp cloth. Do not use this equipment in damp environments such as in bathrooms, damp cellars or at swimming pools etc.

  • Page 9: Installing The Scanner

    Easy Scan 19200 3. Installing the scanner 3.1 Contents of the packaging After unpacking you should have the following items: • Scanner • Mains adapter • Interface cable • CD with drivers and applications • User’s guide Contact your dealer if anything is missing or damaged.
  • Page 10 Easy Scan 19200 Proceed as follows to connect the scanner to your PC: Switch off the computer and all the peripherals connected. Unplug the printer cable from the parallel port on the rear panel of your computer. Connect the printer cable to the ‘Printer’ connection on the rear panel of the scanner.
  • Page 11 Easy Scan 19200 Figure 2: Connecting the scanner, printer and PC Scanner Mains adapter Scanner cable Computer Printer cable...

  • Page 12: Software Installation

    Easy Scan 19200 4. Software installation All the files required to install the drivers and the application software are on the CD. Note: It is assumed in the examples that your computer uses the following drive designations: drive ‘C:’ for the hard disk and drive ‘D:’...

  • Page 13: Windows 95 / Windows Nt

    Easy Scan 19200 Figure 4: Starting installation under Windows 3.1x Click on ‘Scanner Driver’. The ‘Select Model’ window will appear. Click the button of the 19200 Easy Scan. In the menu select the language you want to use and follow the instructions on the screen.

  • Page 14: Installing Mgi Photosuite Se

    Easy Scan 19200 Figure 6: The main screen for the scanner set-up In the menu select the language you want to use and follow the instructions on the screen during installation. Restart the computer once installation of the TWAIN driver is complete.

  • Page 15: Windows 95 / Windows Nt

    Easy Scan 19200 Follow the instructions on the screen. Installation takes a few minutes. Now go to the ‘Installing TextBridge’ chapter. 4.2.2 Windows 95 / Windows NT Note: The MGI PhotoSuite program can also be installed by starting the program [D:\editor\ieditor.exe] .

  • Page 16: Windows 95 / Windows Nt

    Easy Scan 19200 Click on ‘Install Application’. A new window will be visible. Click ‘Xerox TextBridge’. The TextBridge installation window is displayed. Select the language you wish to use during installation and click ‘OK’. A TextBridge 3.0 OCR installation screen appears.
  • Page 17 ‘TWAIN’ and ‘Continue’. See figure 7. A window showing the available TWAIN drivers is displayed. Figure 7: Selecting the input equipment 13. Select ‘Trust Easy Scan 19200 / 32’ from the list and click ‘Select’. A window as in figure 8 is displayed. Figure 8: Finish installation...

  • Page 18: Installing Papercom

    Easy Scan 19200 4.4 Installing PaperCom Note: PaperCom does not run under Windows NT 4.0 PaperCom is an application with which you can process a piece of text or an image from a single menu with the scanner. 4.4.1 Windows 3.1x Restart Windows 3.1x.
  • Page 19 Easy Scan 19200...

  • Page 20: Working With Mgi Photosuite Se

    Easy Scan 19200 5. Working with MGI PhotoSuite SE 5.1 Once-only set-up Proceed as follows to set up MGI PhotoSuite SE for the scanner: Start ‘MGI PhotoSuite SE’. A window as in figure 9 appears. Figure 9: The location of the ‘Work on your own’...

  • Page 21: Scanning With Mgi Photosuite Se

    Easy Scan 19200 From the list select the Trust Easy Scan 19200/16 if you are running Windows 3.1x or the Trust Easy Scan/32 if you are running Windows 95 or NT4. Then click ‘Select’. You can now use your scanner in MGI PhotoSuite SE. The scanner only has to be set up once.
  • Page 22 Easy Scan 19200 Figure 11: Positioning a document (1 = reference point) Figure 12: TWAIN window...
  • Page 23 Easy Scan 19200 Scanning source: Flatbed or transparency Number of colours: a) Line-Art: black-and-white scanning, to use with an OCR program such as TextBridge. b) Diffusion: black-and-white scanning, with the transition between black and white being spread with small dots. Use this for black-and-white photos if you need to restrict the space they take up on the disk.

  • Page 24: Working With Textbridge

    Then click ‘File’. Select ‘Select Source...’. See figure 13. Figure 13: Scanner set-up Select ‘Trust Easy Scan 19200/16’ and click ‘Select’. Your TextBridge is now ready to use. 6.1.2 Producing a scan with TextBridge 3.0 OCR Start ‘TextBridge’ by double-clicking the icon. A screen such as in...
  • Page 25 Easy Scan 19200 Figure 14: TextBridge 3.0 OCR for Windows 3.1x Under ‘Input From’ you must select ‘Scanner’. Deactivate the ‘Save Page Images’ option. Click ‘GO!’ to scan the text. The TWAIN window (see figure 12) now appears. Click ‘Preview’ to produce a test scan first.

  • Page 26: Textbridge Classic For Windows 95

    Easy Scan 19200 To edit the scanned text that you have just saved you must open a text editor, for example ‘Notepad’. You can also use your own text editor or word processor. 6.2 TextBridge Classic for Windows 95 6.2.1 Setting up the scanner The scanner was already set up to use the software during installation of the application.
  • Page 27 Easy Scan 19200 13. Close TextBridge Classic. To be able to edit the scanned text you have just been saved you, you need a text editor or /word processor. Enter the name of the file that you saved in item 12.

  • Page 28: Working With Papercom

    Easy Scan 19200 7. Working with PaperCom Note: PaperCom does not run under Windows NT 4.0 PaperCom gives you fast access to the scanner’s many functions. You are hardly required to make any settings. Once PaperCom is running, a window as in figure 16 is displayed.

  • Page 29: Maintenance

    Easy Scan 19200 8. Maintenance Clean the glass plate regularly with a soft, clean cloth to remove dust and other marks. A clean glass plate is important because marks can be seen in the scanned image. Observe the following safety measures when cleaning the equipment: Remove the plugs from the sockets before cleaning the equipment.

  • Page 30: Troubleshooting

    Easy Scan 19200 9. Troubleshooting Problem Possible cause Solution Scan too dark. Scanner not yet Let the scanner warm up warmed up. for a few minutes before scanning. Monitor too dark. Change the monitor brightness. Brightness in the Set the brightness of the TWAIN incorrectly TWAIN driver.
  • Page 31 Use a separate printer accordance with card. GUI principle. Connect your printer directly to the parallel port when you wish to print. If you are still having problems with your scanner after having tried these solutions, contact your dealer or the Trust helpdesk.
  • Page 32 Easy Scan 19200 Before contacting your dealer or the Trust Helpdesk, ensure that you have the following information on hand. Serial number of the scanner Model number of the scanner Operating system Hardware configuration: a) CPU (MHz) b) Memory (MB)

  • Page 33: Appendix A: Technical Specifications

    Easy Scan 19200 Appendix A: Technical Specifications Type Flatbed Optical resolution (H x V) 600 x 1200 optical Maximum resolution (H x V) 19200 x 19200 dpi • 1 bit black-and-white Scanning method • 10 bit grey scale • 30 bit colour •...
