TRUST COMPACT SCAN USB 19200
1
Introduction
This instruction manual is intended for users of the 'Trust Compact Scan USB 19200'.If you have
any questions, please contact one of the Trust Customer Care Centers. You can find more
information at the back of this instruction manual.
This instruction manual describes how to install the software and how to solve any problems
which may be encountered during the installation.
1.1
Conventions
This manual uses the following layout conventions for instructions:
<key>
Requires the user to press a key. The key legend is shown between
the angle brackets.
'System'
This is a software-specific term, e.g. a term used by Windows.
[DIR]
Text in this font is to be typed by the user.
(Term)
The text between the parentheses (....) is the English term, e.g.
(File), referred to in the accompanying illustration.
Additional information is shown as follows:
Note:
If you connect the scanner to a USB-HUB, the USB-HUB should have its own
power supply.
The examples given assume that the letter "D" has been assigned to your CD-ROM station. If
your system uses a different letter for your CD-ROM drive, such as "E", you should replace the
drive letter "D" in the text with "E".
1.2
Contents of the package
Check the contents of the package before reading the User's manual. You should have the
following items:
•
Scanner;
•
CD-ROM with drivers and applications;
•
CD-ROM with PhotoExpress 3.0;
•
This manual.
Please contact your dealer if anything is missing or damaged.
1
UK

Advertisement

loading
Need help?

Need help?

Do you have a question about the Compact Scan USB 19200 and is the answer not in the manual?

Questions and answers

Related Manuals for Trust Compact Scan USB 19200

Summary of Contents for Trust Compact Scan USB 19200

  • Page 1 TRUST COMPACT SCAN USB 19200 Introduction This instruction manual is intended for users of the ‘Trust Compact Scan USB 19200‘.If you have any questions, please contact one of the Trust Customer Care Centers. You can find more information at the back of this instruction manual.

  • Page 2: Quick Installation

    Select in the left window the language that you wish to use during the installation. See figure 1. Click on the button ‘Compact Scan USB 19200’ to start the installation of the TWAIN steering program. Follow the directions on the screen.
  • Page 3 Your scanner is now ready for use. Use of the Scanner You can scan in two ways with the Trust Compact Scan USB 19200, namely via de Direct Scan application (easiest) and via the TWAIN interface screen (more possibilities). The easiest way to scan is described below: After the installation of the software, a ‘Direct Scan’...

  • Page 4: Acrobat Reader

    TRUST COMPACT SCAN USB 19200 Button Function Description Scan Scans the image and sends this directly to the application Photo Express, in which the image can be processed and stored in the computer. Copy Scans the image and sends this directly to your printer. A new screen appears in advance on which you can adapt various set- ups.

  • Page 5: Troubleshooting

    TRUST COMPACT SCAN USB 19200 Printing the manual Click the ‘Print’ option in the ‘File’ menu (See Figure 3). Adjust the settings if necessary. Click on ‘OK’ to print the document. Troubleshooting Problem Cause Possible solution Scanner does not work...
  • Page 6 TRUST COMPACT SCAN USB 19200 Problem Cause Possible solution Computer jams up on use USB scanner has conflicts Set the other equipment on another of USB. with other USB equipment. address in the BIOS of the computer or disconnect them.
  • Page 7 If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centers. You can find more information at the back of this instruction manual. Please have the following information available: •...
  • Page 8 TRUST COMPACT SCAN USB 19200 • Version of TWAIN interface (see readme.txt on the CD-ROM) Name and version of the application software • A good description of exactly what does not work. • A good description of exactly when the problem arose.
