Easy Scan 9600 Plus
Easy Scan 9600 Plus
User's Manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easy Scan 9600 Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trust Easy Scan 9600 Plus

Summary of Contents for Trust Easy Scan 9600 Plus

  • Page 1 Easy Scan 9600 Plus Easy Scan 9600 Plus User’s Manual Version 1.0...
  • Page 2 Easy Scan 9600 Plus Copyright Statement No part of this manual may be reproduced or transmitted, in any form or by any means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, for any purpose other than the purchaser's personal use, without the prior written permission of the manufacturer.

  • Page 3: Table Of Contents

    Easy Scan 9600 Plus Table of Contents 1. Introduction..................2 1.1 Conventions ................2 1.2 Contents ..................2 1.3 Minimum system requirements ..........3 2. Safety ..................... 4 3. Connecting..................5 4. Installing the software..............6 4.1 Installation of the TWAIN program..........6 4.2 Installation of TextBridge............

  • Page 4: Introduction

    Easy Scan 9600 Plus 1. Introduction This manual is intended for users of the Easy Scan 9600 Plus scanner. No specific knowledge is required for installing or using this product. The scanner works only under Windows 95/98 and Windows NT 4.0.

  • Page 5: Minimum System Requirements

    Easy Scan 9600 Plus 1.3 Minimum system requirements • Compatible PC with an 80486 CPU and 8 MB RAM • Microsoft Windows 95/98 or Windows NT 4.0 • Printer port (EPP) • Hard disk with at least 60 MB of available hard-disk space (for installation) •...

  • Page 6: Safety

    Easy Scan 9600 Plus 2. Safety Read the following instructions thoroughly before using the product: Remove the plugs from the outlet before cleaning the device. Do not use any cleaning fluids or spray cans to clean the product. Wipe off the device with a damp cloth.

  • Page 7: Connecting

    Easy Scan 9600 Plus 3. Connecting Note: Turn off the computer before you connect any peripheral equipment. Follow the instructions below to connect the scanner to your computer: Turn off the computer and all its peripheral equipment. Remove the plug of the printer cable from the parallel port (if present) located on the back of your computer.

  • Page 8: Installing The Software

    Easy Scan 9600 Plus 4. Installing the software All files required for installing the drivers and applications are on the CD-ROM. Note: The following drive letters are used in the examples: Hard disk: driver ’C:’, CD-ROM player: driver ‘D:’ Substitute these letters if your system uses different ones.
  • Page 9 ‘TWAIN’ and ‘Continue’ (see Figure 4). A window containing the present TWAIN drivers will appear. Figure 4: Selecting the device for input Choose ‘Trust Easy Scan 9600 Plus’ from the list and click ‘Select’. A window will appear as in Figure 5.

  • Page 10: Installation Of Adobe Photo Deluxe

    Easy Scan 9600 Plus Figure 5: Completing the installation 10. Click ‘End’ to complete the installation. After Text Bridge Classic has been installed, you can install Adobe Photo Deluxe, which has been supplied on a separate CD-ROM. 4.3 Installation of Adobe Photo Deluxe Adobe Photo Deluxe is a program used to scan and edit images.

  • Page 11: Working With The Scanner

    Start the application software; e.g. Adobe PhotoDeluxe. Click ‘Acquire’ in the ‘File’ menu. Click ‘Select TWAIN source...’ Select the relevant scanner (Trust Easy Scan 9600 Plus V2.0) from the list that appears, and click ‘Select’. Click ‘Acquire’ in the ‘File’ menu and select ‘TWAIN’.

  • Page 12: The Twain Program

    Easy Scan 9600 Plus 5.2 The TWAIN program The TWAIN program consists of 3 tabs: Main Advanced Preferences 5.2.1 Main This main functions needed in order to be able to work with the scanner are displayed here. Figure 6: The main window...
  • Page 13 Easy Scan 9600 Plus Function Tabs used to move between the different windows. • Main: This window contains the main functions for scanning. • Advanced: This window contains the same functions as the Main window but also includes correction functions.

  • Page 14: Advanced Window

    Easy Scan 9600 Plus Sets destination • Send to Application: The scanned image is copied to your application software (works only if you scan from an application (e.g. TextBridge)). The remaining options work if you have started the TWAIN program from the start menu.

  • Page 15: Preferences Window

    Easy Scan 9600 Plus Function Zoom: Magnifies scanning area. Mirror: Flips scanning area. Invert: Sets inversion. Descreen: Eliminates moiré patterns in the printed matter. Gamma: Sets gamma. HSV: Sets colour, tone and saturation Tone adjustment: Edits colours Auto Color Control: Automatic setting Special Effect: Initiates special effects.

  • Page 16: Using The Scan Key

    The scan key is located on the front of the scanner (see Figure 9). Follow the instructions below to scan with the scan key: Start the program ‘Trust Easy Scan 9600 Plus’. See Chapter 5.1.1. Find the auto-scan key on the front of the scanner (Figure 9, Key Press button (A).

  • Page 17: Working With Adobe Photodeluxe

    Click ‘File’, select ‘Open Special’ and then select ‘Scan Photo...’ (See Figure 10). Figure 10: Selecting and starting TWAIN Select ‘Trust Easy Scan 9600 Plus’ from the window. Click ‘OK’. The scanner is now set for use. 6.2 Scanning with Adobe PhotoDeluxe Start the ‘Adobe PhotoDeluxe’...
  • Page 18 Easy Scan 9600 Plus Click ‘Scan’. After scanning is completed, the image is transported to Adobe PhotoDeluxe. When the scanner is finished scanning, click ‘Exit’ to return to Adobe PhotoDeluxe. You can now edit the image. This was a brief introduction to the program. Consult the program’s Help facilities (‘?’) for more information.You will find a manual for the...

  • Page 19: Working With Textbridge

    Easy Scan 9600 Plus 7. Working with TextBridge TextBridge is a program used to scan text and to edit it in a word processor. You will find an extensive manual for the program on the CD-ROM. 7.1 Setting the scanner The scanner is adjusted for using the software during the installation of the application.
  • Page 20 Easy Scan 9600 Plus TextBridge also has more advanced options. Look in the on-line help and the documentation on the CD-ROM for more information.

  • Page 21: Troubleshooting

    Easy Scan 9600 Plus 8. Troubleshooting Problem Cause Possible solution The window ‘Cannot Interface cable is Connect the interface cable operate!’ appears. not connected. properly (Chapter 3). Power supply Connect the power supply adapter is not adapter properly connected. (Chapter 3).
  • Page 22 Choose 300 DPI maximally high. when scanning an A4- format document. Too large a surface Choose 4800 or 9600 DPI is selected. only for small originals (5x5 mm). Check the FAQ and the latest version of the driver at www.trust.com on the Internet.
  • Page 23 Easy Scan 9600 Plus Contact your dealer if you are still having problems with your scanner after having tried these solutions. Have the following information ready: 1. Operating system 2. Hardware configuration CPU (MHz) Memory (MB) Available free space on hard disk (MB) Display adapter: resolution and number of colours 3.

  • Page 24: Specifications

    Easy Scan 9600 Plus 9. Specifications Type Flatbed, CIS scanner Optic resolution (H x V) 300 x 600 DPI Maximum resolution by 9600 x 9600 DPI interpolation • 1 bit black/white Scanning method • 10 bit grey value • 30 bit colour...
