TRUST COMPACT SCAN USB 19200
Instruction Manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 19200 and is the answer not in the manual?

Questions and answers

Related Manuals for Trust 19200

Summary of Contents for Trust 19200

  • Page 1 Trust Compact Scan USB 19200 TRUST COMPACT SCAN USB 19200 Instruction Manual Version 1.0...
  • Page 2 Trust Compact Scan USB 19200 Thank you Thank you very much for purchasing this product from the Trust range. We wish you hours of fun with it. Please read this manual carefully before using the product. Registration Register your purchase now at the Trust Internet site www.trust.com, so that you are able to receive optimal guarantee and service support.

  • Page 3: Table Of Contents

    Installatie TWAIN steering program ..................4 Installation Fine Reader 4.0 Sprint ..................7 Installation Photo Express 3.0....................10 Connecting Compact Scan USB 19200 to your PC ............13 Use of the Scanner ........................13 Direct Scan application ......................13 TWAIN interface screen......................15 TWAIN settings........................

  • Page 4: Introduction

    Trust Compact Scan USB 19200 1. Introduction This instruction manual is intended for users of the Trust Compact Scan USB 19200. Some experience with computers is necessary when installing this product. In case of doubt consult one of the Trust Customer Care Centres.

  • Page 5: Safety

    Trust Compact Scan USB 19200 2. Safety Read the following instructions carefully before use: Do not use this equipment in humid environments like bathrooms, humid cellars, swimming pools, etc. Never insert objects into the openings on the outside of the device as you can come into contact with live electrical components.

  • Page 6: Installation

    Select in the left window the language that you wish to use during the installation. See figure 2. Click on the button ‘Compact Scan USB 19200’ to start the installation of the TWAIN steering program. Select the preferred language version of the TWAIN steering program and click on ‘OK’.
  • Page 7 Trust Compact Scan USB 19200 Figure 3: installation of TWAIN steering program Indicate the location where you want to install the steering programme (if necessary) and click on ‘Next’. See figure 4. Figure 4: indicating location of steering program 10. Ensure that both options in the next screen are ticked and click on ‘Next’. See figure 5.
  • Page 8 Trust Compact Scan USB 19200 Figure 5: select necessary components 11. Indicate the location on which the program icons are to be placed (if necessary) en click on ‘Next’. See figure 6. Figure 6: indicate location of program icons 12. Click on ‘Start Install' to copy the files to the location indicated. See figure 7.

  • Page 9: Installation Fine Reader 4.0 Sprint

    CD-ROM. Follow the directions below for the installation: Follow steps 1 to 5 of chapter 3.1 once again to start the Trust Software Installer. Click on the ‘Fine Reader 4.0 Sprint’ to start the installation.
  • Page 10 Trust Compact Scan USB 19200 Click on ‘Agreed’ to accept the licensing agreements and to continue the installation. Fill-in your name and in appropriate your company name and click on ‘Next’. See figure 10. Figure 10: complete personal details Click again on ‘Next’ to confirm your details.
  • Page 11 Trust Compact Scan USB 19200 Figure 12: indicate location of program files Click again on ‘Next’ to confirm the indicated location. 10. Click on ‘Go’ to copy the program to the location indicated. See figure 13. Figure 13: start copying the files 11.

  • Page 12: Installation Photo Express 3.0

    Trust Compact Scan USB 19200 12. You have completed the installation. Click on ‘OK’ to close down the installation. Installation Photo Express 3.0 Ulead Photo Express 3.0 is a drawing and processing program with a large number of options. You can use this program to process photographs.
  • Page 13 Trust Compact Scan USB 19200 If desired, indicate a location on which Photo Express is to be installed and click on ‘Next’. See figure 17. Figure 17: indicate location of program files Click on the button 'Typical' to install the desired program components. See figure 18.
  • Page 14 Trust Compact Scan USB 19200 Figure 19: indicate location of program icons 10. Click again on ‘Next’ to confirm all settings. 11. After installation, switch to the option ‘Register Online' to skip the registration and click on ‘Finish’ to round off the installation. See figure 20.

  • Page 15: Connecting Compact Scan Usb 19200 To Your Pc

    4. Use of the Scanner You can scan in two ways with the Trust Compact Scan USB 19200, namely via de Direct Scan application (easiest) and via the TWAIN interface screen (more possibilities). See chapters below for use of the scanner: Direct Scan application The ‘Direct Scan’...
  • Page 16 Trust Compact Scan USB 19200 Figure 22: Direct Scan application Lay an picture with the part to be scanned on the glass plate and close the lid. Click on one of the buttons of the Direct Scan application to scan the picture and transmit it to the indicated location.

  • Page 17: Twain Interface Screen

    Start the program ‘Ulead Photo Express’. The once only ‘Device Type’ screen appears. Choose the option ‘Flatbed scanner’ to select the Trust compact Scan USB 19200 and click on ‘OK’. See figure 23. Figure 23: select scanner The main screen of Photo Express appears.
  • Page 18 Figure 24: Call-up Scanner in Photo Express A number of scanner options appear in the right hand window of Photo Express. At ‘Select data source’ (A) choose the ‘Trust Compact Scan USB 19200’. See figure 25. Figure 25: activate scanner...
  • Page 19 Trust Compact Scan USB 19200 At ‘File name’ (B), indicate a name for the picture to be scanned. See figure 25. At ‘File type’ (C), indicate a file format for the picture to be scanned. See figure 25. Click on the button ‘Acquire’ (D) to call up the TWAIN interface screen of the scanner. See figure 25.
  • Page 20 Trust Compact Scan USB 19200 Figure 27: process the scanned picture 12. Click on the button ‘Share’ and select the option ‘Save’ to store the picture. See figure 28. Figure 28: store the scanned picture 13. In the right window of Photo Express indicate the location (A), file name (B) and file format (C)and click...
  • Page 21 Trust Compact Scan USB 19200 Figure 29: details of picture You have finished making your scan.

  • Page 22: Twain Settings

    Trust Compact Scan USB 19200 TWAIN settings There are a number of buttons in the TWAIN interface screen (see figure 26). See table below for a description of the buttons: Button Function Cropping Tool Select the field in the example window.

  • Page 23: Scan Mode Settings (Main)

    Self determine the scan field in the selection window. Resolution 50 - 19200 select resolution settings. Custom Independently input a resolution between 50 and 19200 DPI. (only whole numbers) De-screen None No de-screen pattern set Newspaper De-screen pattern set for newspaper Magazine De-screen pattern set for magazine / print- work.

  • Page 24: Advanced Settings (Enhance)

    Trust Compact Scan USB 19200 4.3.2 Advanced Settings (Enhance) Figure 30: Advanced settings The 'Enhance; Advanced Settings' file contains settings that you can adapt to the depicting of the original, before you finally make the scan. This file contains also two small images of the trail scan. All the changes that are made in the file are visible in the right-hand image.

  • Page 25: Image Settings (Filters)

    Trust Compact Scan USB 19200 4.3.3 Image Settings (Filters) Figure 31: image settings The "Filters; Image Settings" file contains settings with which you can obtain special effects. At the same time, this file contains 2 small images of the trial scan. The selected effect is visible in the right-hand picture.

  • Page 26: Troubleshooting

    Trust Compact Scan USB 19200 6. Troubleshooting Problem Cause Possible solution Scanner does not Scanner has been connected Remove the scanner from the USB port, install first work after to the USB port of the the TWAIN steering program and the applications,...
  • Page 27 Trust Compact Scan USB 19200 Problem Cause Possible solution Scanner works A very high resolution set. In practice, a resolution of maximum 600dpi is slowly. sufficient. Use higher resolutions only for small original images. Insufficient memory. You need a minimum of 16MB in RAM-memory.
  • Page 28 If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centers. You can find more information at the back of this instruction manual. Please have the following information available: •...

  • Page 29: Specifications

    Trust Compact Scan USB 19200 7. Specifications Type Flatbed, CIS scanner Optical resolution (H x V) 600 x 1.200 DPI Maximum resolution 19.200 x 19.200 DPI Scan Method Single Pass Scan indications • 1 bit black-white • 12 bit grey value •...

  • Page 30: Trust Customer Care Centers

    Trust Compact Scan USB 19200 8. Trust Customer Care Centers Inhabitants of Great Britain and Ireland should contact: GB Office From: Internet www.trust.com 9:30 - 17:00 E-mail support-uk@trust.com +44-(0)1376-514633 Tel. +44-(0)1376-500000 Inhabitants of Italy should contact: Italian Office From: Internet www.trust.com...
