User´s Manual
To a Remote TV through VCR
TV
IN
RF IN
VIDEO 1 VIDEO 2
To Remote Powered Speakers (audio only)
To wall
outlet
230V~
Left speaker
Note: Since A/V transmitter & receiver merely receive stereo signals and do not amplify them, the speakers you use
to enjoy wireless sound must be self-powered or attached to an amplifier or stereo receiver.
To wall
outlet
230V~
Cable TV Hookup
Signal from antenna
Mini stereo phono jack /
stereo RCA adapter
Audio/Video Transmitter & Receiver
RECEIVER
VCR
LINE
IN
RF IN
LINE
RF OUT
OUT2
LINE
OUT1
A/V Cable
RECEIVER
76
A/V Cable
Right speaker
