Audio/Video Transmitter & Receiver
User´s Manual
Receiver
FRONT VIEW
Remote control antenna.
Receives UHF remote
control signals.
IR signal indicator
Status LEDs.
They indicate the
selected channel*.
Chan. 1 Chan. 3
Remote control
Chan. 4
Chan. 2
window.
Transmits UHF remote
control signals.
REAR VIEW
Channel selection
switch*.
Use to find optimal
reception. Must
12 volt power select same channel
adapter plug on both transmitter
ON / OFF
Right
Left
Video
and receiver.
switch
audio
audio
jack
jack
jack
(yellow)
(red)
(white)
Note: Make sure ON/OFF switch is in OFF position before plugging in any accessory.
It depends on the model
*
