Search Host Adapter

When the user presses <R> from the Command Mode menu, the Search Host Adapter screen will appear, with the following
search criteria to choose from:
N- Name- to search by name
I - Index- to search by index number
U- Unique ID- to search by the unique
identification number
C- Comment- to search by words in the
comment field of the Host Adapter info screen
To continue, press a letter, then type in the value of the chosen parameter.
used to move the cursor. Once the selection is highlighted, press <Enter> to select it.
Function Keystroke
N
Name
I
Index
U
Unique ID
C
Comment
Esc
Exit
FYI: If the wrong characters are entered, use the <Backspace> key to remove and edit characters to submit for
The first match to the characters submitted will be displayed as the parameter value is entered.
Note: Find and Search Modes are NOT case sensitive.

Host Adapter Info

To display the selected Host Adapter Info screen, press <I> from the Command Mode menu.
FYI: If there are no Host Adapters configured, the information screen for the User Station will be displayed instead.
This screen displays the following information:
Item Description
Name The name of the Host Adapter
Comment could be used to decribe the location
of the Host Adapter
Unique ID a value unique to the segment
Master ID the segment 's Master ID
Index number used in the index of the
Command Mode menu
Revision ROM version, used to identify the
Host Adapter firmware version
installed
Type PS2, SUN,or USB (Identifies the
type of Host Adapter connected)
CodeCRC ROM CRC, use for identification
Purposes
HostID An internal serial number
Value or Action
type in the name of the Host Adapter, up to 16 characters, case sensitive
type in the index number for the Host Adapter
type in the Unique ID value of the Host Adapter
type in the case sensitive comment, up to 32 characters.
To cancel the search and return to the Command Mode menu

Figure 15- Find Host Adapter screen

The <Up Arrow> or <Down Arrow> may also be

Figure 16- Host Adapter Info screen

20
search.
