Centro Barbecue 2000 Safe Use, Care And Assembly Manual

Hide thumbs Also See for Barbecue 2000:

Advertisement

Quick Links

SERIAL #:
3 Y E A R L I M I T E D W A R R A N T Y
8 5 - 1 1 0 3 - 8 ( P R O P A N E ) ( G 4 1 3 0 3 )
8 5 - 1 0 0 3 - 8 ( N A T U R A L G A S ) ( G 4 1 3 0 4 )
Read and save this manual for future reference.
If pre-assembled, leave this manual with
unit for consumer's future reference.
For product inquiries, parts, warranty
and troubleshooting support, please call
1-877-707-5463
Barbecue 2000
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
D A N G E R
If You Smell Gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
W A R N I N G
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
W A R N I N G
Failure to follow all of the manufacturer's
instructions could result in hazardous
fires, explosions, property damage,
or serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully
prior to operation of barbecue,
even if barbecue was store assembled.
Do not try to light this barbecue
without reading the Lighting Instructions
section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Barbecue 2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Centro Barbecue 2000

  • Page 1 SERIAL #: Barbecue 2000 S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L D A N G E R If You Smell Gas 1.
  • Page 2: Table Of Contents

    Warranty ....ii This Centro Barbecue carries a three year limited warranty against defects in Installation Information ..1 manufacturing workmanship.
  • Page 3: Installation Information

    I N S T A L L A T I O N The installation of this appliance must be in accordance with all local codes, or in the absence of local codes: I N F O R M A T I O N Canadian installation must conform to the current national standards, which at this time •...
  • Page 4 The Cylinder must also be equipped with: A shut-off valve with a correct cylinder valve outlet as specified in current standards. • Canada: CAN / CGA 1.6g-M97 Outdoor Gas Grilles. • a) A safety relief valve with direct connection to the vapour space of the cylinder. b) A collar to protect the tank shut-off valve.
  • Page 5: Prior To Using The Grill

    P R I O R T O U S I N G DO NOT USE YOUR BARBECUE UNTIL YOU HAVE CAREFULLY READ AND FULLY UNDER- STAND ALL THE INFORMATION IN THIS MANUAL. PLEASE ENSURE THE FOLLOWING: Your barbecue is properly assembled. •...
  • Page 6: Safety Hose And Regulator

    S A F E T Y H O S E Propane Gas Models: Your barbecue is designed to operate on L.P. (Propane) gas at a pressure of 2.74 Kpa (11˝ water column). A regulator preset to this pressure is supplied A N D R E G U L A T O R with the barbecue and must be used.
  • Page 7: Safety Leak Testing

    To Reset The Gas Regulator Safety Device 1. Close the LP (propane) tank valve. 2. Turn all burner control knobs to the OFF position. 3. Disconnect the regulator from the LP tank. 4. Open the grill lid. 5. Open all of the control knobs to the high position. 6.
  • Page 8: Lighting The Main Burners

    L I G H T I N G Make sure you have followed all the safety checks, procedures and instructions indicated in the previous section, before attempting to light the grill. T H E G R I L L Lighting The Main Burners 1.
  • Page 9 6. Confirm that the burner is properly lit. If the flame pattern is other than normal, consult the Troubleshooting Guide for corrective action. 7. Always preheat the Barbecue before starting to cook. Light all burners and adjust them to the HIGH position for 5-10 minutes. Before placing any food on the Barbecue, clean the cooking grids with a Porcelain cleaning brush.
  • Page 10: Parts List And

    P A R T S L I S T I N G F O R Item No. Quantity Specification Part No. Top Lid Assembly 8 5 - 1 1 0 3 - 8 ( P R O P A N E ) Top Lid Weldment G413-1100-01 ( G 4 1 3 0 3 )
  • Page 11 8 5 - 1 1 0 3 - 8 ( P R O P A N E ) ( G 4 1 3 0 3 ) Manual Hardware Pack...
  • Page 12 P A R T S L I S T I N G F O R Item No. Quantity Specification Part No. Top Lid Assembly 8 5 - 1 0 0 3 - 8 ( N A T U R A L G A S ) Top Lid Weldment G413-1100-01 ( G 4 1 3 0 4 )
  • Page 13 8 5 - 1 0 0 3 - 8 ( N A T U R A L G A S ) ( G 4 1 3 0 4 ) Manual Hardware Pack...
  • Page 14: Assembly Instructions

    A S S E M B L Y I N S T R U C T I O N S Hardware Pack List Description Part Number Quantity Tools Needed for Assembly 1/4” x 38 mm Screw 20120-13038-250 1/4” x 13 mm Screw 20120-13013-250 #2 Phillips ®...
  • Page 15 Fig. 1 Attach two front casters (EH) and two back casters with lock (EG) to the bottom shelf (EF) by using the provided wrench hardware #11. Fig. 2 Assemble the cart left side panel (EA) and cart right side panel (EB) to the bottom shelf (EF) using hardware #2, #3, #4 and #5 (x6).
  • Page 16 Fig. 4 Assemble the upper brace (CH) below the control panel (CE) as shown using hardware #6,#7 and #8 (x4). Fig. 5 Open lid (A) and position the three flame tamers (BF) above the burners (BD) as shown. Place the two cooking grates (BG) above the flame tamers.
  • Page 17 Fig. 7 Insert grease tray left and right rail (CJ) & (CK) into the holes at the inside of the cart assembly as shown. Insert the tank heat shield (CI) into the holes in the upper rail. Assemble the upper back panel (CL) to the back of the burner box by using hardware #1, #3 and #4 (x4).
  • Page 18 Unscrew the ignitor cap and place AA battery into ignitor (CD) with positive end (+) facing outwards. Screw ignitor cap onto ignitor as shown. Assemble the front panel (EC) to the right and left panel using hardware #3, #4 and #5 (x4). Fig.
  • Page 19: Information On

    6. If a leak cannot be stopped, do not attempt to light the grill. Always contact Centro Customer Support for assistance. 1-888-707-5463. Gas Hookup & Warnings Warnings: Poor Natural Gas Burning Performance and heat distribution is related to the points listed below..
  • Page 20 All gas supply plumbing must be able to supply 7” water column to the barbecue with all burners in operation. ALL Centro BBQ’s are sold either NATURAL GAS or PROPANE READY and are not Convertible to an alternate gas source.
  • Page 22 D I S T R I B U T O R Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8...
  • Page 23 N O T E S...
