CENTRO 3900
Assembly Manual
85-1626-4 (G51206) Propane
85-1651-2 (G51209) Natural Gas
LIMITED 5-YEAR WARRANTY
Read and save manual for future reference.
Assemble your grill immediately.
Missing or damaged parts should be
claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-877-707-5463.
Manual Revision #: 07012009 SA
Advertisement
Related Manuals for Centro CENTRO 3900
Summary of Contents for Centro CENTRO 3900
- Page 1 CENTRO 3900 Assembly Manual 85-1626-4 (G51206) Propane 85-1651-2 (G51209) Natural Gas LIMITED 5-YEAR WARRANTY Read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1-877-707-5463.
-
Page 2: Hardware Pack
HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY No. Description Part Number Quantity ¼"-20UNCX13 Screw 20120-13013-250 • #2 Phillips screwdriver (Long and short) ¼"-20UNCX38 Screw 20120-13038-250 • ¼” Slotted screwdriver (Long and short) ¼"-20UNCX16 Screw 20120-13016-250 • Adjustable wrench ø7 Lock Washer 41400-07000-250 •... - Page 3 PARTS LIST (PROPANE) FOR 85-1626-4 (G51206) EXPLODED DIAGRAM (PROPANE) FOR 85-1626-4 (G51206) Item Qty. Description Part No. Item Qty. Description Part No. Top Lid G512-2800-01 Cooking Grate, Sideburner G501-0077-01 Lid Handle G512-0001-01 Lid- Sideburner G501-0070-01 Lid Handle End Cap-Left G617-0004-01 Side Shelf Table- Right G512-0500-01 Lid Handle End Cap-Right...
- Page 4 PARTS LIST (NATURAL GAS) FOR 85-1651-2 (G51209) EXPLODED DIAGRAM (NATURAL GAS) FOR 85-1651-2 (G51209) Item Qty. Description Part No. Item Qty. Description Part No. Top Lid G512-2800-01 Electrode Set, Sideburner G433-0047-01 Lid Handle G512-0001-01 Cooking Grate, Sideburner G501-0077-01 Lid Handle End Cap-Left G617-0004-01 Lid F/ Sideburner G501-0070-01...
-
Page 5: You Will Need
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Separate the 2 diff erent types of wheels, 2 Attach the front brace (CJ) to the left and right locking wheels (EH) and 2 regular wheels (EI). cart side panels (EA and EB) Attach the locking wheels (EH) to the back of the TIP: One person should align the left side, while bottom shelf (EG) and the regular wheels (EI) to the second person assembles the right side. - Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Attach the right side shelf fascia (DH) to the right THIS STEP REQUIRES 3 OR MORE PEOPLE. DO NOT ATTEMPT ALONE. EXTREMELY side shelf table (DG), as shown. HEAVY. a. Position the top lid and burner box assembly (A and B) onto cart assembly (C) as shown.
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Attach the left shelf fascia (DB) to the left side shelf Remove the hardware that is pre-assembled to the Front table (DA). side burner valve bracket (CC), as shown in fi gure A. Insert the side burner valve stem through the rear of the left side shelf fascia (DB).
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Position the side burner (DD1) through the Place the heat shield (CN) into the groove opening in the left side burner drip pan (DC). which is located at the back side of the front panel as shown in fi gure A. Next, attach the heat shield (CN) to the upper back panel (CM) by using the self tapping screws (x 4), as shown in fi gure B.
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Place the fl ame tamers (BG) into the burner box. a. Insert the grease tray (CL) into the opening in the upper back panel (CM), making sure to engage tracks located under burner box. b. Place the grease cup (CK) onto the tracks, lo- cated on the underside of the grease tray (CL).
- Page 10 ATTENTION: For your families safety, do not attempt to light this BBQ until you have reviewed pages 4-7 of the CENTRO Safety & Care Manual. All Safety and Leak test MUST BE PERFORMED BY THE END USER, prior to lighting this BBQ.
