Stainless 2000 Barbecue
3 Y E A R L I M I T E D W A R R A N T Y
8 5 - 1 2 6 8 - 6 ( P R O P A N E )
8 5 - 1 2 7 3 - 2 ( N A T U R A L G A S )
Read and save this manual for future reference.
If pre-assembled, leave this manual with
unit for consumer's future reference.
For product inquiries, parts, and warranty
and troubleshooting support, please call
1-877-707-5463
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
F O R Y O U R S A F E T Y
If You Smell Gas
1. Immediately turn off the flow of gas to the unit.
2. Extinguish any open flame.
3. Open the lid of the unit.
4. If the odour does not stop quickly, immediately call
your gas supplier or Fire Department for assistance.
F O R Y O U R S A F E T Y
1. Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or
other appliance.
2. An LP Gas cylinder not connected for use shall not
be stored in the vicinity of this or other appliance.
W A R N I N G
Failure to follow all of the Manufacturer's instructions
could result in hazardous fires, explosions, property
damage, or serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully prior to
operation of barbecue, even if barbecue was stored
assembled. Do not try to light this barbecue without
reading the Lighting Instructions section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Centro Stainless 2000
Summary of Contents for Centro Stainless 2000
- Page 1 Stainless 2000 Barbecue S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L F O R Y O U R S A F E T Y If You Smell Gas 1.
-
Page 2: Table Of Contents
Warranty ....ii 3 Year Limited Warranty This Centro Barbecue carries a three year limited warranty against defects in man- Installation ....1 ufacturing workmanship. -
Page 3: Installation
I N S T A L L A T I O N The installation of this appliance must be in accordance with all local codes, or in the absence of local codes: Canadian installation must conform to the current national standards, which at this time •... -
Page 4: Transportation And
The Cylinder must also be equipped with: A shut-off valve with a correct cylinder valve outlet as specified in current standards. • Canada: CAN / CGA 1.6g-M97 Outdoor Gas Grilles. • a) A safety relief valve with direct connection to the vapour space of the cylinder. b) A collar to protect the tank shut-off valve. -
Page 5: Hose And Regulator
H O S E A N D Propane Gas Models: Your barbecue is designed to operate on L.P. (Propane) gas at a pressure of 2.74 Kpa (11˝ water column). A regulator preset to this pressure is supplied R E G U L A T O R with the barbecue and must be used. - Page 6 The Following Must be Checked The tank valve including the threads into the tank (drawing C). • All tank welds (drawing B). • Regulator fittings and tank connections (drawing C). • All hose connections (drawing D). • With a newly filled and tested propane tank attached to the •...
-
Page 7: Lighting The Grill
L I G H T I N G Make sure you have followed all the checks, procedures and instructions • indicated in the prior sections before attempting to light the grill. T H E G R I L L Always raise the barbecue lid before lighting the burner. •... - Page 8 W A R N I N G If the heat output is too low, the flow control feature may have been activated by a gas leak. If so, turn off the burner valve and cylinder valve, and perform the “Leak Test”. If there aren’t any leaks, re-light the burner.
-
Page 9: Tips On Using
T I P S O N U S I N G Using for the First Time: Before cooking, turn on the grill and operate on “HIGH” for about 10 – 15 minutes with the lid open. Close the lid and continue to run the grill on Y O U R B A R B E C U E “HIGH”... -
Page 10: Cleaning And Maintenance
C L E A N I N G To get many years of service out of your barbecue, perform the following procedures at least once a year, especially at the start of a new season. A N D M A I N T E N A N C E Grill: Apply a light coating of cooking oil to the grating to prevent food from sticking. -
Page 11: Troubleshooting Guide
T R O U B L E S H O O T I N G G U I D E Problem Possible Causes Corrective Action Burner will not light Blocked Venturi tubes Clean out blockage • • (match or igniter) Cylinder or gas supply valve turned off Open cylinder or gas supply valve •... -
Page 12: Parts List And
P A R T S L I S T I N G F O R 8 5 - 1 2 6 8 - 6 ( P R O P A N E ) Item No. Quantity Description Part No. / Spec. Item No. - Page 13 8 5 - 1 2 6 8 - 6 ( P R O P A N E )
-
Page 14: Parts List And
P A R T S L I S T I N G F O R 8 5 - 1 2 7 3 - 2 ( N A T U R A L G A S ) Item No. Quantity Description Part No. - Page 15 8 5 - 1 2 7 3 - 2 ( N A T U R A L G A S )
-
Page 16: Assembly Instructions
A S S E M B L Y I N S T R U C T I O N S Tools Needed for Assembly #2 Phillips ® screwdriver • 1/4˝ slotted screwdriver • Adjustable wrench • Pliers • Rubber mallet •... - Page 17 After removing the unit from carton please make sure that all hard- ware is present. Before starting to assemble the unit, read these instructions carefully. It is suggested to assemble the unit on a flat, clean surface. Add the tank mounting brackets (Item 47, 48) to the outside of the left side panel as shown, using (Key G, D, C).
- Page 18 With the help of another person, lift the top and bottom assembly into position as shown. Make sure to align the holes in bottom assem- bly with tapped holes in cross member of the main frame assembly. Assemble the left burner shelf assembly (Item 29) by sliding it into position as shown.
- Page 19 Open the top lid and position the heat plates (Item 28) as shown. Add the cooking grates (Item 27) above the heating plates. Insert the warming rack (Item 12) as shown. Warming rack legs are bendable. Insert the grease cup (Item 50) into the cup holder (Item 51) and slide the grease tray (Item 49) into position.
- Page 20 Assembly of the barbecue is complete. Please read all cautions and warnings before using your barbecue. Unscrew igniter cap and place “AA” battery into igniter slot with positive end (+) facing outward. Screw igniter cap onto igniter.
-
Page 21: Information On Natural Gas
I N F O R M A T I O N O N This model has a 12’ hose with a male coupling plug that will allow you to attach your barbecue to your residential gas line. N A T U R A L G A S M O D E L We strongly recommend contacting a certified gas-technician to install your natural gas unit. - Page 23 D I S T R I B U T O R Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8...
