15.4 Antennas

Type
GAINFLEX 400-430
GAINFLEX 430-470
CA420Q
CA450Q
MINIFLEX 400-430
MINIFLEX 430-470
ANTENNA 869
SATEL antenna selection includes also directional and/or omni-directional antenna. These can be
supplied separately on request. Antennas are also available for the 869 MHz frequency range.

15.5 Filters and lightning protectors

If a radio modem system is installed in an environment that contains high-power transmitters or
sources of radio frequency interference, it is highly recommendable to insert suitable filters
between each radio modem and its antenna. If a station is installed to a location exposed to
lightning, it is recommended to insert a lightning protector to the feed-line outside the protected
zone. SATEL Technical Support can give guidance in the selection of suitable products.

15.6 Power supplies

Type
PS-DIN-2

15.7 Battery pack

Type
SATEL-321

15.8 Installation and enclosures

Type
I-DIN
H-WP
H-WPm2
Description
Half-wave antenna
Half-wave antenna
Sleeve fed quarter wave whip, 2dBi, 405–440 MHz
Sleeve fed quarter wave whip, 2dBi, 440-475 MHz
Helix antenna
Helix antenna
Quarter wave antenna for 869 MHz modems
Description
240 Vac/24 Vdc/2.5A, to be mounted to DIN rail
Description
Weather proof battery pack with extended life time
Description
Installation plate for DIN rail mounting for 3AS(d) modems
Weather proof housing (IP43) for 3AS(d) modems
Weather proof housing (IP53)
