User defined address position setup
-----------------------------------
1) Start position
2) Length
Enter selection or ESC to previous menu >1
User defined address position setup
-----------------------------------
1) Start position
2) Length
Enter selection or ESC to previous menu >2
User defined address position setup
-----------------------------------
1) Start position
2) Length
Enter selection or ESC to previous menu >ESC
The display has now returned to the main menu of the routing settings and it can be seen that the
routing mode (Virtual Mode Routing) as well as the protocol (USERDEFINED 02 03) have been
modified.
01
01
User defined address start position setup
-----------------------------------------
Current value: 01
Enter new start position (0-16) >02
User defined address start position setup
-----------------------------------------
Current value: 02
Enter new start position (0-16) >ESC
02
01
User defined address length setup
---------------------------------
Current value: 01
Enter new length (1-4) >3
User defined address length setup
---------------------------------
Current value: 03
Enter new length (1-4) >ESC
02
03
