IMPORTANT NOTICE

All rights to this manual are owned solely by SATEL Oy (referred to in this user guide
as SATEL). All rights reserved. The copying of this manual (without the written
permission from the owner) by printing, copying, recording or by any other means, or
the full or partial translation of the manual to any other language, including all
programming languages, using any electrical, mechanical, magnetic, optical, manual
or other methods or devices is forbidden.
SATEL reserves the right to change the technical specifications or functions of its
products, or to discontinue the manufacture of any of its products or to discontinue
the support of any of its products, without any written announcement and urges its
customers to ensure, that the information at their disposal is valid.
SATEL software and programs are delivered "as is". The manufacturer does not grant
any kind of warranty including guarantees on suitability and applicability to a certain
application. Under no circumstances is the manufacturer or the developer of a
program responsible for any possible damages caused by the use of a program. The
names of the programs as well as all copyrights relating to the programs are the sole
property of SATEL. Any transfer, licensing to a third party, leasing, renting,
transportation, copying, editing, translating, modifying into another programming
language or reverse engineering for any intent is forbidden without the written
consent of SATEL.
SATEL PRODUCTS HAVE NOT BEEN DESIGNED, INTENDED NOR INSPECTED
TO BE USED IN ANY LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED
FUNCTION NOR AS A PART OF ANY OTHER CRITICAL SYSTEM AND ARE
GRANTED NO FUNCTIONAL WARRANTY IF THEY ARE USED IN ANY OF THE
APPLICATIONS MENTIONED.
Salo, Finland 2023
NOTE! This is a short form user guide for SATEL products. Complete user
guide for each model is available in electronical format on SATEL web site
www.satel.com
SATEL Short Form user guide
1
Version 25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SATELLINE-3AS VHF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Satel SATELLINE-3AS VHF

  • Page 1: Important Notice

    Version 25 IMPORTANT NOTICE All rights to this manual are owned solely by SATEL Oy (referred to in this user guide as SATEL). All rights reserved. The copying of this manual (without the written permission from the owner) by printing, copying, recording or by any other means, or...
  • Page 2: Restrictions On Use

    • The radio modem is only to be operated at frequencies allocated by local authorities, and without exceeding the given maximum allowed output power ratings. SATEL and its distributors are not responsible, if any products manufactured by it are used in unlawful ways.
  • Page 3: Declaration Of Conformity

    SATEL Short Form user guide Version 25 DECLARATION OF CONFORMITY Hereby, SATEL Oy declares that SATELLINE radio modems are in compliance with the essential requirements (radio performance, electromagnetic compatibility and electrical safety) and other relevant provisions of Directive 2014/53/EU. Therefore, the equipment is labeled with the CE-marking (image down below).
  • Page 4: Table Of Contents

    ..................18 PECIFICATION FOR BATTERY ....................19 HARGING INDICATORS ....................... 19 INNING ORDERS SATEL EASY-PROOF AND SATEL PROOF-TR4+ / -TR9 ........20 SATEL EAS (YM6580, YM6585) ...... 20 ECHNICAL SPECIFICATION FOR ROOF SATEL P -TR4+ (YM6577, YM6578) / -TR9 (YM6410,...
  • Page 5 ..TRANSCEIVER MODULE ..........................29 8.13 SATELLINE-M3-R9 (YM7950) ............29 RECEIVER MODULE 8.14 SATEL-TR49 (YM8490, YM8495, YM8500, YM8505, YM8510, YM8515, YM8520, YM8525) ......................... 30 TRANSCEIVER MODULE 8.15 SATEL-TR489 (YM8810, YM8815, YM8820, YM8825) ....30 TRANSCEIVER MODULE 8.16 SATELLINE-TR9, -R9, SATEL–TR49 TR489 ......
  • Page 6: Satelline -3As Vhf

    Size H x W x D 137 x 67 x 29 mm Weight 265 g Technical specifications for SATELLINE-3AS VHF C (YM5020) and -3ASd VHF C (YM5030) Both models are equipped with a heat sink, which is the appropriate choice for continuous transmission.
  • Page 7: Pinning Order

    SATEL Short Form user guide Version 25 Pinning order D15 female connector in radio modem. DTE is an abbreviation for Data Terminal Equipment DIR. column below denotes the direction of the signal: "IN" is from DTE to the radio modem, "OUT"is from the radio modem to the DTE.
  • Page 8: Satel-Easy

    SATEL Short Form user guide Version 25 2 SATEL-EASy+ Technical specifications for SATEL-EASy+ (YM6010, YM6015, YM6050, YM6055) The models SATEL-EASy+ YM6050 and YM6055 are equipped with LCD and push- buttons. Models YM6010 and YM6050 are with AES128 encryption support. Subject Value Frequency range 403 …...
  • Page 9 SATEL Short Form user guide Version 25 RS-232 Clear To Send. This signal indicates that the radio modem serial interface is ready to receive data from DTE. Note*) 7, 8 Operating voltage ground / signal ground. Signal ground has a galvanic connection to the modem casing.
  • Page 10: Satel-Easy Pro

    SATEL Short Form user guide Version 25 3 SATEL-EASy Pro+ Technical specifications for SATEL-EASy Pro+ (YM6820, YM6823, YM6825, YM6830, YM6833, YM6835, YM6840, YM6843, YM6845) YM6820 is with AES128 encryption support and 25 W TX power. YM6823 is with AES128 encryption support and 35W TX power.
  • Page 11: Pinning Orders

    SATEL Short Form user guide Version 25 Three different duty cycle cases which are shown in the table below are measured with the following Ton and Toff times. Duty Cycle/% ON all time Pinning orders a) Data connector SATEL–EASy Pro+...
  • Page 12: Satelline-Easy, -Easy 869, -Easy (865-867 Mhz)

    SATEL Short Form user guide Version 25 4 SATELLINE-EASy, –EASy 869, –EASy (865-867 MHz) Technical specifications for SATELLINE-EASy (YM6500, YM6550, YM6510, YM6560) The models SATELLINE-EASy YM6550 and YM6560 are equipped with LCD and push- buttons. Models YM6510 and YM6560 are with AES128 encryption support.
  • Page 13: Technical Specification For Satelline-Easy, 865-867 Mhz (Ym6501, Ym6551)

    SATEL Short Form user guide Version 25 According to a recommendation of ETSI, the frequencies range 869.4…869.65 MHz is reserved for use of license free radio appliances. The application of this recommendation varies in each country, and for this reason local regulations concerning this frequency range must always be checked.
  • Page 14: Pinning Order

    SATEL Short Form user guide Version 25 4.4 Pinning order D15 female connector in radio modem. PORT AND TYPE DIRECTION NAME EXPLANATION Receive data (Port1) PORT1: RS-232 Transmit data (Port1) PORT2: RS-232 / 422 Receive data (Port2) Transmit data (Port2) 232 ON / 422 OFF A’...
  • Page 15: Satelline-Easy Pro 35W

    SATEL Short Form user guide Version 25 5 SATELLINE–EASy Pro 35W Technical specifications for SATELLINE-EASy Pro 35W (YM6803 and YM6813) The model YM6813 is with AES128 encryption support. Subject Value Frequency range 403 … 473 MHz Tuning range 70 MHz Channel spacing 12.5 / 20 / 25 kHz selectable...
  • Page 16: Pinning Orders

    SATEL Short Form user guide Version 25 Pinning orders a) SATELLINE–EASy Pro 35W Connector: 8-pin ODU, MINI-SNAP SGND PROG Not connected Not connected b) Power connector SATELLINE-EASy Pro 35W Connector: 4-pin ODU MINI-SNAP Style G4 size 1 PWR (+) PWR (+)
  • Page 17: Satel Compact-Proof

    520 g / w battery 850 g IP classification IP67 (NEMA6) 6.2 Technical specification for SATEL Compact-Proof, 869 MHz, (YM6575, YM6576) SATEL Compact-Proof, 869 MHz, YM6576 is without battery. YM6575 is with battery. Subject Value Frequency range 869.4125 … 869.6375 MHz *)
  • Page 18: Specification For Battery

    6.3 Technical specification for SATEL Compact-Proof, 865-867 MHz, (YM6575, YM6576) SATEL Compact-Proof, 865-867 MHz, YM6576 is without battery. SATEL Compact-Proof, 865-867 MHz, YM6575 is with battery. This variant of SATEL Compact-Proof is ready to use on the Indian licence free channels. Subject Value Frequency range 865 …...
  • Page 19: Charging Indicators

    SATEL Short Form user guide Version 25 6.5 Charging indicators Charging conditions, charging power connected Colour Value Green Charging power connected or charging completed (charging power used as a primary power source) Orange Pre-Charging and battery detect Battery charging Blinking orange...
  • Page 20: Satel Easy-Proof And Satel Proof-Tr4+ / -Tr9

    Technical specification for SATEL Proof-TR4+ (YM6577, YM6578) / -TR9 (YM6410, YM6411, YM6412) SATEL Proof-TR4+ YM6577 is with AES128 encryption support. SATEL Proof-TR9 YM6410 is region all model. SATEL Proof-TR9 YM6411 is region US / CA, YM6412 region AU, NZ and BR. Subject Value Frequency range 403 …...
  • Page 21: Pinning Order

    SATEL Short Form user guide Version 25 Pinning order Data connector: Deutsch DT04-6P-CL09 Vb, Operating Voltage Not connected Not connected...
  • Page 22: Customized Radio Modems And Modules

    SATEL Short Form user guide Version 25 8 CUSTOMIZED RADIO MODEMS AND MODULES Down below examples of the customized radio modems. Ask your local SATEL distributor about the various options. SATELLINE-M3 VHF (YM6000) technical specifications In an aluminum housing. Subject...
  • Page 23: Pinning Order For D15 Female Connector Adapter

    SATEL Short Form user guide Version 25 Subject Value Frequency range 330 … 420 / 403 … 473 MHz Tuning range 90 / 70 MHz Channel spacing 12.5 / 20 / 25 kHz selectable RX Sensitivity / TX power max.
  • Page 24: Satelline-M3-Tr1 869 (Ym6301) Transceiver Module

    SATEL Short Form user guide Version 25 8.4 SATELLINE-M3-TR1 869 (YM6301) transceiver module SATELLINE-M3-TR1 869 is available either without housing in PCB format or in aluminum housing. In PCB format the module is available with TNC, MCX, SMA or MMCX antenna connector.
  • Page 25: Pinning Order For Tr1 869 And 865 Mhz Variant, 26-Pin Connector

    SATEL Short Form user guide Version 25 8.6 Pinning order for TR1 869 and 865 MHz variant, 26-pin connector I/O column below denotes the direction of the signal: "IN" is from DTE (Data Terminal Equipment) to the radio modem. "OUT" is from the radio modem to DTE.
  • Page 26: Pinning Order For D15 Female Connector Adapter

    SATEL Short Form user guide Version 25 Note! Unused pins can be left unconnected. Note*) RTS and CTS signals apply to the selected Data port (either Port1 or Port2). Note**) Programming Mode is for changing the settings of the radio modem via Programming menu.
  • Page 27: Satel-Tr4+ (Ym7470, Ym7475, Ym7480, Ym7485) Transceiver Module

    Version 25 8.8 SATEL-TR4+ (YM7470, YM7475, YM7480, YM7485) transceiver module SATEL-TR4+ is available without housing in PCB format. Models YM7470 and YM7480 are with AES128 encryption. Models YM7480 and YM7485 have DTE connector on TOP, while others on BOTTOM. Subject...
  • Page 28: Satel-Tr300 (Ym7300, Ym7305, Ym7315) Transceiver Module

    SATEL Short Form user guide Version 25 8.10 SATEL-TR300 (YM7300, YM7305, YM7315) transceiver module SATEL-TR300 is available without housing in PCB format. Model YM7300 is with AES128 encryption. Model YM7315 has DTE connector on TOP, while others on BOTTOM. Subject...
  • Page 29: Satelline-M3-Tr9 (Ym7900, Ym7910, Ym7915, Ym7920) Transceiver Module

    SATEL Short Form user guide Version 25 8.12 SATELLINE-M3-TR9 (YM7900, YM7910, YM7915, YM7920) transceiver module SATELLINE-M3-TR9 is available without housing in PCB format. YM7910 is for US/CA. YM7915 is for AU. Model YM7920 has DTE connector on TOP, while others on BOTTOM.
  • Page 30: Satel-Tr49 (Ym8490, Ym8495, Ym8500, Ym8505, Ym8510, Ym8515, Ym8520, Ym8525) Transceiver Module

    8.14 SATEL-TR49 (YM8490, YM8495, YM8500, YM8505, YM8510, YM8515, YM8520, YM8525) transceiver module SATEL-TR49 is available without housing in PCB format. YM8490, YM8500, YM8510 and YM8520 are with AES128 encryption support. YM8500 and YM8505 follows US / CA frequency hopping patterns.
  • Page 31: Pinning Order For Satelline-Tr9, -R9, Satel-Tr49

    1.27 mm pitch socket / U.FL Size H x W x D 57 x 36 x 6.9 mm Weight 20 g *) Ask for availability 8.16 Pinning order for SATELLINE-TR9, -R9, SATEL–TR49 and TR489 Signal name Type Direction Pin State Description...
  • Page 32: Satel-Tr49 Snapon (Ym8600, Ym8605, Ym8610, Ym8615, Ym8630, Ym8635) Transceiver Module

    8.17 SATEL-TR49 SnapOn (YM8600, YM8605, YM8610, YM8615, YM8630, YM8635) transceiver module SATEL-TR49 SnapOn is available without housing in PCB format. YM8600, YM8610 and YM8630 are with AES128 encryption support. YM8610 and YM8615 are for US / CA. YM6830 and YM6835 are for AU / BR.
  • Page 33: Pinning Order For Satel-Tr49 Snapon

    SATEL Short Form user guide Version 25 Radio compatibility SATEL 3AS, TrimTalk 450s, TrimMark III, PacCrest- GMSK, -4FSK, -FST @ 400 MHz Freewave / Intuicom @ 900 MHz Connectors PCIe MiniCard full size / U.FL Size H x W x D 51 x 30 x 4.8 mm...
  • Page 34 SATEL Short Form user guide Version 25 Pin No. Mini PCI express Direction Pin State standard description SMB_CLK PETn0 SMB_DATA PETp0 USB_D- USB Data minus High 2.0V - Vcc IN Low -0.5 V - 0.8 V USB_D+ USB Data plus High 2.0V - Vcc IN...
  • Page 35: Additional Equipment

    Note ***) *) Special Modbus compatible variants available. Ask more information from your local SATEL distributor. **) Following modems belong to the group G1: SATELLINE-3AS VHF, -3ASd VHF, -3AS VHF C, -3ASd VHF C SATELLINE-EASy SATEL-EASy+ SATELLINE-EASy 869 SATELLINE-M3 VHF...
  • Page 36: Accessories

    SATEL Short Form user guide Version 25 10 ACCESSORIES SATEL can offer following accessories for SATELLINE radio modems. 10.1 Interface cables and adapters for RS-232 interface Type Description Length Note NARS-1F Adapter D15 m / D15 f, Inc. 2m power supply wires...
  • Page 37: Nms Cable

    SATEL Short Form user guide Version 25 10.3 NMS cable Type Description Length Note CRS-NMS Cable D15 m / 2 x D9f, 1.5 m Inc. power supply wires (YC0302) from master modem to user system and NMS PC 10.4 Programming cable...
  • Page 38: Antennas

    Directional yagi, 8 dBi, 380-410 MHz CA420Y+ 405-440 MHz CA450Y+ 440-475 MHz Example of antenna for other SATELLINE modems: Type Description Antenna 869 Half-wave antenna for EASy 869 modems (YA0869) Please contact your local SATEL distributor in order to get more information of different antennas.
  • Page 39: Power Supplies And Power Cables

    If a station is installed to a location exposed to lightning, it is recommended inserting a lightning protector to the feed-line outside the protected zone. SATEL technical support can give guidance in the selection of suitable products.
  • Page 40: Software

    The device configuration can be also created/saved/explored from/to a file without device connection. The most common use case for which the SATEL NETCO DEVICE is optimized for is editing existing parameters in a SATEL radio product using local connection, such as serial interface.
  • Page 41: Satel Configuration Manager

    The user interface of the product is web browser -based and can therefore be used both locally and remotely. Design with graphical user interface for easy optimizing network design and deployment in a few simple steps, with local and remote connection to SATEL radios.
  • Page 42: How To Establish A Wireless Data Link

    Version 25 12 HOW TO ESTABLISH A WIRELESS DATA LINK Down below is the guidance how to establish a basic wireless data link with a pair of SATEL radio modems and their accessories. 12.1 List of equipment two SATEL radio modems...
  • Page 43: Parameter Setups

    SATEL Short Form user guide Version 25 12.3 Parameter setups The following parameters shall be set equally in both radio modems Radio frequency Channel spacing Error correction Error check Number of data bits in a serial character The serial interface parameters below must be the same in the radio modem and in the PC connected to it.
  • Page 44: Settings

    Version 25 13 SETTINGS The configuration of SATEL radio modems can be easily changed. Simply by connecting the PROG pin to ground (GND) the radio modem will switch into Programming Mode. Serial port PORT 1 is used whenever the radio modem is in the Programming Mode. The serial port settings are 9600 bps, N, 8,1 (data transfer speed 9600 bps, no parity, character length 8 bits and one (1) stop bit).
  • Page 45: Error Correction (Fec)

    It is also recommended to use FEC in case there are intermittent interferences on the radio channel. FEC function decreases data transfer throughput by app. 30 %. Contact your local SATEL distributor in order to get more information of the exact transfer delays introduced by using FEC function.
  • Page 46: Check List / Trouble Shooting

    6. All radio modems in the same system must be configured using the same settings (radio frequency, channel spacing and data field length). In case you need technical support please feel free to contact your local SATEL distributor or send e-mail to our technical support: technical.support@satel.com...
  • Page 47: Recycling

    Please refer to your nearest recycling collection point. When disassembled, the device is recycled as follows: • Housings and mechanical parts, see recycling and material label in component • PCBs are electronic waste If necessary, contact SATEL or nearest distributor for more information.
