Basic RS-232 connection between the radio modem (PORT1) and a typical PC (COM-
port) using handshaking:
9-PIN D-CONN. 25-PIN D-
T
3 2
RD
2 3
RTS
7 4
CTS
8 5
DSR
6
6
SGND
5 7
CD
1 8
DTR
4 2

4.2 Port 2

Port 2 becomes valid only by setting it first ON. Setting can be done from the programming
menu. Port2 RS-232 / RS-422 are selectable, but TTL and LVTTL are hardware related and fixed
at the factory. Only one port can be ON at a time (Port 1 or Port 2). Note that when the
programming mode (pin 12 connected to ground), is selected the modem will automatically use
Port 1 settings (COM1, 9600 bps, 8-bit data, none parity, 1 stop bit).

4.2.1 RS-232, interface, Port 2

Basic connection between a radio modem (PORT2 in RS-232) and a typical PC (COM-
port): 9-PIN D-CONN.
T
3
RD
2
SGND
5
T
RD
RTS
CTS
DSR
SGND
CD
DTR
+V
GND
25-PIN D-
T
2
RD
3
SGND
7
+V
GND
RADIO MODEM
T
RD
RTS
CTS
DSR
SGND
CD
DTR
Fuse
4A
+V
GND
Fuse
4A
23
SATELLINE-EASy
User Guide, Version 2.3
1
9
1
6
1
7
2
1
14,1
7,
RADIO MODEM
T
4
RD
3
SGND
7
DTR
1
+V
14,1
GND
7,
