Satel SATELLINE-EASy User Manual page 15

Additional setup
Error correction
Error check
Repeater
SL-commands
Priority
FullCR16 Check
Routing
Tests
When creating a test connection, you can use Windows™ based SATEL Configuration Manager
(available for free from authorised SATEL dealers or directly from SATEL Customer Support),
HyperTerminal (which is included in most the Windows™ based operating system packages), or
almost any other terminal program.
Basic settings for the serial port of the host computer, when using a terminal program to
communicate with SATEL radio modems, are as follows: "COM1, 9600 bps, 8-bit data, none
parity, 1 stop bit".
The power cable (+V
voltage and with a minimum output current of 2 A (for +3 ... +9 V PWR-module) and 1 A (for
+6 ... +30 V PWR-module).
Note: If you want to change the settings of a radio modem using the Programming Mode of
the radio modem with the help of an external terminal, the data speed of the terminal must
be 9600 bps.
OFF
OFF
OFF
ON
TX
OFF
OFF
OFF
and GND) must be connected to a power supply with a proper output
b
14
SATELLINE-EASy
User Guide, Version 2.3
ON/OFF
ON/OFF
ON/OFF
ON/OFF
RX/TX
ON/OFF
ON/OFF
ON/OFF
