- Page 1 IN32 1 8HR VIDEO DISTRIBUTION AMPLIFIER / LINE DRIVER 1–IN, 8–OUT IN32 1 8HR OPERATION MANUAL...
-
Page 2: Fcc Compliance
Para prevenir un incendio, reemplace solo con el mismo tipo de fusible. CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following... -
Page 3: Product Overview
CONTROLS section on page 3 and set the appropriate jumpers. 1. Place / install the IN3218HR at the desired location. Make sure that the unit is seated on a flat surface or is securely installed in a standard 19” equipment rack using an IN9080 rack shelf (optional). -
Page 4: Operation
Split Mode: The unit operates as two independent amplifiers (each input drives four outputs). In split mode operation, the IN3218HR can be used to amplify two separate composite video signals or to amplify a single S-Video signal, with the Y (luminance) signal connected to one input connector and the C (chrominance) signal connected to the second input connector. - Page 5 INTERNAL CONTROLS CAUTION: Adjustment of the IN3218HR internal controls must only be carried out by qualified technicians. Care must be taken to avoid static shock to the internal components. 1. Remove the screws from the sides of the unit. 2. Slide the top cover off.
-
Page 6: Specifications
Shipping Weight: 3 lbs. / 1.5 kg. Regulatory Compliance UL 1950, 3 Ed.; CE: EN60950-92; Safety CAN/CSA-22.2 No 950, 3 FCC class A; CE: EN55022 (1987), EN50081-1 (1991), EN50082-1 (1992 & 1994), EN60950-92 IN3218HR OPERATION MANUAL - REV. 1.0 01/04/01 ©2000 - INLINE, INC. -
Page 7: Troubleshooting
Solution 1: Make sure the power supply is plugged in and that the input and output cables are connected properly. Solution 2: Bypass the IN3218HR by connecting the input and output cables with a BNC barrel connector to ensure there is a video signal present. -
Page 8: Warranty
The information in this manual has been carefully checked and is believed to be accurate. However, INLINE, Inc. assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will INLINE, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
