Page 1: Operation Manual
Operation Manual IN3213 High Resolution 13W3 Distribution Amplifier IN3262 High Resolution VGA Distribution Amplifier... - Page 2 Installation and Safety Instructions For Models without a Power Switch: The socket outlet shall be installed near the equipment and shall be accessible. For Models with 110 / 220V Power Selector: Caution: Before applying power to this unit, the voltage selector must be set to the appropriate setting to match local A/C line voltage.
- Page 3 Installations und Sicherheitshinweise Für Geräte ohne Netzschalter: Die Netzsteckdose soll in de Nähe des Gerätes installiert und frei zugänglich sein. Für Geräte mit 110 / 220V Spannungswähler: Achtung: Bevor Sie dem Gerät Spann ung zuführen, muß der Spannungswähler entsprechend der Spannung des lokalen Wechselspannungsnetzes eingestellt werden.
- Page 4 CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following standards: EN50081-1 (1991), EN55022 (1987) EN50082-1 (1992 and 1994), EN60950-92...
-
Page 5: Input Compatibility
Since the units have two buffered outputs, they permit the signal from one computer graphics card to be split out to two display devices. The IN3213 / IN3262 are frequently used to amplify and split the computer’s video signal so it may be viewed on the local monitor and a second data display device such as an LCD panel, data projector or presentation monitor. -
Page 6: Installation
If no local monitor is connected to Output #1, a termination plug may be required as detailed below: IN3213 Used with Sun - The default mode is 61KHz if no local monitor is connected. If you wish to emulate a different mode, connect the appropriate Sun monitor to Output #1 or manually set the computer to a different resolution. -
Page 8: Specifications
IN3213 High Resolution 13W3 Distribution Amp. IN3262 High Resolution VGA Distribution Amp IN9204 - 9VDC; 500 mA Power Supply IN9204 - 9VDC; 500 mA Power Supply Operation Manual Operation Manual IN3213 / IN3262 OPERATION MANUAL - REV 1.1 09/05/00 ©1996, 1997 - INLINE, INC. -
Page 9: Troubleshooting
Solution: There needs to be a termination on the loop-through output. Use a local monitor or the IN9031 termination plug. The output image of the IN3213 / IN3262 is visible but has poor quality / low definition. Solution: The output cable may be too long or of poor quality. INLINE offers several high resolution mini-coax cables for analog signals and a series of shielded twisted pair cables designed specifically for digital video signal transmission. -
Page 10: Warranty
INLINE warrants the equipment it manufactures to be free from defects in materials and workmanship. If equipment fails because of such defects and INLINE is notified within two (2) years from the date of shipment, INLINE will, at its option, repair or replace the equipment at its plant, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.
