Lilin H.264 Instruction Manual

Full hd h.264 ip cameras
Hide thumbs
Table of Contents

Advertisement

Quick Links

Cameras
Full HD H.264 IP
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H.264 and is the answer not in the manual?

Questions and answers

Related Manuals for Lilin H.264

Summary of Contents for Lilin H.264

  • Page 1 Cameras Full HD H.264 IP INSTRUCTION MANUAL...

  • Page 2: Key Features

    Executive Summary Full HD IP Cameras, iMEGAPRO II, III, and V, adopts the latest compression technologies providing Quadruple Streaming of H.264 and JPEG in different resolutions. Quadruple Streaming technologies allow transmitting digital video at various bitrate and frame rate to fit both high and low bandwidth network environment.
  • Page 3 Support Android, iPad, and iPhone mobile live monitoring Dynamic DNS (DDNS) supported  Network time protocol (NTP) supported Support PCM/G.711 Support ONVIF protocol  Support CMX Software HD 3.6 Trademark Acknowledgments Microsoft, Windows 2000, Windows XP, Windows Vista, Windows 7, ActiveX, and Internet Explorer are registered trademarks of Microsoft Corporation in the U.S.
  • Page 4 Other References Mobile phone For free mobile surveillance, please refer to eMobile document in the product CD or download the document from our company web site. LILIN Universal ActiveX Control Sample code and document are included in product CD and can be downloaded from our company web site.

  • Page 5: Table Of Contents

    Chapter 2-3 Internet Browser Setting & Software Component Required ....8 Chapter 2-4 Login....................9 Chapter 3 Start Using H.264 FULL HD IP Camera Network Features ....10 Chapter 3-1 IP Camera Operational HTML Page ..........10 Chapter 3-2 IP Camera Main Page Controls............10 Chapter 3-2-1 ePTZ..................
  • Page 6 Chapter 3-5-3 Video Quality ................23 Chapter 3-5-4 Sense-Up Plus ................ 25 Chapter 3-5-5 Privacy Mask ................25 Chapter 3-5-6 Region of Interest (ROI) ............26 Chapter 3-6 IR Cut Removable ................27 Chapter 3-7 SD Card Recording ................. 27 Chapter 3-7-1 SD Card Recording Setting .............

  • Page 7: Chapter 1 System Overview

    Chapter 1-2 Software Requirements Merit LILIN Universal ActiveX software components are required for web interface displaying JPEG or H.264 FULL HD video. When you first time login the IP camera using Internet Explorer, it prompts for a security warning dialog box for downloading LILIN Universal ActiveX.

  • Page 8: Chapter 2 Before Accessing Ip Camera

    Chapter 2 Before Accessing IP Camera Before accessing the IP camera, make sure that the camera’s RJ-45 network cable, audio cable, and IP camera’s power cable are properly installed. For setup IP address, please consult your network administrator for available IP addresses.

  • Page 9: Chapter 2-2 Configure Ip Address Using Html Page

    After finishing above security settings, accessing H.264 FULL HD IP camera’s live video by default IP address of H.264 FULL HD IP camera using Internet Explorer will prompt a Security Warning dialog box. Click on OK button to download the...

  • Page 10: Chapter 2-4 Login

    The default settings of username and password are described as follows: Administrator Guest Username admin guest Password pass guest To logon the H.264 FULL HD IP camera, please type username and password in logon HTML page and click on Submit button to enter the system.

  • Page 11: Chapter 3 Start Using H.264 Full Hd Ip Camera Network Features

    Chapter 3 Start Using H.264 FULL HD IP Camera Network Features After login H.264 FULL HD IP camera as administrator, there are two main features—system operation and configuration. Operation and configuration features are described as follows: Chapter 3-1 IP Camera Operational HTML Page H.264 FULL HD Series operational HTML page layout...

  • Page 12: Chapter 3-2-1 Eptz

    Chapter 3-2-1 ePTZ To operate IP Camera DSP’s ePTZ, please enable ePTZ feature on the main page. A user can operate up, down, left, right, zoom in, zoom out, and presets on main page. When ePTZ is off, LILIN Universal ActiveX control also provides ePTZ (electronically pan, tilt, and zoom) feature.

  • Page 13: Chapter 3-2-2 Region Of Interest (Roi)

    Please use computer mouse pointing to the sub-window of PIP view. Dragging the sub-window can perform ePan and eTilt. Using mouse scroll button can perform zoom in and out features. Performing right-mouse click on the video can disable ePTZ feature. Chapter 3-2-2 Region of Interest (ROI) For D1 and below resolution, ROI feature can apply to the main video stream.

  • Page 14: Chapter 3-2-4 Two-Way Audio

    To playback the AVI video, simply click on Windows Media Player. Chapter 3-3 Configuration H.264 FULL HD IP camera’s administrator can configure H.264 FULL HD IP camera via standard HTML web page. This chapter explains the detail of each configuration setting.

  • Page 15: Chapter 3-3-1 Server Settings

    Device Name The device name can be used by IPScan utility to identify the H.264 FULL HD IP camera To change the device name, enter the name for H.264 FULL HD IP camera and click on Submit button.

  • Page 16: Chapter 3-3-2 User Settings

    There are ten user accounts allowed for the system. Each account can be configured for its access rights. To add/edit a user, please click on Add/Edit User button. To access H.264 FULL HD IP camera without authentication, set Bypass Logon radio button to ON.

  • Page 17: Chapter 3-3-3 Timer

    Chapter 3-3-3 Timer H.264 FULL HD IP camera allows a user to change system timer via standard HTML web page. To change H.264 FULL HD IP camera’s system timer, please enter the date and time in the edit boxes. Click on Submit button to apply this operation.

  • Page 18: Chapter 3-4 Network

    Network general settings are the basic settings connecting H.264 FULL HD IP camera to the network. The default IP Address of H.264 FULL HD IP camera is 192.168.0.200. A user can use this IP address to verify the network connection between a local PC and H.264 FULL HD IP camera using Internet Browser.

  • Page 19: Chapter 3-4-2 Dhcp Setting

    Since the DHCP may assign a different IP address to the H.264 FULL HD IP camera after power off, a user can use IPScan utility to launch Internet browser for searching H.264 FULL HD IP camera.

  • Page 20: Chapter 3-4-3 Http & Rtsp Service

    Chapter 3-4-3 HTTP & RTSP Service HTTP protocol is a reliable protocol for sending video streaming. Port forwarding technology can be used for sending video over Internet. The detail is described in the appendix. For changing HTTP service’s port number, please consult available port number from your network administrator.

  • Page 21: Chapter 3-4-5 Ftp Service

    E-mail receiver setting E-mail address— E-mail address of the recipient E-mail sender setting E-mail address— E-mail address of the sender Auto E-mail sent with snapshot—constantly send JPEG snapshot within E-mail dwell time. SMTP server— Sender’s SMTP server Authorization— SMTP server’s authorization option if applicable Authorization account—...

  • Page 22: Chapter 3-4-6 Ddns Settings

    FTP server IP/DNS— IP address or domain name of the FTP server Account— Account of the FTP server Password— Password of the account Directory—File path for storing the JPEG snapshots Prefix—Prefix of the JPEG filename Date format—Date format string for the JPEG filename Postfix—Postfix of the JPEG filename Auto FTP sent—Constantly send JPEG snapshot within FTP dwell time.

  • Page 23: Chapter 3-5 Video Settings

    Chapter 3-5 Video Settings This section describes the details in setting the H.264 FULL HD video’s attributes. Bit rate control, video input, and video resolution, settings can be configured. Chapter 3-5-1 Video General For transmitting H.264 FULL HD video over low bandwidth network such as Internet, please set the bit rate close to network upload bandwidth.

  • Page 24: Chapter 3-5-2 Weighted Streaming Mode

    Bit Rate: Maximum bit rate available for a network connection Output Frame Rate: the frame rate of the profile GOP: I frame period per second Video Output: NTSC/PAL video system Power line frequency: 60Hz/50Hz lighting power frequency Chapter 3-5-2 Weighted Streaming Mode Weighted streaming mode is activated when an alarm went off.
  • Page 25 To setup Exposure Control, Automatic Gain Control, White Balance Control, please adjust the value accordingly. To increase, the sensitivity at nights, please adjust Sense Up feature. Exposure Value: Adjust the value of the image exposure WDR: Enable or disable wide dynamic range feature. Black-light Compensation: Increase the exposure to the darker object.

  • Page 26: Chapter 3-5-4 Sense-Up Plus

    No Sense-Up 3 Frame Sense-Up Chapter 3-5-4 Sense-Up Plus Sense-Up Plus feature is for low-light and high sensitivity DSP control enabling outstanding video quality at difficult environment. Sense-Up Plus technology can be used for both black-n-white and/or color video mode. To do so, please first enable Auto Gain Control (AGC) setting.

  • Page 27: Chapter 3-5-6 Region Of Interest (Roi)

    Chapter 3-5-6 Region of Interest (ROI) Region of interest (ROI) feature is for sub-stream (D1 or CIF) video buffer to scale and to crop on main video buffer (1080P) to meet best-fit video area. The major purpose is to use sub-stream for saving storage or bandwidth. Not Important Area Crop &...

  • Page 28: Chapter 3-6 Ir Cut Removable

    Chapter 3-6 IR Cut Removable IR Cut removable allows to schedule IR activation by (1) auto, (2) day, (3) night, or (4) schedule. When the setting is set to "Auto", IR activation is determined by the light sensor. "Night" setting means that the IR cut filter is removed. "Day" setting means that the IR cut filter is forced to be always on.
  • Page 29 SD Recording: Enable SD card recording. Alarm/Motion Triggering: Digital input, face detection, tampering detection, and motion detection SD card recording. Recording Time: Post alarm recording time. Continuous: Continuous recording mode No Network Activity: If there is no network connection, perform SD recording.

  • Page 30: Chapter 3-8 Alarm Settings

    FTP archiving can be found at this section. Chapter 3-8-1 Motion/Alarm Setup There are motion detection zones allowed in the H.264 FULL HD IP camera. A user can enable the detection zones with different sensitivities ranging from 1 to 99 (highest to lowest) for motion detection.

  • Page 31: Chapter 3-8-4 Face Detection

    Chapter 3-8-4 Face Detection The video analytics contains face detection engine. There are up to 4 faces can be detected. Each face should be at least 1/20 out of the video size for recognition purpose. Once a face is detected, the alarm output, e-Mail with a snapshot, and/or an FTP snapshot can be triggered.

  • Page 32: Chapter 3-8-5 Audio Detection

    Chapter 3-8-5 Audio Detection For audio model, the IP camera has audio detector detecting acoustic level. If the volume exceeds the audio sensitivity value, audio detector triggers an alarm for notification. Chapter 3-8-6 Tampering Detection The IP camera’s video analytics engine is able to detect tampering. Tampering detection works (1) lens spray paint prevention, (2) camera move prevention, and (3) out of focus prevention.

  • Page 33: Chapter 3-9 Audio Setting

    Chapter 3-9 Audio Setting Audio setting is based on the following: MIC Volume: MIC or line input volume Audio Input Mode: Choose MIC input or Line input. Audio Input Gain: Voice input gain magnification Audio Output Volume: Line output volume adjustment Audio Coding Type: G.711 u-Law Sample Rate: Audio sample rate Bit Rate: Audio bit rate.

  • Page 34: Appendix

    Internet. When ISP re-assigns a new IP address to H.264 AVC IP camera, H.264 AVC IP camera notifies DDNS service. A remote PC can access H.264 AVC IP camera by typing domain name in a browser.

  • Page 35: Advance Network Port Forwarding Technology

    Advance Network Port Forwarding Technology Port forwarding technology is an advanced network technology which is widely used for using one global IP shared by many network devices. The network architecture is illustrated as below. Port 80 of the router (61.220.86.166) is assigned to the device IP address, 192.168.0.10.

  • Page 36: Specification

    JPEG 720x480 25 FPS, JPEG 352x240 25 FPS Multiple profile Up to H.264 1280x720 30 FPS, H.264 720x480 30 FPS, JPEG 352x240 25 FPS Up to H.264 1920x1080 30 FPS, H.264 720x480 30 FPS, JPEG 1280x720 25 FPS Up toH.264 1920x1080 30 FPS, H.264 720x480 30 FPS, JPEG 720x480 25 FPS...
  • Page 37 DISTRIBUTOR： 66-IP43ASOOE-1...

This manual is also suitable for:

Imegapro iiImegapro iiiImegapro v
