Cable Connection

1) Cut the zip tie holding the power cord to the back of the monitor.
2) Connect the power cord to an AC outlet.
3) Press the monitor power switch to the ON position.
WARNINGS:
• The main power must be turned on and off with the monitor power switch. Do not connect or disconnect the power cord or turn
the breaker on and off while the monitor power switch is on.
• When switching the monitor power switch or the POWER button off and and back on, always wait for at least 5 seconds. For
complete electrical disconnection, pull out the main plug.

Turning the INF7020 On/Off

The computer module, sound bar and monitor function independently. Each component must be controlled separately.
TO TURN THE INF7020 ON
1) Press the computer module POWER button located on the back of the monitor.
2) Press the POWER button located on the front of the monitor (or use the monitor's remote).
3) If installed, press the sound bar POWER button on. The computer module, monitor and sound bar turn on.
INF7020 Quick Setup Guide
TOUCH PANEL LED
POWER LED
POWER BUTTON
Page 3
