Summary of Contents for InFocus INF6501C
- Page 1 USER GUIDE INF6501C / INF6501W 009-1544-02...
-
Page 3: Table Of Contents
What’s Included...................................... 7 Setup ........................................8 Mounting ......................................8 Connecting to other devices ................................9 Insert LightCast key (INF6501c only) ............................. 12 Connecting AC Power ..................................12 External PC Touchscreen Control Setup ............................12 Turning the Monitor On/Off ................................. 12 Using the Remote .................................... - Page 4 OSD (On-Screen Display) Menu System ............................... 40 Picture menu ....................................41 Screen menu ....................................42 Audio menu ....................................43 PIP menu......................................44 Configuration 1 menu ..................................45 Configuration 2 menu ..................................46 Advanced Option menu ................................. 47 Troubleshooting ....................................48 Specifications ......................................
-
Page 5: Declaration Of Conformity
SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. All other trademarks are the property of their respective owners. Any other trademarks, service marks, personal names or product names are assumed to be the property of their respective owners and are used only for reference. -
Page 6: Safety Considerations
This document applies to regulatory model: INF6501c Input ratings: AC 100-240V AC, 2.5A, 50/60Hz InFocus reserves the right to alter product offerings and specifications at any time without notice. Safety Considerations Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source. -
Page 7: 安全資訊
Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty. •... - Page 8 • 如果您需要使用附帶的超細纖維清潔布進行清潔，請拔掉顯示器插頭。電源關閉時，可使用清潔布擦拭螢幕。切勿在顯 示器上使用酒精、溶劑或含氨 液體。 • 操作顯示器附帶的線纜後需要洗手。 • 顯示器遙控器利用電池工作。一些型號在發運時還附有採用電池工作的滑鼠和鍵盤。請確保電池極性 (+/-) 正確對齊。按 照當地廢棄物品處理法規處理 廢舊電池。 • 僅使用符合此產品規格的適當耐火等級牆和支架安裝硬體，並遵守製造商的安裝指示。由額定安裝硬體使用不當或安裝 不當造成的任何損壞均不在保 修範圍內。 • 請向專業維修人員諮詢所有維修資訊。請勿卸下封蓋或封底。自行維修顯示器不僅會對您造成傷害，而且也會使保修失 效。 • 僅使用 InFocus 指定的更換零件。未經授權進行更換可能會造成火災、電擊或人身傷害，並可能使保修失效。 • 將顯示器安裝到牆上時，必須使用 8 枚公制（12 毫米）螺絲。此外，安裝介面應符合北美地區的 UL1678 標準。安裝方 法應結實牢固，足以承受顯 示器的重量（參見產品技術規格）。 • 遵守這些指示有助於確保使用壽命內顯示器的圖像品質。不遵守這些指示可能會影響保修。 • 鋰電池注意事項（僅適用于發運時配有內嵌 PC 箱的型號）：如果更換的電池類型不正確，可能會有爆炸的風險。應按 照製造商的建議，使用相同或同類型的電池進行更換。按照當地廢棄物品處理法規處理廢舊電池。 Page 6...
-
Page 9: What's Included
(batteries not included) VESA cable Power cord LightCast key (varies per country) (INF6501c only) For additional accessory options, such as stands, feet, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. INF6501c/INF6501w User Guide Page 7... -
Page 10: Setup
Setup Mounting This product does not ship with mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • Only use properly rated wall and stand mounting hardware that meet this product’s specifications and follow the manufacturer installation instructions. -
Page 11: Connecting To Other Devices
(1), HDMI (4), VGA, Component, RS232 for serial control, Audio In 3.5mm, Audio RCA In L/R, Audio RCA Out L/R. USB 3.0 Type A Connect a USB device to one of the USB Type A 3.0 connectors (e.g. a USB 3.0 / 2.0 hard drive). INF6501c/INF6501w User Guide Page 9... - Page 12 Address: 13190 SW 68th Parkway Part No./ INF6501c 50642P650202H**(B)** Part Number: INF6501c Suite 200, Portland, OR 97223-8368 Bottom panel (left to right) Power switch Press it to the ON position to turn on the monitor, and press it to the OFF position to turn the monitor off.
- Page 13 Connect a 3.5mm audio cable to an external device (e.g., iPod player). AUDIO IN2 Connect a RCA L/R audio cable to an external device (e.g., DVD player). AUDIO OUT Connect an RCA L/R audio cable to external stereo speakers. INF6501c/INF6501w User Guide Page 11...
-
Page 14: Insert Lightcast Key (Inf6501C Only)
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer. -
Page 15: Using The Remote
Do not mix new and old batteries or different types of batteries together. • Replace the batteries as soon as they run out. • Remove batteries from the remote control when storing or not in use for a prolonged period. INF6501c/INF6501w User Guide Page 13... - Page 16 Remote buttons Power: Switches the power on or puts the monitor into Standby. POWER Home: Changes the active source back to the embedded PC. HOME Input: Toggles the Input Source menu on and off, which allows the user to change INPUT sources.
-
Page 17: Using The Keypad
Press to navigate to the down in the OSD menu. Press to navigate to the up in the OSD menu. Press to display or exit the OSD menu. Press to toggle between source inputs. Turns the power on and off. INF6501c/INF6501w User Guide Page 15... -
Page 18: First Time Use
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer. - Page 19 Cast: displays instructions on how to wirelessly display your computer, tablet, or phone content on the panel using LightCast, AirPlay, or Miracast. Whiteboard: provides a Whiteboard for capturing meeting notes and annotation. Browser: provides access to the internet. INF6501c/INF6501w User Guide Page 17...
-
Page 20: Lightcast Casting
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer. -
Page 21: Airplay
Select the device name listed in step 3 of the Connect with AirPlay window. Using an OS X device Select the Airplay icon from the menu bar on OS X device. Select the device name listed in step 2 of the Connect with AirPlay window. INF6501c/INF6501w User Guide Page 19... -
Page 22: Miracast
Miracast MiraCast can make an adhoc network connector over Wifi, however you must have an Android or Windows device (Windows 8.1 or above) with embedded MiraCast in order to use the MiraCast feature on this monitor. In addition, your network must follow Miracast configuration guidelines as specified by the Wi-Fi Alliance (www.wi-fi.org). -
Page 23: Whiteboard
Draw on the whiteboard canvas with your finger or the stylus. TIP: Keep other objects, including writing utensils, other fingers, and knuckles away from the drawing surface to draw your image cleanly. Use Eraser, Select, Undo, and Redo to modify the drawing. See "Whiteboard Tools" on page 29 for more information. INF6501c/INF6501w User Guide Page 21... -
Page 24: Import An Image
Import an image Supported image types include JPEG, PNG, BMP, GIF, and TIFF. Tap More. Tap Import. Choose Internal to import an image that has been saved to the monitor or External Storage to import an image that is located on an external device, such as a USB thumb drive. - Page 25 While the object is highlighted, drag it to the desired location and re-size it as needed using the sizing handles. In addition, you can cut, copy, paste, and delete it using the features in the Select submenu. Tap Cancel when finished. INF6501c/INF6501w User Guide Page 23...
-
Page 26: Modify Whiteboard Canvas Objects
Modify whiteboard canvas objects Tap Select. Tap and drag your finger or the stylus across the objects you would like to select. The objects are outlined. To copy the selected objects: tap Copy and tap Paste. While the objects are selected, drag them to the desired location. To cut the objects and place them on a different page of the whiteboard canvas: tap Cut. -
Page 27: Save The Whiteboard Canvas
For JPG and PDF file types, tap Current view to save the visible portion of the canvas or tap Whole view to save the entire can- vas. Note: Whole view creates multiple pages and requires extra time to complete. Enter the desired file location or accept the default location. Tap Save. INF6501c/INF6501w User Guide Page 25... -
Page 28: Save The Whiteboard Canvas To A Usb Thumb Drive
Save the whiteboard canvas to a USB thumb drive Tap More. Tap USB. Type a file name in the Name text box. Select the file type: File Type Option Choose this file type if you want to... DigiEasel saves the whiteboard file for future editing. creates an image file. -
Page 29: Open A Whiteboard File
Whiteboard file from a USB thumb drive, tap the USB icon at the top of the Open Files window, and navigate to the desired USB thumb drive. Navigate to the desired folder and tap the file you wish to open. INF6501c/INF6501w User Guide Page 27... -
Page 30: Open A Whiteboard File From A Usb Thumb Drive
Open a whiteboard file from a USB thumb drive Tap More. Tap USB. Tap Open. If the whiteboard canvas contains objects, you will be prompted to save the existing canvas. Select Save to save the existing canvas or select Don't save to delete the existing canvas and open a new one. (Cancel returns the user to the current canvas.) Navigate to the desired folder and tap the file you wish to open. -
Page 31: Whiteboard Tools
Tap to use a pen. NOTE: Opacity control is not available for the pen object. Highlighter Tap to use a highlighter. Rectangle Tap to draw a rectangle. Circle Tap to draw a circle. Line Tap to draw a line. INF6501c/INF6501w User Guide Page 29... - Page 32 Laser Tap to highlight something temporarily. The red laser mark disappears when a new mark is made. Laser marks cannot be saved. Select Tap Select. Tap and drag the selection box around the drawing objects which you want to move, copy or delete. Tap and drag the selected objects to move them.
- Page 33 Tap to send an email with an attachment of the whiteboard canvas as either a JPG or PDF file. Tap to save or open files from an external USB thumb drive. Setting Tap to access the Setting menu. Next Tap to go to the next page. INF6501c/INF6501w User Guide Page 31...
-
Page 34: Lightcast Browser
If your monitor did not ship with a LightCast key and you would like to use the LightCast Browser features, you can purchase a Light- Cast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer. -
Page 35: Lightcast Settings
If your monitor did not ship with a LightCast key and you would like to use the LightCast features, you can purchase a LightCast key (p/n INA-LCKEY1, INA-LCKEY2, or INA-LCKEY3 depending on your region) from InFocus (www.infocusstore.com) or your local dealer. -
Page 36: Set Up Bluetooth
Set up Bluetooth From the Network Settings section of the Settings menu, tap Bluetooth Settings. The Bluetooth submenu displays. Tap On to use a Bluetooth device. If the list of available (or already paired) devices does not automatically display, tap the Refresh button. Tap the desired device and follow the onscreen prompts to pair your device to this monitor. -
Page 37: Software Version
Reset to factory default settings From the Systems and Security section of the Settings menu, tap Firmware Update. Tap the Factory Reset check box to place a check mark in it. Tap the Reset button. INF6501c/INF6501w User Guide Page 35... -
Page 38: Reboot The Monitor
Reboot the monitor From the Systems and Security section of the Settings menu, tap Reboot to reboot this monitor. The monitor reboots immediately. Reset the registration parameters From the Systems and Security section of the Settings menu, tap Reset to register the monitor with new information. Tap Yes to initi- ate the registration process. -
Page 39: Resize The Image
From the Systems and Security section of the Settings menu, tap Resize to digitally zoom the Display window smaller or larger, up to 100%. Define the default email address From the Accounts section of the Settings menu, tap to update the default email address. Tap OK when done. INF6501c/INF6501w User Guide Page 37... -
Page 40: Request Desktop Site
Request desktop site To use a desktop formatted website, tap to select the Request Desktop site check box. Otherwise a mobile web site will be used. Define the default browser home page From the Browser Preferences section of the Settings menu, tap to update the default browser home page. Tap OK when done. Page 38... -
Page 41: Update A Monitor Without Lightcast Key
Insert a USB thumb drive with the software update on it into an available USB slot or navigate to the network . Follow the prompts to update the software, or tap OK, if the software is already up-to-date. Tap the X in the upper-right corner to close the Settings window. INF6501c/INF6501w User Guide Page 39... -
Page 42: Osd (On-Screen Display) Menu System
OSD (On-Screen Display) Menu System The OSD provides the user the ability to control the monitor display. To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the monitor. Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu. -
Page 43: Picture Menu
Range: 0-100 for each color. Picture Mode: provides different preset picture modes to choose from. Options include: Standard (default), HighBright, and Soft. Picture Reset: resets all Picture menu items to factory default settings. Options: Yes and No. INF6501c/INF6501w User Guide Page 41... -
Page 44: Screen Menu
Screen menu H Position: adjusts the horizontal position of the image. Range: 0-100. (Default 50.) V Position: adjusts the vertical position of the image. Range: 0-100. (Default 50.) Clock: adjusts the width of the image (For VGA input only). Range: 0-100. (Default 50.) Clock Phase: adjusts the focus, clarity and stability of the image (For VGA input only). -
Page 45: Audio Menu
Audio Source: selects the audio input source. Options include: HDMI 1, HDMI 2, HDMI 3, HDMI 4, Lightcast, Audio 1, and Audio 2. Audio Reset: resets all Audio menu items to factory default settings. Options: Yes and No. INF6501c/INF6501w User Guide Page 43... -
Page 46: Pip Menu
PIP menu PIP Size: changes the size of the PiP window used in the Corner-to-Corner configuration. Options include: Small (default), Middle and Large. PIP Audio: switches the audio source from the main source to the PiP source. Options include: Main (default) and Sub. PIP Reset: resets all PIP menu items to factory default settings. -
Page 47: Configuration 1 Menu
(default), Lightcast, and External. Configuration Reset: resets all Configuration 1 and Configuration 2 menu items to factory default settings. Options: Yes and No. Factory Reset: resets all menu items to factory default settings. Options: Yes and No. INF6501c/INF6501w User Guide Page 45... -
Page 48: Configuration 2 Menu
Configuration 2 menu OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 10) Freeze: When enabled, freezes the image which is currently displayed. Options: On and Off (default). OSD H Position: adjusts the horizontal position of the OSD menu. Range: 0-100. (Default: 50) OSD V Position: adjusts the vertical position of the OSD menu. -
Page 49: Advanced Option Menu
Unlock (default; keypad is enabled). DDC/CI: enables and disables DDC/CI communication. Options include: On (default) and Off. Advanced Option Reset: resets all Advanced Option menu items to factory default settings. Options: Yes and No. INF6501c/INF6501w User Guide Page 47... -
Page 50: Troubleshooting
Troubleshooting SYMPTOM POSSIBLE SOLUTIONS No power • Verify the power cord is properly connected to the power outlet and to the monitor. • Verify the power switch is ON and that the Power button on the remote or keypad has been turned on (the front LED should be on). - Page 51 The monitor is in standby mode. Press the Power button on the remote or keypad. Green • The monitor is powered on. Orange • The source signal is out of range. For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support INF6501c/INF6501w User Guide Page 49...
-
Page 52: Specifications
Specifications To read the latest product specifications, be sure to visit our support website at www.infocus.com/support, as specifications are subject to change. Size (viewable) 1428.5mm (H) x 803.5mm (V) Dimensions (without stand) 60.2" (W) x 36.4" (H) x 3.3" (D); 1529.18 mm (W) x 924.22 mm (H) x 84.7 mm (D) Weight (without stand) 110.23 lbs / ~50.0 kg... -
Page 53: Limited Warranty
If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new... - Page 54 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced. In addition, LCD burn-in as a result of excessive display of static images on the product is not covered under the terms of this Limited Warranty.
- Page 55 Distributors originally sold the hardware product. InFocus will provide warranty service either (i) at an ASP location, where service is performed at the location, or the ASP may send the product to an InFocus repair service location for service, (ii) by sending you pre-...
- Page 56 Upon receipt of the replacement product or part, the original product or part becomes the property of InFocus and you agree to fol- low instructions, including arranging the return of original product or part to InFocus in a timely manner. When providing a product exchange or Customer Self Repair (CSR) part requiring the return of the original product or part, InFocus may require a credit card au- thorization as security for the retail price of the replacement product or part and applicable shipping costs.
