HARDWARE GUIDE
INF8022
009-1624-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INF8022 and is the answer not in the manual?

Questions and answers

Related Manuals for InFocus INF8022

Summary of Contents for InFocus INF8022

  • Page 1 HARDWARE GUIDE INF8022 009-1624-01...

  • Page 3: Table Of Contents

    CONTENTS Declaration of Conformity ..............................3 Safety Considerations .................................4 安全資訊 ....................................5 Information about this Hardware Guide ..........................6 What’s Included ..................................7 Setup ....................................8 Mounting ..................................8 Attaching the speakers ..............................9 Attaching the HD video conferencing camera ......................10 Connecting to other devices ............................11 Connecting AC power ..............................14 External PC touchscreen control setup ........................14 Turning the Monitor On/Off ...............................14 Setting up the Wireless Mouse and Keyboard ........................15...

  • Page 5: Declaration Of Conformity

    Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. SRS TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.

  • Page 6: Safety Considerations

    SAFETY CONSIDERATIONS Please read and follow all safety instructions provided below and on the monitor before connecting the monitor to a power source. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and may damage or impair protection provided by the equipment.

  • Page 7: 安全資訊

    • Refer all service to qualified service personnel. Do not remove the cover or back. Servicing your own monitor can be dangerous to you and will void the warranty. • Only use replacement parts specified by InFocus. Unauthorized substitutions may result in fire, electrical shock or injury and may void the warranty.

  • Page 8: Information About This Hardware Guide

    Although this product comes pre-installed with the Mondopad software, you must first assemble the product. This Hardware Guide will assist you in setting up the INF8022. After the product is fully installed, please refer to the Mondopad Software Guide at www.infocus.com/support for more information.

  • Page 9: What's Included

    (varies per country) *Not included for all countries. For setup purposes, a keyboard and mouse are recommended. For additional accessory options, such as stands, feet, carts and wall mounts, see the InFocus website (www.infocus.com/store) or your local dealer. INF8022 Series Hardware Guide...

  • Page 10: Setup

    SETUP Mounting This product does not ship with mounting accessories. Only use commercially manufactured mounting accessories which meet this product's specifications and follow the manufacturer installation instructions. • Only use properly rated wall and stand mounting hardware that meet this product’s specifications and follow the manufacturer installation instructions.

  • Page 11: Attaching The Speakers

    The speakers can be installed as desired around the perimeter of the monitor using the supplied brackets, however NOTE: InFocus recommends installing the speakers across the bottom of the monitor. If you are not attaching the speakers, proceed to the next section, "Attaching the HD video conferencing camera" on page 10.

  • Page 12: Attaching The Hd Video Conferencing Camera

    Connect one end of the AC power cord to the AC In jack on the back of the speakers. Connect the other end of the AC power cord to the AC Out jack on the bottom connector panel of the monitor. ON/OFF POWER INPUT...

  • Page 13: Connecting To Other Devices

    Audio In 3.5mm (2), Audio In RCA (1-R/L), and Audio Out RCA (1-R/L). USB ： used for the external camera. Antennas TOUCH CONTROL USB-A USB-A RJ45 RJ45 RS232 IN 1 Audio IN 2 Audio OUT HDMI PC IN COMPONENT INF8022 Series Hardware Guide Page 11...
  • Page 14 TOUCH TOUCH CONTROL Connect a Type A to Type B USB cable from the monitor to an external CONTROL computer in order to use the touchscreen gestures on the monitor. Connect a wireless mouse, USB thumb drive or other USB device to this USB 1-4 USB Type A connector.
  • Page 15 Connect a 3.5mm audio cable to an external device (e.g., iPod player). Audio OUT AUDIO IN2 Connect an RCA L/R audio cable to an external device. AUDIO OUT Connect an RCA L/R audio cable to external stereo speakers. INF8022 Series Hardware Guide Page 13...

  • Page 16: Connecting Ac Power

    Connecting AC power Connect one end of the AC power cord to the AC In jack on the back of the monitor. Connect the other end of the AC power cord to an AC outlet. Press the power switch. (The LED on the front of the monitor turns on.) NOTES: • Your monitor should only be operated from the power source indicated on the label.

  • Page 17: Setting Up The Wireless Mouse And Keyboard

    Insert two (2) AAA batteries (not included) into the keyboard, by aligning the + and – ends of the batteries and sliding them in place. Replace the cover. Press the CONNECT button and hold it for one second to allow the keyboard to bind with the dongle. INF8022 Series Hardware Guide Page 15...

  • Page 18: Using The Remote

    USING THE REMOTE The remote uses two (2) AAA batteries (not included). Install the batteries by removing the cover from the remote’s back, aligning the + and – ends of the batteries, sliding them in place and replacing the cover. To operate, point the remote at the monitor sensor at the bottom right-hand corner of the monitor.
  • Page 19 Onscreen Menu features. Info: Displays source information. INFO Vol up: Increases the audio volume. VOL UP Vol down: Decreases the audio volume. VOL DOWN Mute: Switches the audio on or off. MUTE INF8022 Series Hardware Guide Page 17...
  • Page 20 Freeze: When enabled, freezes the image which is currently displayed. Blank: Toggles between the source and a blank black screen. Dimming: Adjusts brightness level. Page 18...

  • Page 21: Using The Keypad

    > button: When the OSD menu is on, this button increases the value of selected OSD items. When the OSD menu is off, this button increases the audio volume. Menu button: Turns the OSD menu on and off. INF8022 Series Hardware Guide Page 19...

  • Page 22: Osd (On-Screen Display) Menu System

    OSD (ON-SCREEN DISPLAY) MENU SYSTEM The OSD provides the user the ability to control the monitor display. To access the OSD, press the Menu button on the remote or the keypad located on the right-hand side of the monitor. Use the up and down arrows on the remote or keypad to scroll through the menu options and press OK to enter the highlighted menu.

  • Page 23: Picture

    User to access this feature. Range: 0-100 for each color. Picture Mode: provides different preset picture modes to choose from. Options include: Standard (default), HighBright, and Soft. Picture Reset: resets all Picture menu items to factory default settings. Options: Yes and No. INF8022 Series Hardware Guide Page 21...

  • Page 24: Screen

    Screen SCREEN H POSITION V POSITION CLOCK CLOCK PHASE BLANK DIMMING ASPECT RATIO WIDE SCREEN RESET < > Adjust Enter Back Quit H Position: adjusts the horizontal position of the image. Range: 0-100. (Default 50.) V Position: adjusts the vertical position of the image. Range: 0-100. (Default 50.) Clock: adjusts the width of the image (For VGA input only).

  • Page 25: Audio

    Audio Source: selects the audio input source. Options include: HDMI 1, HDMI 2, HDMI 3, DisplayPort (DP), PCSpeaker, Mondopad, Audio 1, and Audio 2. Audio Reset: resets all Audio menu items to factory default settings. Options: Yes and No. INF8022 Series Hardware Guide Page 23...

  • Page 26: Pip

    PIP MODE PIP INPUT PIP POSITION TOP-RIGHT PIP SWAP PIP SIZE SMALL PIP AUDIO MAIN PIP RESET < > Adjust Enter Back Quit PIP Mode: enables or disables Picture-in-Picture mode. Options include: Yes and No. PiP Input: selects the source input for the PiP window. Options include: HDMI1, HDMI2, HDMI3, DisplayPort, Mondopad, VGA, Component.

  • Page 27: Configuration 1

    Options: Auto (default), Mondopad, and External. Configuration Reset: resets all Configuration 1 and Configuration 2 menu items to factory default settings. Options: Yes and No. Factory Reset: resets all menu items to factory default settings. Options: Yes and No. INF8022 Series Hardware Guide Page 25...

  • Page 28: Configuration 2

    Configuration 2 CONFIGURATION 2 OSD TURN OFF FREEZE OSD H POSITION OSD V POSITION OSD ROTATION PORTRAIT MONITOR INFORMATION < > Adjust Enter Back Quit OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 10) Freeze: When enabled, freezes the image which is currently displayed.

  • Page 29: Advanced Option

    Unlock (default; keypad is enabled). DDC/CI: enables and disables DDC/CI communication. Options include: On (default) and Off. Advanced Option Reset: resets all Advanced Option menu items to factory default settings. Options: Yes and No. INF8022 Series Hardware Guide Page 27...

  • Page 30: Troubleshooting

    TROUBLESHOOTING SYMPTOM POSSIBLE SOLUTIONS No power • Verify the power cord is properly connected to the power outlet and to the monitor. • Verify the power switch is ON and that the Power button on the remote or keypad has been turned on (the front LED should be green). • Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage.
  • Page 31 • An HDMI® 1.3 (or higher) source and source device is required to hear audio via the HDMI cable. Video camera is not in focus • Verify that the plastic protecting the camera lens has been removed. INF8022 Series Hardware Guide Page 29...
  • Page 32 Verify that the power switch on the back of the unit is turned on; 3) Plug another electrical device to the power outlet to verify that the outlet is supplying the proper voltage. For additional troubleshooting support, please contact: InFocus Corporation - Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support...

  • Page 33: Limited Warranty

    If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, InFocus will either (1) repair the hardware defect at no charge, using new parts or refurbished...
  • Page 34 (l) if the product is not used under normal operating conditions which are defined as use not in excess of 16 hours continuously per day with a minimum 8 hour period of continuous rest in the powered off state; or (m) if any InFocus serial number has been removed or defaced.
  • Page 35 InFocus will provide warranty service either (i) at an ASP location, where service is performed at the location, or the ASP may send the product to an InFocus repair service location for service, (ii) by sending you prepaid...
  • Page 36 If during the diagnosis period, InFocus identifies that the repair can be accomplished by the use of a CSR part, InFocus will ship that part directly to you for replacement. There are two categories of CSR parts: • Parts for which customer self repair is mandatory. ...
  • Page 37 InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, OR 97223-8368 USA © 2016 InFocus Corp. All rights reserved. InFocus and the InFocus logo are trademarks of InFocus Corp., registered in the U.S. and other countries.

  • Page 38: 安全注意事項

    安全注意事項 在將顯示器連接到電源之前，請仔細閱讀並遵守顯示器上提供的下述安全說明。如不遵守安全說明則可能導致火災、觸電或 人身傷害，並可能損壞或 損害對設備所提供的保護。 請妥善保存所有安全說明。 • 這種顯示器是非常沉重的，應由至少兩個人進行搬動和安裝。不要試圖自行搬動或安裝顯示器，否則可能造成傷害和/ 或損害。 • 搬動顯示器時，利用手柄和側板或底板始終牢固地把持住顯示器。不要把持頂板。 • 在搬動顯示器紙箱時，不要傾斜或倒置紙箱。始終將其保持在豎直方向。 • 在移動顯示器前，請斷開所有配件和電纜。 • 如果顯示器安裝在牆上，顯示器與牆壁之間的距離至少保持為 1.98 英寸（5釐米），以提供足夠的通風。 • 請參閱正確的開機和關機程式方面的指南。 • 遵循本手冊和顯示器上的所有警告和注意事項。 • 顯示器的安放位置遠離加熱和冷卻通風孔至少 4 英尺（1.2米）。 • 請勿堵塞通風口。顯示器放在通風良好且不阻礙進氣口和排氣口的地方。 • 不要在諸如散熱器、熱記錄器、火爐或其他發熱設備（包括放大器）等熱源附近安裝或使用顯示器或揚聲器。 • 不要將顯示器放置在陽光直射、潮濕、油膩或灰塵較多的地方，或顯示器可能接觸到雨水、煙霧或蒸汽的地方。 • 顯示器使用的電源線不應該靠近水，例如靠近浴缸、洗臉盆、廚房水槽、游泳池等。 • 不要在靠近水的地方使用顯示器的任何元件，包括揚聲器。警告：為減少火災或觸電的危險，請勿將本設備和該設備的 任何元件淋雨或受潮。 • 請勿摔落顯示器。 • 不要將液體灑在顯示器上。濺落的液體可能損壞顯示器。...
  • Page 39 • 只使用富可視公司指定的更換零部件。未經認可的代用品可能會導致火災、觸電或人身傷害，並可能導致保修失效。 • 在將顯示器安裝到牆上時，必須使用 M8 (12 毫米) 規格的螺栓。此外，安裝介面應符合北美 UL1678 標準。安裝方 式應牢固到足以承受顯示器的重量。 • 請遵照以下說明，以確保顯示器使用壽命期間的圖像品質。不遵守這些說明可能會影響保修。 • 鋰電池（PC 主機殼中的）注意事項：如果更換的電池類型不正確，則有爆炸的危險。更換的電池應為相同類型，或製 造商推薦的等效類型。根據當地 處理法規處理廢舊電池。 INF8022 Series Hardware Guide Page 37...

  • Page 40: Mondopad 80"顯示器I/O Port 介紹前/後面板

    Mondopad 80"顯示器I/O port 介紹前/後面板 USB ： used for the external camera. Antennas TOUCH CONTROL USB-A USB-A RJ45 RJ45 RS232 IN 1 Audio IN 2 Audio OUT HDMI PC IN COMPONENT TOUCH TOUCH CONTROL CONTROL 將USB纜線從顯示器連接至外部電腦，以便使用觸控模組。 直接存取USB磁碟機上的多媒體檔案。 Page 38...
  • Page 41 開啟/關閉主機。 DISPLAYPORT 將內部信號通過DISPLAYPORT線纜輸出至另一台顯示器上。 USB-A USB-A 連接至USB 3.0/2.0硬碟機，數據傳輸。 USB-A RJ45 RJ45 RJ45 連接到乙太網絡 (10/100/1000 Mbps)。 RS232 RS232 連接外部數據機。 連接至麥克風。 IN 1 Audio AUDIO IN1 接收來自外部裝置（例如iPod播放器）所發出的音頻訊號。 IN 2 Audio OUT AUDIO IN2 接收來自外部裝置（例如DVD播放器）所發出的音頻訊號。 AUDIO OUT 連接到外接式立體聲喇叭。 INF8022 Series Hardware Guide Page 39...
  • Page 42 開啟或關閉顯示器。 選取/確認屏幕顯示(OSD) 功能表中的選項。 開啟或關閉OSD 功能表。 在OSD 功能表中向上捲動瀏覽各個設定和選項。 在OSD 功能表中向下捲動瀏覽各個設定和選項。 音量增加鍵，在OSD 功能表中向左捲動瀏覽各個設定和選項。 音量減小鍵，在OSD 功能表中向右捲動瀏覽各個設定和選項。 Page 40...
