is 456.
Press Select button to enter Admin Settings.
Scroll to Line Configuration and press Select button.
Scroll to Line 1 and press Select button.
Scroll to Address and enter PBXware extension number. Example: 1003.
Scroll to Server 1 and press Select button.
Press Edit button to edit Address line and enter PBXware IP address. Example
192.168.1.10. Then press the Ok button.
Press the Back button.
Scroll to Authentication and press Select button.
Press Edit button to edit User ID enter PBXware extension number. Example:
1003. Then press the Ok button.
Scroll to Password and press Edit button, enter secret of the extension as
received in the e-mail associated with this extension. Example: _%Z4M3*Ts9y7.
Then press the Ok button.
Press Back button twice, then press Select button to Save Configuration.
If everything is done as above described, you should have successfully registered
your phone to PBXware. Dial *123 to verify registration.

DNS SRV

4.1.3.2
This chapter describes how to use a DNS SRV record which specifies the location of the
PBXware. N O TE
Bicom Sy stem s can prov ide serv ice to set up this for y ou.
1. Check if the DNS SRV is enabled in your PBXware
Contact your PBXware administrator to find out if the DNS SRV is enabled in your
PBXware, or if you have access to the PBXware you can check this yourself.
Open a new browser window and enter the IP address in order to access the
PBXware web administration login screen. Example: http://192.168.1.10.
Login to PBXware with your e-mail address and password.
© 2003 - 2012 Bicom Systems
Y our DNS Serv er needs to be configured correctly for this to work.
Registering Phone 7
