[MAIN BOARD]

REF ORDER
NO. NO.
IC2221 1130007570 S.IC
IC2222 1130007570 S.IC
IC2231 1130005490 S.IC
IC2232 1130007570 S.IC
IC2241 1160000130 S.IC
Q111 1590002310 S.TRANSISTOR
Q112 1590002310 S.TRANSISTOR
Q121 1590002310 S.TRANSISTOR
Q122 1590001870 S.TRANSISTOR
Q131 1590002310 S.TRANSISTOR
Q132 1590002310 S.TRANSISTOR
Q133 1590001870 S.TRANSISTOR
Q151 1590002310 S.TRANSISTOR
Q271 1590000720 S.TRANSISTOR
Q351 1590002480 S.TRANSISTOR
Q352 1590002480 S.TRANSISTOR
Q353 1590002480 S.TRANSISTOR
Q354 1590002480 S.TRANSISTOR
Q521 1590002310 S.TRANSISTOR
Q522 1590002310 S.TRANSISTOR
Q571 1590002310 S.TRANSISTOR
Q572 1530002060 S.TRANSISTOR
Q573 1530002060 S.TRANSISTOR
Q601 1530002060 S.TRANSISTOR
Q611 1530002060 S.TRANSISTOR
Q621 1560000560 S.FET
Q631 1510000510 S.TRANSISTOR
Q632 1560000560 S.FET
Q633 1530002060 S.TRANSISTOR
Q634 1530002060 S.TRANSISTOR
Q635 1590002310 S.TRANSISTOR
Q636 1590001330 S.TRANSISTOR
Q721 1530002060 S.TRANSISTOR
Q731 1580000600 S.FET
Q732 1590002480 S.TRANSISTOR
Q741 1560000560 S.FET
Q751 1530002060 S.TRANSISTOR
Q771 1530002060 S.TRANSISTOR
Q772 1590002760 S.TRANSISTOR
Q773 1590002760 S.TRANSISTOR
Q774 1530002060 S.TRANSISTOR
Q776 1530002060 S.TRANSISTOR
Q777 1510000510 S.TRANSISTOR
Q961 1530002060 S.TRANSISTOR
Q981 1590002310 S.TRANSISTOR
Q982 1590002310 S.TRANSISTOR
Q1011 1560000330 S.FET
Q1012 1590002310 S.TRANSISTOR
Q1013 1530002060 S.TRANSISTOR
Q1014 1590002760 S.TRANSISTOR
Q1041 1590002310 S.TRANSISTOR
Q1061 1510000510 S.TRANSISTOR
Q1062 1530002060 S.TRANSISTOR
Q1071 1590002310 S.TRANSISTOR
Q1072 1590002310 S.TRANSISTOR
Q1073 1590002310 S.TRANSISTOR
Q1074 1590002310 S.TRANSISTOR
Q1075 1590002310 S.TRANSISTOR
Q1091 1590002310 S.TRANSISTOR
Q1092 1530002060 S.TRANSISTOR
Q1101 1590002310 S.TRANSISTOR
Q1131 1510000510 S.TRANSISTOR
Q2001 1590001870 S.TRANSISTOR
Q2131 1590002310 S.TRANSISTOR
Q2141 1590002310 S.TRANSISTOR
Q2171 1510000510 S.TRANSISTOR
Q2172 1530002060 S.TRANSISTOR
Q2221 1590002480 S.TRANSISTOR
Q2222 1590002480 S.TRANSISTOR
Q2223 1590002480 S.TRANSISTOR
Q2224 1590002480 S.TRANSISTOR
Q2225 1590002480 S.TRANSISTOR
Q2226 1590002310 S.TRANSISTOR
Q2227 1590002310 S.TRANSISTOR
D111 1750000640 S.DIODE
D112 1750000640 S.DIODE
D123 1790001250 S.DIODE
D131 1790001620 S.DIODE
DESCRIPTION
BU4094BCFV-E2
BU4094BCFV-E2
TC74HC4094AF
BU4094BCFV-E2
TD62783AF (TP1)
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTA114EE TL
DTC114EE TL
DTC114EE TL
DTA114EE TL
DTC114EE TL
DTA144EUA T106
UMC3N TR
UMC3N TR
UMC3N TR
UMC3N TR
DTC114EE TL
DTC114EE TL
DTC114EE TL
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SK882-GR (TE85L)
2SA1576A T106R
2SK882-GR (TE85L)
2SC4081 T107 R
2SC4081 T107 R
DTC114EE TL
DTA114EUA T106
2SC4081 T107 R
3SK126-O (TE85R)
UMC3N TR
2SK882-GR (TE85L)
2SC4081 T107 R
2SC4081 T107 R
UMC1NTR
UMC1NTR
2SC4081 T107 R
2SC4081 T107 R
2SA1576A T106R
2SC4081 T107 R
DTC114EE TL
DTC114EE TL
2SK210-GR (TE85R)
DTC114EE TL
2SC4081 T107 R
UMC1NTR
DTC114EE TL
2SA1576A T106R
2SC4081 T107 R
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
DTC114EE TL
2SC4081 T107 R
DTC114EE TL
2SA1576A T106R
DTA114EE TL
DTC114EE TL
DTC114EE TL
2SA1576A T106R
2SC4081 T107 R
UMC3N TR
UMC3N TR
UMC3N TR
UMC3N TR
UMC3N TR
DTC114EE TL
DTC114EE TL
1SV312 (TE85L)
1SV312 (TE85L)
MA2S111-(TX)
1SV308 (TPL3)
[MAIN BOARD]
REF ORDER
NO. NO.
D132 1790001610 S.DIODE
D133 1790001250 S.DIODE
D141 1790001620 S.DIODE
D142 1750000640 S.DIODE
D143 1790001620 S.DIODE
D151 1790001620 S.DIODE
D152 1790001620 S.DIODE
D153 1790001620 S.DIODE
D222 1750000640 S.DIODE
D224 1790001620 S.DIODE
D251 1790001620 S.DIODE
D252 1790001620 S.DIODE
D261 1790001620 S.DIODE
D262 1790001620 S.DIODE
D271 1750000430 S.DIODE
D272 1790001620 S.DIODE
D273 1790001620 S.DIODE
D274 1790001620 S.DIODE
D275 1790001620 S.DIODE
D276 1790001620 S.DIODE
D351 1750000520 S.DIODE
D352 1750000520 S.DIODE
D500 1790001620 S.DIODE
D501 1790001620 S.DIODE
D502 1790000450 S.DIODE
D521 1750000450 S.DIODE
D522 1750000450 S.DIODE
D551 1750000430 S.DIODE
D552 1790000450 S.DIODE
D561 1790000450 S.DIODE
D562 1790000450 S.DIODE
D571 1790001260 S.DIODE
D572 1750000450 S.DIODE
D573 1750000450 S.DIODE
D574 1790001250 S.DIODE
D621 1790000450 S.DIODE
D622 1790001250 S.DIODE
D623 1790001250 S.DIODE
D631 1750000520 S.DIODE
D632 1790001210 S.DIODE
D633 1790001250 S.DIODE
D634 1790001250 S.DIODE
D671 1790000450 S.DIODE
D672 1790000450 S.DIODE
D681 1790000450 S.DIODE
D682 1790000450 S.DIODE
D683 1790001250 S.DIODE
D691 1790000450 S.DIODE
D692 1790000450 S.DIODE
D701 1790000450 S.DIODE
D702 1790000450 S.DIODE
D711 1790000450 S.DIODE
D712 1790000450 S.DIODE
D721 1790000450 S.DIODE
D761 1790001210 S.DIODE
D771 1790001210 S.DIODE
D772 1790001250 S.DIODE
D791 1790000450 S.DIODE
D861 1790001240 S.DIODE
D921 1750000520 S.DIODE
D923 1710000160 S.DIODE
D931 1750000370 S.DIODE
D932 1750000370 S.DIODE
D981 1790001610 S.DIODE
D1011 1790001250 S.DIODE
D1012 1720000590 S.VARICAP
D1013 1790001210 S.DIODE
D1014 1790001210 S.DIODE
D1041 1790001250 S.DIODE
D1042 1790000450 S.DIODE
D1061 1730002510 S.ZENER
D1071 1790001250 S.DIODE
D1072 1790001240 S.DIODE
D1073 1790001240 S.DIODE
D1074 1790001610 S.DIODE
D1075 1790001250 S.DIODE
D1076 1790001040 S.ZENER
D1077 1790001040 S.ZENER
D1078 1790001240 S.DIODE
D1091 1160000140 S.DIODE
D1111 1790001610 S.DIODE
D1112 1790001610 S.DIODE
5 - 3
DESCRIPTION
1SS385 (TE85L)
MA2S111-(TX)
1SV308 (TPL3)
1SV312 (TE85L)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV312 (TE85L)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
HSB88WSTR
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
DAN222TL
DAN222TL
1SV308 (TPL3)
1SV308 (TPL3)
MA862 (TX)
1SV265-TL
1SV265-TL
HSB88WSTR
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA2S077-(TX)
1SV265-TL
1SV265-TL
MA2S111-(TX)
MA862 (TX)
MA2S111-(TX)
MA2S111-(TX)
DAN222TL
1SS375-TL
MA2S111-(TX)
MA2S111-(TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA2S111-(TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
1SS375-TL
1SS375-TL
MA2S111-(TX)
MA862 (TX)
MA2S728-(TX)
DAN222TL
1SS133
DA221 TL
DA221 TL
1SS385 (TE85L)
MA2S111-(TX)
MA357 (TX)
1SS375-TL
1SS375-TL
MA2S111-(TX)
MA862 (TX)
MA8027-H (TX)
MA2S111-(TX)
MA2S728-(TX)
MA2S728-(TX)
1SS385 (TE85L)
MA2S111-(TX)
MA8033-L (TX)
MA8033-L (TX)
MA2S728-(TX)
DAP222 TL
1SS385 (TE85L)
1SS385 (TE85L)
S.=Surface mount
