Icom IC-706MKIIG Service Manual page 40

[PLL UNIT]
REF ORDER
NO. NO.
R956 7030005380 S.RESISTOR
R957 7030005400 S.RESISTOR
R958 7030005390 S.RESISTOR
R959 7030005400 S.RESISTOR
R960 7030005390 S.RESISTOR
R961 7030005400 S.RESISTOR
R962 7030005390 S.RESISTOR
R963 7030005400 S.RESISTOR
R964 7030005390 S.RESISTOR
R965 7030005400 S.RESISTOR
R966 7030005390 S.RESISTOR
R967 7030005400 S.RESISTOR
R968 7030005390 S.RESISTOR
R969 7030005400 S.RESISTOR
R970 7030005400 S.RESISTOR
R1011 7030003400 S.RESISTOR
R1012 7030003400 S.RESISTOR
R1013 7030003400 S.RESISTOR
R1014 7030003400 S.RESISTOR
R1015 7030003400 S.RESISTOR
R1017 7030003400 S.RESISTOR
C1 4040000190 BARRIERLAYR
C2 4030008560 S.CERAMIC
C3 4030006950 S.CERAMIC
C4 4610001850 S.TRIMMER
C5 4030016550 S.CERAMIC
C11 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C12 4030006880 S.CERAMIC
C13 4030006880 S.CERAMIC
C14 4030016550 S.CERAMIC
C15 4030016550 S.CERAMIC
C21 4030009530 S.CERAMIC
C22 4030011600 S.CERAMIC
C31 4030006880 S.CERAMIC
C41 4030006880 S.CERAMIC
C44 4030006880 S.CERAMIC
C45 4030008680 S.CERAMIC
C51 4030006880 S.CERAMIC
C52 4030006880 S.CERAMIC
C71 4030006880 S.CERAMIC
C72 4030011600 S.CERAMIC
C73 4030007050 S.CERAMIC
C75 4030006880 S.CERAMIC
C76 4030007090 S.CERAMIC
C77 4030007090 S.CERAMIC
C101 4030011600 S.CERAMIC
C102 4030011600 S.CERAMIC
C103 4030011600 S.CERAMIC
C104 4030011600 S.CERAMIC
C105 4030011600 S.CERAMIC
C106 4030011600 S.CERAMIC
C107 4030011600 S.CERAMIC
C108 4030011600 S.CERAMIC
C109 4030011600 S.CERAMIC
C110 4030011600 S.CERAMIC
C111 4030011600 S.CERAMIC
C112 4030011600 S.CERAMIC
C113 4030011600 S.CERAMIC
C114 4030011600 S.CERAMIC
C131 4030006880 S.CERAMIC
C132 4030011600 S.CERAMIC
C133 4550003220 S.TANTALUM
C145 4030006880 S.CERAMIC
C146 4030006880 S.CERAMIC
C147 4030006880 S.CERAMIC
C148 4030006880 S.CERAMIC
C149 4030006880 S.CERAMIC
C150 4030006880 S.CERAMIC
C151 4030006880 S.CERAMIC
C152 4030006880 S.CERAMIC
C153 4030006880 S.CERAMIC
C154 4030006880 S.CERAMIC
C155 4030006880 S.CERAMIC
C161 4030006880 S.CERAMIC
C163 4030006880 S.CERAMIC
C165 4030007130 S.CERAMIC
C166 4030007130 S.CERAMIC
C200 4030011340 S.CERAMIC
C201 4550006080 S.TANTALUM
C202 4030009110 S.CERAMIC
DESCRIPTION
RR0816P-102-B (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-102-D (1 kΩ)
RR0816P-202-D (2 kΩ)
RR0816P-202-D (2 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
UAT 05X 103K
C1608 CH 1H 300J-T-A
C1608 CH 1H 040C-T-A
TZBX4R200BA110T00 20P
CM105 CH 151G 50AT
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
CM105 CH 151G 50AT
CM105 CH 151G 50AT
C1608 CH 1H 030B-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C2012 JF 1C 105Z-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 220J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
TEMSVA 1E 105M-8L
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 101J-T-A
C1608 CH 1H 101J-T-A
C1608 CH 1H 471J-T-A
TEMSVB2 1C 106M-8L
C3216 JB 1C 474K-T-A
[PLL UNIT]
REF ORDER
NO. NO.
C203 4030011600 S.CERAMIC
C204 4030007170 S.CERAMIC
C205 4030009110 S.CERAMIC
C206 4550006080 S.TANTALUM
C207 4030009110 S.CERAMIC
C208 4030010210 S.CERAMIC
C209 4550006080 S.TANTALUM
C210 4030006860 S.CERAMIC
C212 4030006880 S.CERAMIC
C215 4030007090 S.CERAMIC
C218 4030006880 S.CERAMIC
C220 4030007090 S.CERAMIC
C221 4030006880 S.CERAMIC
C222 4030007090 S.CERAMIC
C223 4030007090 S.CERAMIC
C224 4030007090 S.CERAMIC
C225 4030007090 S.CERAMIC
C231 4510004590 ELECTROLYTIC
C232 4030009110 S.CERAMIC
C233 4030006880 S.CERAMIC
C234 4030011600 S.CERAMIC
C235 4510004590 ELECTROLYTIC
C236 4510004590 ELECTROLYTIC
C237 4030011600 S.CERAMIC
C238 4030006880 S.CERAMIC
C239 4030011600 S.CERAMIC
C240 4030011600 S.CERAMIC
C241 4030011600 S.CERAMIC
C251 4030006860 S.CERAMIC
C256 4030011600 S.CERAMIC
C262 4030006860 S.CERAMIC
C265 4030006860 S.CERAMIC
C271 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C272 4030006880 S.CERAMIC
C273 4030006880 S.CERAMIC
C274 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C281 4030006880 S.CERAMIC
C284 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C285 4030006880 S.CERAMIC
C286 4030011600 S.CERAMIC
C291 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C292 4030006880 S.CERAMIC
C293 4030006880 S.CERAMIC
C294 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C295 4510001350 ELECTROLYTIC
C301 4030011340 S.CERAMIC
C302 4030006850 S.CERAMIC
C303 4030006880 S.CERAMIC
C304 4030009510 S.CERAMIC
C305 4030006850 S.CERAMIC
C306 4610001830 S.TRIMMER
C307 4030009540 S.CERAMIC
C308 4030007150 S.CERAMIC
C321 4030006880 S.CERAMIC
C322 4030006880 S.CERAMIC
C323 4030006880 S.CERAMIC
C325 4030006850 S.CERAMIC
C326 4030006880 S.CERAMIC
C331 4030007150 S.CERAMIC
C332 4030006850 S.CERAMIC
C333 4030006880 S.CERAMIC
C334 4030009510 S.CERAMIC
C335 4610001830 S.TRIMMER
C336 4030006950 S.CERAMIC
C351 4030006880 S.CERAMIC
C352 4030006880 S.CERAMIC
C353 4030006880 S.CERAMIC
C355 4030006880 S.CERAMIC
C356 4030006850 S.CERAMIC
C364 4030006850 S.CERAMIC
C366 4030006970 S.CERAMIC
C367 4610001860 S.TRIMMER
C368 4030009510 S.CERAMIC
C369 4030006850 S.CERAMIC
C370 4030009570 S.CERAMIC
C372 4030006860 S.CERAMIC
C373 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C374 4030006980 S.CERAMIC
C375 4030006860 S.CERAMIC
C376 4550002890 S.TANTALUM
C381 4030006880 S.CERAMIC
C382 4030006880 S.CERAMIC
5 - 15
DESCRIPTION
C1608 JB 1C 104KT-N
C1608 CH 1H 221J-T-A
C3216 JB 1C 474K-T-A
TEMSVB2 1C 106M-8L
C3216 JB 1C 474K-T-A
C3216 JB 1C 105M-T-A
TEMSVB2 1C 106M-8L
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
16 MV 470 HC
C3216 JB 1C 474K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
16 MV 470 HC
16 MV 470 HC
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
16 MS5 10UF
C1608 CH 1H 471J-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 010B-T-A
C1608 JB 1H 471K-T-A
TZBX4N100BA110T00 10P
C1608 CH 1H 1R5B-T-A
C1608 CH 1H 151J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 151J-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 010B-T-A
TZBX4N100BA110T00 10P
C1608 CH 1H 040C-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 060D-T-A
TZBX4Z060BA110T00 6P
C1608 CH 1H 010B-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 0R3B-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 070D-T-A
C1608 JB 1H 102K-T-A
TESVA 1A 225M1-8L
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
S.=Surface mount
