Icom IC-706MKIIG Service Manual page 38

[PLL UNIT]
REF ORDER
NO. NO.
Q621 1530002560 S.TRANSISTOR
Q661 1530002560 S.TRANSISTOR
Q681 1530002560 S.TRANSISTOR
Q851 1590001330 S.TRANSISTOR
Q931 1530002060 S.TRANSISTOR
Q941 1530002560 S.TRANSISTOR
D1 1720000590 S.VARICAP
D231 1750000520 S.DIODE
D261 1750000520 S.DIODE
D271 1710000780 S.DIODE
D301 1720000390 S.VARICAP
D302 1790000620 S.DIODE
D331 1720000390 S.VARICAP
D332 1790000620 S.DIODE
D361 1790001400 S.VARICAP
D362 1790000620 S.DIODE
D511 1790000620 S.DIODE
D531 1750000620 S.DIODE
D601 1720000590 S.VARICAP
D701 1790000450 S.DIODE
D731 1790000450 S.DIODE
D732 1790000450 S.DIODE
D761 1750000210 S.DIODE
D762 1750000210 S.DIODE
D821 1790001620 S.DIODE
D822 1790001620 S.DIODE
D825 1790001620 S.DIODE
D851 1790001620 S.DIODE
D861 1750000210 S.DIODE
D862 1160000060 S.DIODE
D863 1790001250 S.DIODE
D864 1790001250 S.DIODE
D931 1790001250 S.DIODE
FI71 2020001600 S.CERAMIC
X621 6050005711 XTAL
L1 6130002970 COIL
L11 6200005010 S.COIL
L30 6200002040 S.COIL
L41 6200003590 S.COIL
L42 6200003590 S.COIL
L43 6200003590 S.COIL
L44 6200003590 S.COIL
L45 6200001830 S.COIL
L48 6200001830 S.COIL
L71 6200002860 S.COIL
L131 6200001830 S.COIL
L161 6200002040 S.COIL
L163 6200003540 S.COIL
L231 6140002220 COIL
L301 6170000230 COIL
L302 6190001280 COIL
L303 6170000230 COIL
L331 6170000230 COIL
L332 6190001370 COIL
L333 6170000230 COIL
L363 6180000810 COIL
L364 6180000810 COIL
L366 6190001390 COIL
L367 6200005010 S.COIL
L382 6200003260 S.COIL
L383 6180000810 COIL
L391 6200005010 S.COIL
L411 6140002220 COIL
L461 6200005010 S.COIL
L501 6200001980 S.COIL
L531 6140002810 S.COIL
L532 6200003540 S.COIL
L542 6200002920 S.COIL
L600 6200002040 S.COIL
L601 6130001100 COIL
L621 6200003260 S.COIL
L622 6200003590 S.COIL
L623 6150004520 S.COIL
L641 6200002000 S.COIL
DESCRIPTION
2SC4403-3-TL
2SC4403-3-TL
2SC4403-3-TL
DTA114EUA T106
2SC4081 T107 R
2SC4403-3-TL
MA357 (TX)
DAN222TL
DAN222TL
MA114 (TX)
KV1470TL
MA77 (TX)
KV1470TL
MA77 (TX)
MA304B (TX)
MA77 (TX)
MA77 (TX)
MA717WK (TX)
MA357 (TX)
MA862 (TX)
MA862 (TX)
MA862 (TX)
1SV237 (TE85R)
1SV237 (TE85R)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV308 (TPL3)
1SV237 (TE85R)
DAN202U T107
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
SFECV10.5MA-5
CR-275A (30.00000 MHz)
LB-343
NL 252018T-100J
NL 252018T-101J
EXCCL3225U1
EXCCL3225U1
EXCCL3225U1
EXCCL3225U1
NL 322522T-100J
NL 322522T-100J
NL 252018T-4R7J
NL 322522T-100J
NL 252018T-101J
MLF1608D R22K-T
LR-270 (TR6X3X2 3A9)
LW-25
E544GN-110248
LW-25
LW-25
E544GN-110254
LW-25
LAL 03NA 2R2M
LAL 03NA 2R2M
C-13975-4.5
NL 252018T-100J
NL 322522T-101J
LAL 03NA 2R2M
NL 252018T-100J
LR-270 (TR6X3X2 3A9)
NL 252018T-100J
NL 252018T-1R0J
LR-317
MLF1608D R22K-T
ELJNC R33K-F
NL 252018T-101J
LB-146
NL 322522T-101J
EXCCL3225U1
LS-508
NL 252018T-3R3J
[PLL UNIT]
REF ORDER
NO. NO.
L642 6200004670 S.COIL
L681 6150004830 S.COIL
L682 6150004830 S.COIL
L711 6200002160 S.COIL
L712 6200001630 S.COIL
L713 6200002160 S.COIL
L741 6200002150 S.COIL
L742 6200003670 S.COIL
L743 6200003670 S.COIL
L771 6200002160 S.COIL
L781 6200001770 S.COIL
L782 6200002120 S.COIL
L801 6200005740 S.COIL
L802 6200005720 S.COIL
L811 6200005710 S.COIL
L812 6200005720 S.COIL
L821 6200007740 S.COIL
L822 6200007720 S.COIL
L823 6200007730 S.COIL
L824 6200007710 S.COIL
L861 6200005700 S.COIL
L862 6200005680 S.COIL
L871 6200005680 S.COIL
L872 6200005670 S.COIL
L881 6200002180 S.COIL
L882 6200005660 S.COIL
L901 6200005010 S.COIL
L941 6200003540 S.COIL
L981 6200003170 S.COIL
L991 6200007390 S.COIL
L992 6200006380 S.COIL
L1000 6200006980 S.COIL
L1001 2040000490 COIL
L1016 6200005010 S.COIL
R11 7030003280 S.RESISTOR
R12 7030003320 S.RESISTOR
R13 7030003680 S.RESISTOR
R14 7030003680 S.RESISTOR
R15 7030003340 S.RESISTOR
R16 7030003520 S.RESISTOR
R21 7030003640 S.RESISTOR
R23 7030003320 S.RESISTOR
R24 7030003370 S.RESISTOR
R32 7030003430 S.RESISTOR
R34 7030004050 S.RESISTOR
R41 7030003220 S.RESISTOR
R42 7030003300 S.RESISTOR
R43 7030003220 S.RESISTOR
R52 7030003280 S.RESISTOR
R53 7030003370 S.RESISTOR
R54 7030003660 S.RESISTOR
R71 7030003280 S.RESISTOR
R72 7030003370 S.RESISTOR
R73 7030003660 S.RESISTOR
R75 7030003400 S.RESISTOR
R76 7030003360 S.RESISTOR
R101 7030003440 S.RESISTOR
R102 7030003440 S.RESISTOR
R103 7030003440 S.RESISTOR
R104 7030003440 S.RESISTOR
R105 7030003440 S.RESISTOR
R106 7030003440 S.RESISTOR
R131 7030003570 S.RESISTOR
R132 7030003840 S.RESISTOR
R133 7030009690 S.RESISTOR
R134 7030005630 S.RESISTOR
R135 7030005390 S.RESISTOR
R141 7030003440 S.RESISTOR
R142 7030003440 S.RESISTOR
R143 7030003440 S.RESISTOR
R144 7030003440 S.RESISTOR
R145 7030003440 S.RESISTOR
R151 7030003560 S.RESISTOR
R152 7030003560 S.RESISTOR
R153 7030003560 S.RESISTOR
R154 7030003560 S.RESISTOR
R155 7030003560 S.RESISTOR
R161 7030003380 S.RESISTOR
R162 7030003590 S.RESISTOR
R164 7030003300 S.RESISTOR
5 - 13
DESCRIPTION
NL 252018T-3R9J
LS-509
LS-509
ELJNC 82NK-F
ELJNC R10K-F
ELJNC 82NK-F
ELJNC 56NK-F
ELJNC 68NK-F
ELJNC 68NK-F
ELJNC 82NK-F
ELJNC 47NK-F
ELJNC 33NK-F
ELJRE 47NG-F
ELJRE 33NG-F
ELJRE 27NG-F
ELJRE 33NG-F
LQN21A 47NJ04
LQN21A 33NJ04
LQN21A 39NJ04
LQN21A 27NJ04
ELJRE 22NG-F
ELJRE 15NG-F
ELJRE 15NG-F
ELJRE 12NG-F
NL 252018T-R12J
ELJRE 10NG-F
NL 252018T-100J
MLF1608D R22K-T
NL 322522T-330J
ELJFC 120K-F 12U
ELJFC 150K 15U
ELJRE R10G-F
EXC-ELDR25C
NL 252018T-100J
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 150 V (15 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
RR0816P-101-D (100 Ω)
RR0816R-154-D (150 kΩ)
RR0816P-102-D (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 680 V (68 Ω)
S.=Surface mount
