Icom IC-706MKIIG Service Manual page 46

[FILTER BOARD]
REF ORDER
NO. NO.
L69 6200002040 S.COIL
L70 6200003550 S.COIL
L71 6200002040 S.COIL
L72 6200002040 S.COIL
L73 6200002040 S.COIL
L74 6200002040 S.COIL
L75 6200002040 S.COIL
L76 6200002040 S.COIL
L77 6200002040 S.COIL
L78 6200002040 S.COIL
L79 6200002040 S.COIL
L80 6200002040 S.COIL
L81 6200002040 S.COIL
L82 6200002040 S.COIL
L83 6200002040 S.COIL
L84 6200002040 S.COIL
L85 6200002040 S.COIL
L86 6200002040 S.COIL
L87 6180000900 COIL
R2 7030007190 S.RESISTOR
R3 7030003560 S.RESISTOR
R4 7030003550 S.RESISTOR
R5 7030003440 S.RESISTOR
R6 7030003640 S.RESISTOR
R7 7030003680 S.RESISTOR
R8 7540000130 ABSORBER
R9 7030003320 S.RESISTOR
R10 7030003320 S.RESISTOR
R11 7010003241 RESISTOR
R15 7030003440 S.RESISTOR
R16 7030003320 S.RESISTOR
R17 7030003440 S.RESISTOR
R18 7030003320 S.RESISTOR
R26 7030003560 S.RESISTOR
R27 7030003440 S.RESISTOR
R28 7030003440 S.RESISTOR
R33 7030003440 S.RESISTOR
R34 7030003440 S.RESISTOR
R35 7030003440 S.RESISTOR
R36 7030003440 S.RESISTOR
R37 7030003440 S.RESISTOR
R38 7030003440 S.RESISTOR
R39 7030003440 S.RESISTOR
R40 7030003440 S.RESISTOR
R42 7030003480 S.RESISTOR
R43 7030003480 S.RESISTOR
R60 7030003480 S.RESISTOR
R61 7030003320 S.RESISTOR
R62 7030003390 S.RESISTOR
R63 7030003290 S.RESISTOR
R64 7030003720 S.RESISTOR
R65 7030003720 S.RESISTOR
R66 7030003520 S.RESISTOR
R67 7030000320 S.RESISTOR
R68 7030003440 S.RESISTOR
R69 7030003560 S.RESISTOR
R70 7030003440 S.RESISTOR
R71 7030003560 S.RESISTOR
R72 7030003440 S.RESISTOR
R73 7030003560 S.RESISTOR
R74 7030003440 S.RESISTOR
R75 7030003560 S.RESISTOR
R76 7030003440 S.RESISTOR
R77 7030003560 S.RESISTOR
R78 7030003440 S.RESISTOR
R79 7030003560 S.RESISTOR
R80 7030003440 S.RESISTOR
R81 7030003560 S.RESISTOR
R82 7030003440 S.RESISTOR
R83 7030003560 S.RESISTOR
C1 4030007070 S.CERAMIC
C2 4030009470 S.CERAMIC
C3 4030007100 S.CERAMIC
C4 4030007030 S.CERAMIC
C5 4030007080 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030006880 S.CERAMIC
C15 4030006880 S.CERAMIC
DESCRIPTION
NL 252018T-101J
MLF1608A 4R7K-T
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
LAL 03NA 101K
ERJ12YJ220H (22 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
2P-50A-301
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
PSD1/4V 47 Ω
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
MCR10EZHJ 330 Ω (331)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
C1608 CH 1H 330J-T-A
C1608 CH 1H R75C-T-A
C1608 CH 1H 560J-T-A
C1608 CH 1H 150J-T-A
C1608 CH 1H 390J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
[FILTER BOARD]
REF ORDER
NO. NO.
C16 4030006880 S.CERAMIC
C17 4010005360 CERAMIC
C19 4010007590 CERAMIC
C21 4010005930 CERAMIC
C22 4030006880 S.CERAMIC
C23 4030006880 S.CERAMIC
C29 4030006880 S.CERAMIC
C30 4030006880 S.CERAMIC
C31 4010007610 CERAMIC
C32 4010005810 CERAMIC
C33 4010005880 CERAMIC
C36 4030006880 S.CERAMIC
C37 4030006880 S.CERAMIC
C40 4010007610 CERAMIC
C43 4030006880 S.CERAMIC
C44 4030006880 S.CERAMIC
C45 4010005930 CERAMIC
C46 4010008160 CERAMIC
C47 4010005870 CERAMIC
C48 4010005810 CERAMIC
C49 4010007490 CERAMIC
C50 4030006880 S.CERAMIC
C51 4030006880 S.CERAMIC
C52 4010007500 CERAMIC
C53 4010006410 CERAMIC
C54 4010007500 CERAMIC
C55 4010005820 CERAMIC
C56 4010007500 CERAMIC
C57 4030006880 S.CERAMIC
C58 4610002050 S.TRIMMER
C59 4030007160 S.CERAMIC
C62 4030010760 S.CERAMIC
C63 4030010760 S.CERAMIC
C64 4030007090 S.CERAMIC
C65 4030006850 S.CERAMIC
C66 4030006850 S.CERAMIC
C67 4030006850 S.CERAMIC
C69 4030006880 S.CERAMIC
C70 4030006880 S.CERAMIC
C71 4030006880 S.CERAMIC
C72 4030006880 S.CERAMIC
C73 4030006880 S.CERAMIC
C74 4030006880 S.CERAMIC
C75 4030006880 S.CERAMIC
C76 4030006880 S.CERAMIC
C78 4010005850 CERAMIC
C79 4010005860 CERAMIC
C80 4010007590 CERAMIC
C81 4010006410 CERAMIC
C82 4010007500 CERAMIC
C84 4010007490 CERAMIC
C87 4030006880 S.CERAMIC
C88 4030006880 S.CERAMIC
C89 4030006880 S.CERAMIC
C90 4030006880 S.CERAMIC
C91 4030006880 S.CERAMIC
C92 4030006880 S.CERAMIC
C93 4030006880 S.CERAMIC
C94 4030006880 S.CERAMIC
C95 4030006880 S.CERAMIC
C96 4030006880 S.CERAMIC
C97 4030006880 S.CERAMIC
C98 4030006880 S.CERAMIC
C99 4030006880 S.CERAMIC
C100 4030006880 S.CERAMIC
C101 4030006860 S.CERAMIC
C102 4030006880 S.CERAMIC
C103 4030006880 S.CERAMIC
C104 4030006880 S.CERAMIC
C105 4030006880 S.CERAMIC
C110 4030006880 S.CERAMIC
C111 4030006880 S.CERAMIC
C112 4030006880 S.CERAMIC
C113 4030006880 S.CERAMIC
C114 4030006880 S.CERAMIC
C115 4030006880 S.CERAMIC
C116 4030006880 S.CERAMIC
C117 4030006880 S.CERAMIC
C118 4030006880 S.CERAMIC
C119 4030006880 S.CERAMIC
C120 4030006880 S.CERAMIC
C121 4030006880 S.CERAMIC
5 - 21
DESCRIPTION
C1608 JB 1H 472K-T-A
HM11SJ SL 301J 500V
HM15SJ SL 681J 500V
HM11SJ SL 391J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM95SJ SL 241J 500V
HM74SJ SL 111J 500V
HM95SJ SL 271J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM95SJ SL 241J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM11SJ SL 391J 500V
HM13SJ SL 431J 500V
HM95SJ SL 221J 500V
HM74SJ SL 111J 500V
HM15SJ SL 561J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM15SJ SL 751J 500V
HM13SJ SL 471J 500V
HM15SJ SL 751J 500V
HM74SJ SL 121J 500V
HM15SJ SL 751J 500V
C1608 JB 1H 472K-T-A
ECR-JC010 A12W
C1608 CH 1H 181J-T-A
C1608 CH 1H 331J-T-A
C1608 CH 1H 331J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HM95SJ SL 181J 500V
HM95SJ SL 201J 500V
HM15SJ SL 681J 500V
HM13SJ SL 471J 500V
HM15SJ SL 751J 500V
HM15SJ SL 561J 500V
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
S.=Surface mount
