5-2 IC-M710RT
[CONNECT UNIT]
REF
ORDER
NO.
NO.
J1
6510007130 CONNECTOR
J2
6510007130 CONNECTOR
WS1
8600036270 M.OTHER
[CTRL2 BOARD]
REF
ORDER
NO.
NO.
IC1
1140004670 S.IC
IC2
1120002560 S.IC
IC3
1120002510 S.IC
IC4
1120002550 S.IC
IC5
1110002750 S.IC
IC6
1130003760 S.IC
IC7
1110003780 S.IC
IC8
1130007260 S.IC
IC9
1130007260 S.IC
Q1
1530002690 S.TRANSISTOR
Q2
1530002690 S.TRANSISTOR
Q3
1530002690 S.TRANSISTOR
Q4
1530002690 S.TRANSISTOR
Q5
1510000770 S.TRANSISTOR
Q6
1510000770 S.TRANSISTOR
Q7
1510000770 S.TRANSISTOR
Q8
1510000770 S.TRANSISTOR
Q9
1530002690 S.TRANSISTOR
Q10
1530002690 S.TRANSISTOR
Q11
1510000770 S.TRANSISTOR
D1
1750000370 S.DIODE
D2
1750000370 S.DIODE
D3
1750000370 S.DIODE
D4
1750000370 S.DIODE
D7
1160000070 S.DIODE
D8
1160000070 S.DIODE
D9
1160000080 S.DIODE
D10
1160000080 S.DIODE
D11
1750000370 S.DIODE
D12
1750000550 S.DIODE
X1
6050009470 XTAL
L1
6200000020 S.COIL
L2
6200002920 S.COIL
L3
6200002920 S.COIL
L4
6200002920 S.COIL
L5
6200002920 S.COIL
R5
7030000220 S.RESISTOR
R6
7030000220 S.RESISTOR
R7
7030000220 S.RESISTOR
R8
7030000220 S.RESISTOR
R9
7030000220 S.RESISTOR
R10
7030000220 S.RESISTOR
R11
7030000220 S.RESISTOR
R12
7030000220 S.RESISTOR
R13
7030003440 S.RESISTOR
R14
7030003440 S.RESISTOR
R15
7030003440 S.RESISTOR
R16
7030003440 S.RESISTOR
R17
7030003440 S.RESISTOR
R18
7030003440 S.RESISTOR
R19
7030003440 S.RESISTOR
R20
7030003440 S.RESISTOR
R21
7030000300 S.RESISTOR
R22
7030003490 S.RESISTOR
R23
7030006090 S.RESISTOR
R24
7030003420 S.RESISTOR
DESCRIPTION
BNC-R111E
BNC-R111E
SX2132 P02CO
DESCRIPTION
SC-1288
HD26C32AFP
DS14C232TM
NJM311M-TE3
TA75S01F (TE85R)
TC4S81F (TE85R)
NJM2902V-TE1
TC7W74FU (TE12L)
TC7W74FU (TE12L)
2SC4116-GR (TE85R)
2SC4116-GR (TE85R)
2SC4116-GR (TE85R)
2SC4116-GR (TE85R)
2SA1586-GR (TE85R)
2SA1586-GR (TE85R)
2SA1586-GR (TE85R)
2SA1586-GR (TE85R)
2SC4116-GR (TE85R)
2SC4116-GR (TE85R)
2SA1586-GR (TE85R)
DA221 TL
DA221 TL
DA221 TL
DA221 TL
DAN202K T146
DAN202K T146
DAP202K T146
DAP202K T146
DA221 TL
1SS355 TE-17
CR-508 (5.0688 MHz)
LQH 3N 101K 04
ELJNC R33K-F
ELJNC R33K-F
ELJNC R33K-F
ELJNC R33K-F
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
MCR10EZHJ 47 Ω (471)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 220 Ω (221)
ERJ3GEYJ 272 V (2.7 kΩ)
RR0816P-272-D (2.7 kΩ)
ERJ3GEYJ 681 V (680 Ω)
[CTRL2 BOARD]
REF
ORDER
NO.
NO.
R25
7410000950 S.ARRAY
R26
7030003640 S.RESISTOR
R27
7030003640 S.RESISTOR
R28
7030003640 S.RESISTOR
R29
7030003640 S.RESISTOR
R30
7030003640 S.RESISTOR
R31
7030003800 S.RESISTOR
R32
7030003450 S.RESISTOR
R33
7030003560 S.RESISTOR
R36
7030003640 S.RESISTOR
R37
7030003440 S.RESISTOR
R38
7030003440 S.RESISTOR
R39
7030003440 S.RESISTOR
R40
7030003590 S.RESISTOR
R41
7030003560 S.RESISTOR
R42
7030003580 S.RESISTOR
R43
7030003320 S.RESISTOR
R44
7030003630 S.RESISTOR
R45
7030003630 S.RESISTOR
R46
7030003560 S.RESISTOR
R47
7030003560 S.RESISTOR
R48
7030003650 S.RESISTOR
R50
7030003380 S.RESISTOR
R51
7030006090 S.RESISTOR
R52
7030003600 S.RESISTOR
R53
7030005980 S.RESISTOR
R54
7030003730 S.RESISTOR
R55
7030005870 S.RESISTOR
R56
7030003840 S.RESISTOR
R57
7030005320 S.RESISTOR
R58
7030005320 S.RESISTOR
R59
7030005680 S.RESISTOR
R60
7030003760 S.RESISTOR
R61
7030005970 S.RESISTOR
R62
7030003840 S.RESISTOR
R63
7030005320 S.RESISTOR
R64
7030005320 S.RESISTOR
R65
7030006100 S.RESISTOR
R66
7030003680 S.RESISTOR
R67
7030005690 S.RESISTOR
R68
7030003650 S.RESISTOR
R69
7030003580 S.RESISTOR
R70
7030003600 S.RESISTOR
R71
7030003200 S.RESISTOR
R72
7030003200 S.RESISTOR
R73
7030003200 S.RESISTOR
R74
7030003200 S.RESISTOR
R75
7030003200 S.RESISTOR
R76
7030003440 S.RESISTOR
R77
7030003440 S.RESISTOR
R78
7030003440 S.RESISTOR
R79
7030003440 S.RESISTOR
R80
7030003520 S.RESISTOR
R81
7030008070 S.RESISTOR
R82
7030003720 S.RESISTOR
R83
7030006100 S.RESISTOR
R84
7030003420 S.RESISTOR
R85
7030003520 S.RESISTOR
R86
7030003320 S.RESISTOR
R88
7030003200 S.RESISTOR
C1
4510005090 ELECTROLYTIC
C2
4510005090 ELECTROLYTIC
C3
4510005090 ELECTROLYTIC
C4
4510005090 ELECTROLYTIC
C5
4030008630 S.CERAMIC
C6
4030008630 S.CERAMIC
C7
4030008630 S.CERAMIC
C8
4030008630 S.CERAMIC
C9
4030008630 S.CERAMIC
C10
4030008630 S.CERAMIC
C11
4030008630 S.CERAMIC
C12
4510004630 S.ELECTROLYTIC ECEV1CA100SR
C13
4510004630 S.ELECTROLYTIC ECEV1CA100SR
C14
4510004630 S.ELECTROLYTIC ECEV1CA100SR
C15
4510004630 S.ELECTROLYTIC ECEV1CA100SR
C16
4030006860 S.CERAMIC
C17
4030006880 S.CERAMIC
C18
4030006860 S.CERAMIC
5 - 5
DESCRIPTION
EXB-V8V 102JV
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 331 V (330 Ω)
RR0816P-272-D (2.7 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
RR0816P-333-D (33 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
RR0816R-104-D (100 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
RR0816P-103-D (10 kΩ)
RR0816P-103-D (10 kΩ)
RR0816R-473-D (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
RR0816R-683-D (68 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
RR0816P-103-D (10 kΩ)
RR0816P-103-D (10 kΩ)
RR0816P-183-D (18 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
RR0816P-123-D (12 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
RR0816P-273-D (27 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
RR0816P-183-D (18 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 100 V (10 Ω)
6.3 MV 470 HC
6.3 MV 470 HC
6.3 MV 470 HC
6.3 MV 470 HC
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
S.=Surface mount
