4-2 INTERFACE ADJUSTMENTS
ADJUSTMENT
ADJUSTMENT CONDITION
1 • Connect a main body and controller
INTERFACE
ADJUSTMENT
with a coaxial cable, then turn
power ON.
• CTRL2 BOARD
MEASUREMENT
UNIT
LOCATION
CTRL2 Connect a frequency
counter
to
check
point CP2.
4 - 2
ADJUSTMENT
VALUE
UNIT
1.2672 MHz
CTRL2
CP2
C22
POINT
ADJUST
C22
Interface
check point
Interface
adjustment
