BIOS Setup Utility

3-1 SOYO COMBO SETUP

This Motherboard does not use any hardware jumpers to set the
CPU frequency. Instead, CPU settings are software configurable
with the BIOS [SOYO COMBO SETUP].
After the hardware installation is complete, turn the power switch on,
then press the <DEL> key during the system diagnostic checks to
enter the Award BIOS Setup program. The CMOS SETUP UTILITY
will display on screen. Then, select the [SOYO COMBO SETUP]
option from the main menu and press the <Enter> key.
CPU Frequency (MHz)
CPU Host/PCI Clock
CPU Ratio
CPU L2 Cache ECC Checking
Boot Sequence
Quick Power On Self Test
POWER ON Function
KB Power ON Password
Hot Key Power ON
Power Button
Soft – Off by PWR-BTTN
Power-On by Ring/LAN
Resume by Alarm
The [SOYO COMBO SETUP] menu combines the main parameters
that you need to configure, all in one menu, for a quick setup in
BIOS.
ROM PCI/ISA BIOS
SOYO COMBO SETUP
AWARD SOFTWARE, INC.
: Manual
: 100/33 MHz
: X 3.5 = 350MHz
: Enabled
: A,C,SCSI
: Enabled
: BUTTON ONLY
: Enter
: Ctrl-F1
: Enabled
: Instant-Off
: Enabled
: Disabled
33
CPU Warning Temperature
Current CPU Temperature
Current System Temp.
Current CPUFAN1 Speed
Current CPUFAN2 Speed
Vcore : 1.98 V
3.3 (V) : 3.55 V
+12 (V) : 11.97 V
- 5 (V) : - 0.02 V
CPUFAN Off In Suspend
ESC : Quit
F1 : Help
F5 : Old Values
F7 : Load Setup Defaults
SY-6IBM
: Disabled
: 28 C / 82 F
: 26 C / 78 F
: 5433 RPM
: 0 RPM
VTT (V) :
+ 5 (V) :
-12 (V) :
: Enabled
↑ ↓ → ←
: Select Item:
PU / PD / + / - : Modify
(Shift) F2 : Color
1.50 V
4.94 V
-12.04 V
