Chapter 3 Maintaining the Server
S e n d d o c u m e n t c o m m e n t s t o u c s - d o c f e e d b a c k @ c i s c o . c o m
Slide the server out the front of the rack far enough so that you can remove the top cover. You might
c.
have to detach cables from the rear panel to provide clearance.
Caution
d. Remove the top cover as described in the
on page
e. Remove the screw that holds the riser card assembly to the rear of the chassis. See
page
Lift the assembly and any attached PCIe cards straight up and out of the chassis. Lift up on both
f.
ends of the assembly evenly to avoid damaging the sockets or the riser cards.
Remove the screw that secures the PCIe card rear plate to the assembly rear slot (see
g.
Disconnect any cables from the card.
h.
i. Pull the PCIe card connector out of the riser card socket and set the card aside.
Step 2 Install a PCIe card:
a. If you are installing a PCIe card to an empty slot on the riser card assembly, remove any blank panel
from the assembly rear slot by removing the screw that secures the blank panel. Set the screw aside.
Note
Align the PCIe card connector with the riser card socket and push on both ends of the card evenly
b.
to fully engage the connector with the riser card socket.
Install the screw that secures the rear plate of the card to the assembly rear slot.
c.
Connect any cables to the card. Refer to the LSI documentation for the card for instructions.
d.
If you are installing the optional battery backup unit (BBU), this server requires that you install the BBU
Caution
differently than the LSI instructions to avoid overheating the card. See the
Instructions For the LSI MegaRAID Battery Backup Unit" section on page
Set the assembly in place, aligning the riser cards with the PCIe slots on the motherboard.
e.
Press down evenly on both ends of the assembly to fully engage the riser cards with the PCIe slots
f.
on the motherboard.
Replace the screw that secures the riser card assembly to the chassis.
g.
Replace the top cover.
h.
i. Replace the server in the rack, replace power cords and any other cables, and then power on the
server by pressing the Power button.
OL-20732-02
If you cannot safely view and access the component, remove the server from the rack.
3-8.
3-25.
A standard-profile PCIe card must be installed on the right side of the assembly, as viewed from
the rear of the server. A low-profile PCIe card can be installed in either the low-profile slots on
the left, or the standard-profile slots on the right if a standard-profile I/O bracket is used on the
card.
Installing or Replacing Components
"Removing and Replacing the Server Top Cover" section
Cisco UCS C200 Server Installation and Service Guide
Figure 3-14 on
Figure 3-16).
"Special Installation
3-30.
