3.1.3 Functional Specifications - DNP 3.0 Slave
The DNP 3.0 Slave driver provides extensive support for Slave implementations
of the protocol. The serial port on the gateway is user-configurable to support the
DNP 3.0 protocol (Slave, Error Checking, Baud rate, and so on).
General Parameters
Internal Database
Communication parameters
DNP Mode
DNP Slave
Node address

3.1.4 Hardware Specifications

Specification
Power Supply
Current Load
Operating Temperature
Storage Temperature
Relative Humidity
Dimensions
LED Indicators
Configuration
Serial Port
ProSoft Technology, Inc.
December 1, 2009
Binary Inputs: 0 to 500 word count
Analog Inputs: 0 to 500 points
Counters: 0 to 250 points
Binary Outputs: 0 to 200 word count
Analog Outputs: 0 to 500 points
Binary Input Events: 0 to 100 event buffer
Analog Input Events: 0 to 100 event buffer
Baud Rate: 110 to 115K baud
Stop Bits: 1
Data Size: 8 bits
Parity: None
RTS Timing delays: 0 to 65535 milliseconds
DNP 3.0 Slave - Level 2
0 to 65534 (software selectable)
Description
24 VDC nominal
18 to 32 VDC allowed
Positive, Negative, GND Terminals
2.5 mm screwdriver blade
500 mA max@ 32 VDC max
-20 to 50°C (-4 to 122°F)
-40 to 85°C (-40 to 185°F)
5% to 95% (non-condensing)
Standard: 5.20 H x 2.07 W x 4.52 D inches
(13.2 cm H x 5.25 cm W x 11.48cm D)
Extended: 5.20 H x 2.73 W x 4.52 D inches
(13.2 cm H x 6.934 cm W x 11.48cm D)
Power and Module Status
Application Status
Serial Port Activity LED
Serial Activity and Error LED Status
DB-9M RS-232 only
No hardware handshaking
ProLinx DNPS ♦ ProLinx Gateway
DNP 3.0 Slave
