ProSoft Technology ProLinx DNPS User Manual page 73

Reference
User Manual
OBJECT
Obj Var Description
4 16-Bit Frozen
Delta Counter
Event Without
Time
5 32-Bit Frozen
Counter Event
With Time
6 16-Bit Frozen
Counter Event
With Time
7 32-Bit Frozen
Delta Counter
Event With
Time
8 16-Bit Frozen
Delta Counter
Event With
Time
30 0 Analog Input:
All Variations
1 32-Bit Analog
Input
2 16-Bit Analog
Input
3 32-Bit Analog
Input Without
Flag
4 16-Bit Analog
Input Without
Flag
5 Short Floating
Point Analog
Input
6 Long Floating
Point Analog
Input
31 0 Frozen Analog
Input: All
Variations
1 32-Bit Frozen
Analog Input
2 16-Bit Frozen
Analog Input
3 32-Bit Frozen
Analog Input
With Time To
Freeze
ProSoft Technology, Inc.
December 1, 2009
REQUEST RESPONSE
Func Qual Func Qual
Codes Codes Codes Codes
(hex) (hex)
1 06
1 06 129, 00, 01
130
1 06 129, 00, 01
130
1 06 129, 00, 01
130
1 06 129, 00, 01
130
1 06 129, 00, 01
130
1 06 129, 00, 01
130
ProLinx DNPS ♦ ProLinx Gateway
Data NOTES
Size
(bits)
24 Slave will return Unknown Object to
this request
88 Slave will return Unknown Object to
this request
72 Slave will return Unknown Object to
this request
88 Slave will return Unknown Object to
this request
72 Slave will return Unknown Object to
this request
16 Slave will respond with variation 4
data
40 Slave will return this variation (Note:
Data will only be 16-bit)
24 Slave will return this variation
32 Slave will return this variation (Note:
Data will only be 16-bit)
16 Slave will return this variation
40 Slave will return this variation
72 Slave will return this variation
Slave will return Unknown Object to
this request
40 Slave will return Unknown Object to
this request
24 Slave will return Unknown Object to
this request
88 Slave will return Unknown Object to
this request
DNP 3.0 Slave
Page 73 of 86
