This Document is Hosted by: www.oldwillknottscales.com
MODEL 2341
BABY SCALE
Owners Manual
CARDINAL SCALE MFG. CO.
8535-M213-O1 Rev. B
PO BOX 151 WEBB CITY, MO 64870
06/11
PH (417) 673-4631 FAX (417) 673-5001
Web Site - http://www.detectoscale.com
Technical Support: Ph: 866-254-8261 techsupport@cardet.com
Advertisement
Related Manuals for Cardinal Detecto 2341
Summary of Contents for Cardinal Detecto 2341
- Page 1 This Document is Hosted by: www.oldwillknottscales.com MODEL 2341 BABY SCALE Owners Manual CARDINAL SCALE MFG. CO. 8535-M213-O1 Rev. B PO BOX 151 WEBB CITY, MO 64870 06/11 PH (417) 673-4631 FAX (417) 673-5001 Web Site - http://www.detectoscale.com Technical Support: Ph: 866-254-8261 techsupport@cardet.com...
-
Page 3: Specifications
SPECIFICATIONS Capacity ....16 kg x 5 kg Tray Size ....51 cm W x 20 cm D / 20 in W x 8 in D (flat portion) Overall Size ..... 51 cm W x 33 cm D x 19 cm H / 20 in W x 13 in D x 7.5 in H Application .... - Page 4 4. Unlock the beam by rotating the lock knob as indicated on the right side of the scale. (fig. 4) fig. 4 5. To zero scale, slide both upper & lower poise weights to the far left until they point to 0 Upper Poise Lower Poise fig.
-
Page 5: Operating Instructions
OPERATING INSTRUCTIONS 1. Before weighing, make certain the scale is set to zero. See set-up above if it is not. 2. Place infant on scale. 3. Lift the large lower poise and slide it until the beam tip starts 4. Slide the small upper poise until the beam pointer aligns with the fixed pointer. (fig. 7) 5.
