Cardinal DETECTO 1001T2B Instruction Sheet

Model
1001TB / 1001T2B
1001TBKG
1001TBNS / 1001T2BNS
1002TB / 1002T2B
1002TBKG
1002TBNS / 1002T2BNS
1051TBS
1051TBSKG
1052TBS
1052TBSKG
Cardinal Scale reserves the right to improve, enhance, and modify features and specifications without prior notice.
* All models with Scoop and Jar include:
P/N 6100-0002, SCOOP, PLASTIC.
P/N 6100-0005, JAR W/LID, POLYPROPYLENE.
Check for any damage to carton incurred in shipping and for damage to scale when unpacked. If the scale
has been damaged, place a claim with the carrier. It is the responsibility of the purchaser to file all claims for
any damages or loss incurred during transit. Use the original carton and shipping material if possible to return
the scale.
1. Open carton and remove packing and/or the scoop and counterweight jar.
2. Remove the inner scale carton and open. DO NOT use blade as you could scratch the scale.
3. Remove scale from carton by lifting on center of packing and pulling straight up.
4. Remove the weights form the outside of packing material.
5. Carefully remove the packing form either side of scale. Be careful as weights inside could fall out.
6. Remove weights from inside of packing.
Adjusting the Counterweight
1. Unscrew top from counterweight.
2. Place counterweight, top, and scale pan on respective sides.
3. Fill counterweight with sugar or salt until balance is achieved.
4. Secure top to counterweight.
To Move Poise
To move poise, lift up to clear notches on beam, and slide to desired position and release.
•
DO NOT subject the weight plates to sudden shocks.
•
DO NOT use abrasive cleaners, acetone, or other volatile solvents for cleaning scale.
•
DO clean the scale using a damp soft cloth and mild detergent.
•
DO avoid areas where the scale might be exposed.
8525-0366-O1 Rev B 03/18
PRODUCT SPECIFICATIONS
*Scoop
Capacity
and Jar
16 lb X
8 kg X
16 lb
8 lb X
5 kg X
8 lb
16 lb X
8 kg X
8 lb X
5 kg X
UNPACKING INSTRUCTIONS
OPERATING INSTRUCTIONS
CARE AND CLEANING OF SCALE
Mechanical Baker's Dough Scale
Instruction Sheet
Weight Stainless
Pack P/N Steel
1WP100X
1WK200X
1WP100X
1WP250X
1WK100X
1WP250X
1WP100X X
1WK200X X
1WP250X X
1WK100X X
Enamel
X
X
X
X
X
X
