GAS PRESSURE WASHER
039-8569-0
Congratulations on the purchase of your new
pressure washer. In order to ensure you have the best
possible experience please read through the following
instructions. If you require any help please contact the
customer service department at:
1-866-4SIMONIZ (1-866-474-6664
®
1-800-544-2444 (KOHLER
Engine)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simoniz Platinum 039-8569-0
Summary of Contents for Simoniz Platinum 039-8569-0
- Page 1 GAS PRESSURE WASHER 039-8569-0 Congratulations on the purchase of your new pressure washer. In order to ensure you have the best possible experience please read through the following instructions. If you require any help please contact the customer service department at: 1-866-4SIMONIZ (1-866-474-6664 ®...
-
Page 2: Table Of Contents
Table of Contents 1. Safety Advice......................3 1.1 Definitions......................3 1.2 Safety Warnings.....................3 1.3 Intended Application....................7 2. Parts List........................8 3. Assembled Model Diagram..................10 4. Assembly Instructions....................12 5. Operating Instructions....................15 5.1 Using Spray Nozzle.....................15 5.2 Water Supply (Cold Water Only)................15 5.3 Starting Pressure Washer..................15 5.4 Cleaning with Detergents..................16 5.5 Shutting Down and Cleaning Up................16 6. -
Page 3: Safety Advice
Safety Advice 3 TOXIC GASES 1. S AFETY DVICE Alerts against possible toxic gases which can be harmful to your health or deadly if IMPORTANT: RETAIN FOR FUTURE you are exposed to them. REFERENCE AND READ CAREFULLY! FLAMMABLE AND COMBUSTIBLE MATERIALS Do not attempt to install or operate this product Alerts against the presence of until you have read the safety instructions in... - Page 4 Safety Advice 1.2 Safety Warnings CAUTION – HOT ENGINE AND MUFFLER DANGER – WORK AREA THE ENGINE AND MUFFLER SAFETY AND EXHAUST FUMES BECOME VERY HOT DURING • Keep work area clean and well lit. Cluttered AND AFTER USE. AVOID and dark areas incite accidents.
- Page 5 Safety Advice 5 1.2 Safety Warnings CAUTION–ENGINE SAFETY • Certain components in this product and its related FLAMMABLE AND POISONOUS accessories contain chemicals which are known to MATERIALS cause cancer, birth defects, or other reproductive harm. Wash hands after handling. •...
- Page 6 Safety Advice 1.2 Safety Warnings CAUTION – SPECIFIC SAFETY ADVICE CAUTION – SPECIFIC SAFETY •This product is capable of producing high pressure ADVICE as rated in the Technical Specifications. To avoid • Avoid dangerous conditions. Always operate this rupture and injury, do not operate this product with product on dry, solid and level ground.
-
Page 7: Intended Application
•Low-Oil Auto Shut-Off: Protects the engine and refer to our website at www.simoniz.ca or prevents operating without proper lubrication. If the engine oil level goes below the recommended level, call us at 1-866-4SIMONIZ the pressure washer shuts off automatically. -
Page 8: Parts List
Parts List 2. P ARTS Ref. Description Qty. Visual Main frame Wheel with axle Handle & panel with five nozzles Spray gun with metal wand High-pressure hose 30′(9 m) Lower gun holster Upper gun holster... - Page 9 Parts List 9 Ref. Description Qty. Visual Hose hook Square neck bolt Knob Bolt and Nut 1 set Water inlet filter Spray tip cleaner Spark plug wrench Screwdriver Spare O-rings (two for high-pressure hose, one for quick-connector) Wrench Oil funnel...
-
Page 10: Assembled Model Diagram
Assembled Model Diagram 3. A SSEMBLED ODEL IAGRAM... - Page 11 Assembled Model Diagram 11 3. A SSEMBLED ODEL IAGRAM Ref. Description Ref. Description Spray nozzles (x5) Detergent tank caps Trigger safety lock Engine I/O switch Water outlet for pressure Spray gun with wand hose Starter cord handle Pump detergent inlet Muffler Air filter Oil tank with dipstick...
-
Page 12: Assembly Instructions
Assembly Instructions 4. A SSEMBLY NSTRUCTIONS Wheel Assembly NOTE: Make sure that there is enough air in wheel before assembly. Lift the frame (A) with one hand and attach one of the wheels (B) by pressing the wheel’s pin and inserting the wheel shaft into the main frame (A). - Page 13 Assembly Instructions 13 Hose Hook Assembly Hose Connection Attach the hose hook (H) to the Insert the water filter (L) into the back of handle assembly (C) until it pump inlet. Attach one end of slides into place. garden hose to pump inlet, and fasten the plastic nut counter-clockwise.
- Page 14 Assembly Instructions Gun/Hose Assembly Remove the air shield on pump outlet, then connect one end of pressure hose to pump outlet, and secure the plastic nut. Connect the other end to pressure gun, and fasten the plastic nut. Now your pressure washer is fully assembled.
-
Page 15: Operating Instructions
Operating Instructions 15 5.3 Starting Pressure Washer 5. O PERATING NSTRUCTIONS • Detach the quick connector from pump water inlet and screw it on a garden hose. Then attach them to 5.1 Using Spray Nozzle pump water inlet. This pressure washer comes with five different Attach the other end of garden hose to water source. -
Page 16: Cleaning With Detergents
Follow the detergent manufacturer’s 6. Disconnect the garden hose from the pump. directions or call the Simoniz toll-free number at 1-866-4SIMONIZ (1-866-474-6664) if you have any 7. Disconnect the pressure hose from the pump and questions or concerns. -
Page 17: Engine Operation
Engine Operation 17 6.2 Adding Fuel 6. E NGINE PERATION WARNING 6.1 Adding/Checking Oil •Make sure there is enough fuel in the fuel tank before operating the pressure washer. IMPORTANT • Use only clean, fresh, unleaded fuel. Use a Oil has been drained for shipping. Failure to fill minimum of 87 octane / 87 AKI (91 RON). -
Page 18: Starting Engine
•Remove the water inlet filter (L) from the pump inlet 6.3 Starting Engine pipe and clean. IMPORTANT If you have problems starting the pressure washer, Call the Simoniz toll-free number at 1-866-4SIMONIZ (1-866-474-6664) and one of our customer service representatives will be glad to assist you. IMPORTANT Before each use: •... -
Page 19: Cleaning And Maintenance
Cleaning and Maintenance 19 IMPORTANT Used oil is a hazardous waste product and must be disposed of properly. Do not discard with household waste. Check with your local authorities, service centre, or Canadian Tire for safe disposal/recycling facilities. Checking Air Filter IMPORTANT Clean air filter (12) element after every 50 hours of use (every 10 hours under dusty conditions). -
Page 20: Cleaning Carburetor
Cleaning and Maintenance the fuel from the tank, carburetor, and hose. Screw 7.3 Cleaning the Carburetor the carburetor drain hex screw back once the fuel has been completely drained. 1. Screw down the bolt on the bottom of carburetor with wrench. 2. -
Page 21: Winterizing Procedures
Technical Specifications 21 Cleaning and Maintenance 8. T ECHNICAL PECIFICATIONS 7.6 Winterizing Procedure • Pressure washer might be damaged if subjected to Maximum Pressure 2600 PSI freezing temperatures. This type of damage is not Rated Water covered by the limited warranty. To avoid possible 2000 PSI Pressure damages, use a small amount of antifreeze. -
Page 22: Troubleshooting
9. T OUBLESHOOTING NOTE: If your unit still is not functioning properly once you have used this guide please call the SIMONIZ toll-free service number at 1-866-4SIMONIZ (1-866-474-6664). Please do NOT bring the unit back to the store until you have called this number. - Page 23 Troubleshooting 23 PROBLEM POSSIBLE CAUSE SOLUTION Nozzle tip not attached Attach required nozzle tip Turn on faucet. Ensure there are no Water supply faucet closed kinks or blockage in hose Ensure faucet is fully opened. Check Water supply pressure is to make sure water supply is a minimum 30 psi, 4 GPM No pressure, low...
-
Page 24: Limited Warranty
The warranty is void if the equipment is used for commercial, rental, or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-4SIMONIZ (1-866-474-6664). Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8... -
Page 25: Exploded Parts Diagram 25
Exploded Parts Diagram 25 11. E XPLODED ARTS IAGRAM... - Page 26 Exploded Parts Diagram Ref. Description Ref. Description Handle foam Locknut M8 Handle Rubber foot Inner Hexagon Bolt M8×45 Cross pan head tapping screw ST4×25 Locknut M5 Rubber foot washer Back panel Inlet hose Hose hook Inlet hose nut High pressure hose Detergent tank Plug φ28 Cross pan head screw M5×40...
