GAS Pressure Washer
039-8563-8
Congratulations on the purchase of your new pressure
washer. In order to ensure you have the best possible
experience please read through the following instructions.
If you require any help please contact the customer ser-
vice department at:
1-866-4SIMONIZ
(1-866-474-6664)
Contact us for assistance, we're here to help.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simoniz 039-8563-8
Summary of Contents for Simoniz 039-8563-8
- Page 1 GAS Pressure Washer 039-8563-8 Congratulations on the purchase of your new pressure washer. In order to ensure you have the best possible experience please read through the following instructions. If you require any help please contact the customer ser- vice department at:...
-
Page 2: Table Of Contents
Table of Contents 1. Safety Advice......................3 1.1 Definitions......................3 1.2 Safety Warnings....................3 1.3 Intended Application..................7 2. Scope of Delivery....................8 3. Parts List.......................10 4. Assembly Instructions..................12 5. Engine Operation....................14 5.1 Adding/Checking Oil..................14 5.2 Adding Fuel.....................14 5.3 Checking Air Filter...................15 5.4 Starting Engine....................15 5.5 Stopping Engine....................15 6. -
Page 3: Safety Advice
Safety Advice 1. S AFETY DVICE TOXIC GASES IMPORTANT, RETAIN FOR FU- Alerts against possible toxic gases which can be TURE REFERENCE AND harmful to your health or deadly if you are exposed to them. READ CAREFULLY! Do not attempt to install or operate this product FLAMMABLE AND COMBUSTIBLE MA- until you have read the safety instructions in this TERIALS... -
Page 4: Safety Advice
Safety Advice 1.2 Safety Warnings DANGER–WORK AREA SAFETY AND WARNING–PERSONAL SAFETY EXHAUST FUMES • Stay alert, watch what you are doing, and use • Keep work area clean and well lit. Cluttered and dark common sense when operating a pressure washer. areas incite accidents. - Page 5 Safety Advice 1.2 Safety Warnings FLAMMABLE AND POISONOUS MATE- CAUTION–ENGINE SAFETY RIALS • Certain components in this product and its related • Gasoline is highly flammable and its vapours can accessories contain chemicals which are known to explode if ignited. Take precautions when using fuel cause cancer, birth defects, or other reproductive to reduce the chance of serious personal injury.
- Page 6 Safety Advice 1.2 Safety Warnings CAUTION–SPECIFIC SAFETY ADVICE • • This product is capable of producing high pressure CAUTION–SPECIFIC SAFETY ADVICE as rated in the Technical Specifications. To avoid • Avoid dangerous conditions. Always operate this rupture and injury, do not operate this product with product on dry, solid and level ground.
-
Page 7: Intended Application
This equipment was not designed for industrial use. Please refer to the icons below for suggested applica- tions. For questions regarding other uses, please refer to our website at www. simoniz.ca or call us at IMPORTANT–SAFETY FEATURES 1-866-4SIMONIZ (1-866-474-6664). • • Thermal Relief Valve: Protects the pump from overheating in case the nozzle gets clogged. -
Page 8: Scope Of Delivery
Scope of Delivery 2. S COPE OF ELIVERY Ref. Description Qty. Visual Main Frame Wheel with Axle Handle & Panel with 5 nozzles attached Spray Gun with Metal Wand High-Pressure Hose (25ft) Lower Gun Holder Upper Gun Holder Hose Hook Square Neck Bolt Securing Nut... -
Page 9: Scope Of Delivery
Scope of Delivery 2. S COPE OF ELIVERY Ref. Description Qty. Visual Bolt,Nut 1sets Water Inlet Filter Spray Tip Cleaner Spark Plug Wrench Screwdriver Spare O-Rings (2 for high pressure hose, 1 for quick-connector) Wrench Oil funnel... -
Page 10: Parts List
Parts List 3. P ARTS... -
Page 11: Parts List
Parts List 3. P ARTS Ref. Description Ref. Description Spray Nozzles (x5) Detergent Tank Trigger Safety Lock Detergent Tank Caps Spray Gun with Wand Air Filter Start Cord Handle Water Outlet for Pressure Hose Muffler Pump Detergent Inlet Oil Tank with Dipstick Engine I/O Switch Spark Plug Fuel Tank... -
Page 12: Assembly Instructions
Assembly Instruction 4. A SSEMBLY NSTRUCTIONS Letters refer to Scope of Delivery diagrams on pages 8 and 9. ２ Lift the main frame (A) with one hand and at- tach one of the wheels (B) by pressing the wheel’s pin and inserting the wheel shaft into the main frame (A). - Page 13 Assembly Instruction 4. A SSEMBLY NSTRUCTIONS ４ ６ Insert hose hook (H) to the groove of handle Insert the water inlet filter (L) into the pump assembly(C) until the end as per instruction. fresh water inlet (8). Then attach a garden hose or other means of water supply (not provided) to the pump inlet (8).
- Page 14 Assembly Instruction 4. A SSEMBLY NSTRUCTIONS ８ Attach one end of the pressure hose (18) to the spray gun (3) .Take down the air shield on pump water outlet (13), then attach to the other end of the pressure hose and fasten. Note: please make sure all the quick connectors are connected in the right direction.
-
Page 15: Engine Operation
Engine Operation 5. E NGINE PERATION 5.1 Adding/Checking Oil 5.2 Adding Fuel IMPORTANT WARNING • • • Make sure there is enough fuel in the fuel tank Oil has been drained for shipping. Failure to fill en- gine with oil before starting engine will result in per- fore operating the pressure washer. -
Page 16: Starting Engine
IMPORTANT If you have problems starting the pressure washer, 5.3 Stopping Engine call the Simoniz toll-free number at 1-866-4SIMONIZ • To stop the engine set the engine I/O switch (1-866-474-6664) and one of our customer service (15) to O position. -
Page 17: Operating Instructions
Operation Instructions 6. O PERATION NSTRUCTIONS 6.3 Using Pressure Washer 6.1 Using Spray Nozzle This pressure washer comes with 5 different • Start the engine (→Starting Engine). nozzles (1) that can be installed on the stain- • Install appropriate spray nozzle (1). less steel wand (11). -
Page 18: Cleaning With Detergents
6.5 Shutting Down and Cleaning Up Follow the detergent manufacturer’ s directions or call the Simoniz toll-free number at 1-866-4SIMONIZ 1. Skip step two if you are not using detergent. (1-866-474-6664) if you have any questions or con- 2. -
Page 19: Cleaning And Maintenance
Cleaning and Maintenance 7. C LEANING AND AINTENANCE Inspecting, Replacing or Cleaning the Spark Plug WARNING The spark plug should be checked every 100 DO NOT operate this pressure washer without the hours of operation or every 6 months. water inlet filter in place, as deposits could build up internally and affect the functioning of the unit. -
Page 20: Cleaning The Spray Tips
Cleaning and Maintenance 7. C LEANING AND AINTENANCE 7.4 Storing 3. Check the gap with a wire gauge. If neces- sary, reset the gap to 0.7-0.8 mm. Install and Store idle product out of the reach of children tighten the spark plug to the recommended and do not allow persons unfamiliar with the torque–180 lb-in (20 Nm). -
Page 21: Winterizing Procedures
Cleaning and Maintenance/Technical Specifications 7. C LEANING AND AINTENANCE IMPORTANT • If the pressure washer is to be stored with gasoline in the fuel tank and carburetor, it is important to re- duce the hazard of gasoline vapor ignition. • Select a well-ventilated storage area away from any appliance that operates with a flame, such as a furnace, water heater, or clothes dryer. - Page 22 NOTE: If your unit still is not functioning properly once you have used this guide please call the SIMONIZ toll-free service number at 1-866-4SIMONIZ (1-866-474-6664). Please do NOT bring the unit back to the store until you have called this number.
-
Page 23: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Nozzle tip not attached Attach required nozzle tip Turn on faucet. Ensure there are Water supply faucet closed no kinks or blockage in hose Ensure faucet is fully opened. Water supply pressure is Check to make sure water supply is a minimum 30 psi, 4 Clean the water filter. - Page 24 pressure washer 9. T ROUBLESHOOTING...
-
Page 25: Limited Warranty
The warranty is void if the equipment is used for commercial, rental, or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-4SIMONIZ (1-866-474-6664). -
Page 26: Explosion View
Explosion View 11. E XPLOSION... - Page 27 Explosion View 11. E XPLOSION Ref. Description Qty. Ref. Description Qty. Rubber Foot Handle Foam Handle M8×45 ST4×25 Rubber Foot Washer Locknut M5 Inlet Hose Back Panel Inlet Hose Nut Hose Hook Detergent Tank High Pressure Hose M5×40 Plug Square Neck Bolt Lower Gun Holder Securing Nut Assembly M5×50...
